How To Choose A Paper Bubble Machine
Three paper bubble machines cover sample work, roll production and sheet production. The choice comes down to output format, width and roll handling.
Start With The Output Format
Ask first whether the packing station works from a dispenser or from a pile. The EM-PB800 winds a roll up to 1000 mm in diameter. The EM-PB600 sheet machine cuts, slits and stacks sheets at 300 pieces per minute measured at 200 x 200 mm. Buying the wrong format means adding a cutting step you did not plan for.
Paper Bubble Sheet Making Machine
Then Width And Speed
The EM-PB800 runs 800 mm wide at zero to 60 m per minute. The EM-PB600 mini runs 600 mm at zero to 45 m per minute. Width usually matters more than speed, because a roll that is too narrow forces double wrapping and wastes both paper and bench time.
Kraft Paper Bubble Making Machine
Roll Handling Is A Safety Decision
The EM-PB800 has an automatic lifting unwinding system for parent rolls up to 1200 mm in diameter. The mini machine unwinds by manual loading within a 600 mm limit. If your parent reels are large, roll handling is not a convenience question.
Do Not Skip The Sample Machine
The 400 kg EM-PB600 mini produces genuine embossed paper bubble, not a mock-up. Converters running a production line often keep one so a customer approval sample does not have to stop the main machine.
Questions On This Topic
What is the minimum paper weight?
60 gsm on the roll machines and 80 gsm on the sheet machine, which runs up to 180 gsm.
Which machine gives the largest finished roll?
The EM-PB800, at up to 1000 mm rewinding diameter.
Is the emboss pattern fixed?
It is set by the embossing rollers, so specify the pattern with the order.
