AC and Fluid Service
Air conditioning and transmission work where the job is to remove what is in the system, not just top it up.
AC Service Machine · Model AC700S
AC700S Automatic AC Service Machine With Flushing Function
Fully automatic R134a station with flushing
Product Overview
AC700S is a fully automatic R134a air conditioning service station that flushes, recovers, drains used oil, injects new oil and recharges without the operator driving each step. Flushing cleans the system on the vehicle to restore cooling efficiency, and an LCD screen with database and printer documents what was done.
Key Benefits
What This Machine Changes in the Bay
- Automatic flushing deep cleans the air conditioning system to improve cooling efficiency
- On-vehicle pipeline cleaning means the system does not have to come off the car
- More powerful compressor recovers refrigerant faster, so bay time per vehicle drops
- Oil separator divides gas and oil so refrigerant can be reused
- LCD screen with database and printer gives the customer a record of the service
Application Scenarios
- Air conditioning service on R134a vehicles
- Poor cooling complaints caused by contaminated systems
- Post-compressor-failure clean out before fitting a new compressor
- Seasonal air conditioning service campaigns
Who It Is For
- General workshops offering air conditioning service
- Air conditioning specialists
- Fleet workshops servicing R134a vehicles
- Distributors supplying air conditioning equipment
Problems It Solves
What It Stops Costing You
- Debris left in the system after a compressor failure destroys the replacement
- Poor cooling returns if the system is only recharged rather than cleaned
- Manual procedures vary between technicians and produce inconsistent charges
- Customers dispute air conditioning invoices without a printed record
Technical Features
- Fully automatic operation for R134a refrigerant
- Automatic flushing
- Automatic recovering
- Automatic and manual vacuum
- Automatic and manual used oil drain
- Automatic and manual new oil injection
- Oil separator for gas and oil separation to reuse refrigerant
- Large observation window with LED backlight
- Auxiliary port for multiple charging methods
- On-vehicle cleaning of the air conditioning pipeline
- LCD screen with database and printer
Specifications
Compared With Other Models
- Against the AC700: fully automatic operation with an LCD screen, database and printer instead of semi-automatic control and an LED display
- Against the AC720S: built for R134a rather than R1234yf
- Against a recovery-only unit: flushing and oil management, not just refrigerant handling
Use Guide
- Connect the service couplers to the vehicle and select the model from the database
- Run the flushing cycle where the system has been contaminated
- Let the machine recover, vacuum, drain oil, inject new oil and recharge automatically
- Print the record for the customer file
Quality and Support
What Comes With the Machine
Quality Assurance
Every product is supplied with a long warranty assurance.
Expert Guidance
Pre-sales and after-sales teams give professional guidance and aftersales support.
Reliability
Consistent and reliable performance across every product line.
Innovation
An experienced R&D team develops the products the market asks for.
Customization. Machines are built to your local voltage and frequency, and optional equipment is listed on the quotation. Send us your requirement and we will confirm what can be changed before you order.
Bay Solutions Using This Machine
AC700S Questions Buyers Ask
Which refrigerant does it use?
R134a. For R1234yf vehicles see the AC720S or AC720.
What does the flushing function do?
It deep cleans the air conditioning system to improve cooling efficiency, and can clean the pipeline on the vehicle.
Can it work in manual mode?
Vacuum, used oil drain and new oil injection can each be run automatically or manually.
Does it print a service record?
Yes, the machine has an LCD screen, a database and a printer.
Why does it have an oil separator?
Separating gas and oil allows the recovered refrigerant to be reused.
What is the lead time for export orders?
Lead time depends on quantity and voltage variant. Send your requirement and we will confirm in writing.
