Product Overview
What This Product Is And Who It Is For
A 24V light bar held in place by magnets rather than screws. That single change removes the drilling, the fixings and the sealed penetrations from a cabinet or cooler installation, and it lets staff lift the bar off to clean behind it. Maximum current is 45 mA per LED and the working and storage temperature range runs from minus 20 to 45 degrees Celsius, which covers chilled and most display applications.
Key Benefits
Why Buyers Choose This Build
Magnetic mounting means no drilling, no fixings and no new holes in a cabinet or cooler liner
The bar lifts off for cleaning, which matters in food display
Rated from minus 20 to 45 degrees Celsius, so it works in chilled cabinets as well as dry display
Low lumen depreciation and consistent colour temperature across multiple bars in one cabinet
Application
Where It Fits And What It Fixes
Who It Is For
- Retail and display cabinet operators retrofitting lighting
- Refrigeration service companies upgrading existing cases
- Shopfitters who need a reversible installation
Problems It Solves
- Retrofits where drilling a cabinet liner would break its seal or its warranty
- Display cases that must be cleaned around the lighting every day
- Multi bar installations where visible colour differences between bars spoil the display
Application Scenarios
- Cabinets
- Display counters
- Lockers
- Refrigerator and cooler lighting
Technical Features
- Magnetic mounting with no drilling required
- Working voltage 24V DC
- Maximum current 45 mA per LED
- Working and storage temperature minus 20 to 45 degrees Celsius
- Low lumen depreciation and long lifetime
- Multiple colours available with consistent CCT and no visible aberration
- Multiple accessories available for convenient installation
Specifications
Specification Table
Figures below are the published specification for this build. Where a value is set per order it is stated as such rather than estimated.
- Working Voltage
- DC 24V
- Maximum Current
- 45 mA per LED
- Working Temperature
- -20 to 45 degrees Celsius
- Storage Temperature
- -20 to 45 degrees Celsius
- Mounting
- Magnetic
- Colour Options
- Multiple colours available
Manufacturing
How It Is Made Checked And Customised
Materials
- Aluminium bar body
- Magnetic mounting hardware
- Mid power LED board
Manufacturing Process
- LED board assembly
- Bar profile assembly
- Magnet fitting
- Lit and current test
- Cold chamber check
- Packing
Quality Control
- Incoming LED and magnet inspection
- Current measurement per bar
- Colour consistency sorting across a batch
- Low temperature function check
Certifications
- CE
- RoHS
Customisation Options
- Bar length and LED count
- Colour temperature selection
- Mounting accessory selection
- Lead length and connector
Comparison
How It Compares With Other Products In The Range
Compared With DC Linear Module Standard for Cooler Application
A fixed rigid board for a case maker to build in, not a removable retrofit bar
Compared With Strip Light 2835 Energy Saving
A flexible reel for long or curved runs where a rigid bar cannot follow the shape
Use Guide
Specifying And Installing It Correctly
- Check the mounting surface is ferrous before specifying magnetic mounting
- Order matched bars for one cabinet so the colour temperature stays consistent along the run
- Keep the bar within the minus 20 to 45 degree working range, including during defrost cycles
Related Products
Other Products Worth Comparing
Cooler LED Module
Strip Light 2835 Energy Saving Solution
24V 5 m reels from 300 to 800 LEDs, CRI above 90, IP20 or IP67
View Specifications →
Cooler LED Module
DC Module Standard for Cooler Lighting Tunable White
Dual channel 2700K and 6500K boards in 140, 280 and 560 mm with CRI 80, 90 or 98
View Specifications →
LED Module
DC Module High Efficiency 24V Linear
600 x 24 mm 24V board reaching 200 lm/W for panels, linears, troffers and wall lights
View Specifications →Go Deeper
Industry Pages And Guides That Cover This Product
Refrigeration And Cold Display
Lighting for refrigerated cases has to work at low temperature, survive condensation and wash-down, render fresh food honestly and add as little heat as possible to the plant.
Read More →
Residential Cabinet And Wardrobe
Cabinet and wardrobe lighting is a detail, and details are looked at closely.
Read More →
Buying Guide
How To Choose LED Modules For Cooler Lighting
Cold display lighting is chosen on four things at once: efficacy, colour rendering, sealing and physical fit. This guide works through them in the order that actually affects the decision.
Read The Guide →FAQ
Magnetic Light Energy Saving Solution FAQ
How does it mount?
Magnetically, with no drilling. Additional mounting accessories are available.
What is the working temperature range?
Minus 20 to 45 degrees Celsius for both working and storage.
What is the maximum current per LED?
45 mA.
Will bars match each other in colour?
Multiple colours are available and are sorted so the colour temperature stays consistent without visible aberration.
Request A Quote For Magnetic Light Energy Saving Solution
Tell us the quantity, the colour temperature and the profile it has to fit. We will confirm the part number and the lead time.
