1200.C Chamber Furnace with Lift-Up Door/Opens from Bottom Up
Highlight Heating from Three Sides: Ensures uniform temperature distribution. Intelligent Touch Screen Controller: Provides easy and precise control of the furnace settings. Vacuum-Formed Ceramic Fiber Furnace Chamber: High-efficiency insulation for optimal temperature retention. Double-Layer Steel Casing with Fan...
Introduction
The 1200.C Chamber Furnace with Lift-Up Door is a laboratory device specifically designed for high-temperature heat treatment. It is widely used in material science, metallurgy, chemical engineering, ceramics, and other fields. The furnace features a hydraulic system for controlling the door, ensuring safe and convenient operation while maintaining excellent sealing performance under high temperatures. With a maximum temperature of 1200°C, it is suitable for sintering, ashing, pyrolysis, and other processes involving various samples.
Key Features
- Hydraulic Drive System
- Safe and Reliable: Advanced hydraulic technology enables smooth and rapid opening and closing of the furnace door, reducing mechanical wear and extending equipment lifespan.
- Precise Temperature Control System
- High-Precision PID Regulation: Incorporates advanced PID control algorithms and supports multi-step temperature programming, ensuring precise and stable temperature control with excellent repeatability.
- Real-Time Monitoring: The touchscreen interface provides real-time temperature curve monitoring and data recording for convenient analysis and report generation.
- Excellent Sealing Performance
- High-Temperature Seal: Special high-temperature-resistant seals around the door ensure reliable sealing, even at elevated temperatures, preventing external air intrusion that could affect experimental results.
- User-Friendly Design
- Spacious Chamber: A large heating chamber accommodates larger samples or multiple samples simultaneously.
- Easy to Clean: The simple internal structure facilitates cleaning and maintenance, reducing residue impact on subsequent experiments.
- Easy to Operate: The intelligent 7″ color touch screen controller provides simple operation and a clear heating process.
Which Kinds of Industry Can Use This 1200.C Chamber Furnace?
College & Universities, New Material Research, New Energy, Powder Metallurgy, Electronics, Ceramic, Chemistry, Medicine,etc.
Applications of 1200.C Chamber Furnace with Lift-Up Door
- Material Synthesis and Sintering
- High-temperature synthesis and sintering of metallic powders, ceramics, and advanced composite materials.
- Processing of new materials for industrial and research applications.
- Thermal Treatment
- Annealing, tempering of metals and alloys.
- Decomposition and calcination processes for chemicals and materials.
- Chemical Analysis
- Ashing of organic and inorganic samples for compositional analysis.
- Thermal decomposition experiments for studying material properties.
- Environmental Testing
- Analysis of soil, sludge, and waste materials for contaminants or valuable compounds.
- Preparation of samples for environmental monitoring and research.
- Laboratory Research and Development
- Conducting heat treatment experiments in universities, research institutes, and industrial R&D labs.
- Development and testing of novel materials and coatings.
- Ceramic and Glass Production
- Firing and sintering of ceramic components, glazes, and glass materials.
- Small-scale production and quality testing of ceramic goods.
- Energy and Electronics
- Processing of materials for battery research, such as cathodes and anodes.
- Fabrication and testing of semiconductor and electronic components.
The lift-up door design improves safety and ergonomics, making the furnace particularly suitable for high-frequency use in laboratories and production environments.
Specifications
Figures below are the manufacturer data for this model. Anything not listed is confirmed in writing with the quotation rather than estimated here.
| Model | M1200-20 |
|---|---|
| Maximum Temperature | 1200°C |
| Rated Temperature | 1150°C |
| Touchscreen Size | 7.0″ |
| Heating Rate | 1°C/H – 20°C/Min |
| Sensor Type | K-Type Thermocouple |
| Rated Power | 4 KW |
| Chamber Dimensions | 200×200×300(D) mm |
| External Dimensions | 530×700×580 mm |
| Control System | Intelligent Touchscreen Controller 1. Embedded operating system with a bilingual graphical interface (Chinese/English), 7-inch true-color touchscreen input, smart human-machine interaction mode, and non-linear sample temperature correction. 2. Stores up to 15 curves, each configurable with 30 “time-temperature” programs, saving time on repetitive curve modifications. 3. Features over-temperature alarms, thermocouple disconnection prompts, and leakage protection. |
| Temperature Accuracy | ±1°C |
| Heating Element | Top Quality Resistance wire Heating Chamber of 1200.C Chamber Furnace |
| Net Weight | 64 KG |
| Service and Support | One-year limited warranty with lifetime support |
1200.C Chamber Furnace with Lift-Up Door/Opens From Bottom Up In Detail
