TMK-500 500 kg Per Day Organic Waste Composter With Built-In Bin Lifter
The TMK-500 is equipped with the latest PLC technologies and automation control systems, and it decomposes 500 to 550 kg of organic food waste in an expected 21 to 24 hours using stage-in-craft indirect heating...
What the TMK-500 Composter Does
The TMK-500 is equipped with the latest PLC technologies and automation control systems, and it decomposes 500 to 550 kg of organic food waste in an expected 21 to 24 hours using stage-in-craft indirect heating and dry composting. Its built-in bin lifter means staff are not lifting wheelie bins by hand, which is the practical difference at this size. It is described as designed for larger requirements in medical outlets and comes with a 3 year warranty.
Why This Model and Not the Next One Up
180 tons per year processed on site, covering a large hotel, hospital or shopping centre
Built-in bin lifter system so food waste input does not depend on manual lifting
500 to 550 kg decomposed in an expected 21 to 24 hours
Latest PLC technologies and automation control systems
3 year warranty stated for this model
Buyers This Model Suits
- Commercial buildings, shopping centres, schools, large hotels and resorts, hospitals and municipalities
- Sites where staff currently move wheelie bins by hand
- Operations needing 21 to 24 hour turnaround on several hundred kilos a day
- Medical outlets with larger catering requirements
What It Takes Off Your Plate
- Manual handling risk and labour time spent tipping bins
- Waste that would otherwise sit between collections on a busy dock
- Disposal cost at a site producing several hundred kilos of organics a day
- Secondary pollution, since the process uses no water and holds no toxic traits
Where It Gets Installed
Commercial building or shopping centre collecting from several food tenants
Large hotel or resort with banqueting peaks
Hospital or medical outlet catering department
School or municipal catering operation at district scale
How It Is Built
- Stage-in-craft indirect heating with dry composting technology
- Built-in bin lifter system for easy food waste input
- Lifting plus fermentation and deodorization function
- WiFi, touch screen and PLC control
- Stainless steel tank with an expected lifespan of over 20 years
- Overload function halts the machine during an overload to avoid spillage and danger to the user
Materials
- Stainless steel composting tank
- Q235 structural steel body with spray paint finish
Process Sequence
Bin lift and feed → Indirect heating → Dry aerobic composting → Deodorization → Discharge
TMK-500 Composter Specification Table
| Capacity | 500kg/day, 180tons/year |
|---|---|
| Dimensions (L*W*H) | 2,812mm x 1,874mm x 1,644mm |
| Machine Weight | 1800kgs |
| Machine Material | Q235 + Spray Paint |
| Process Type | Aerobic Composting |
| Process Duration | Within 24 Hours |
| Function | Lifting + Fermentation & Deodorization |
| Other Functions | Wifi + Touch Screen + PLC Control |
| Volume Reduction | 85-90% |
| Micro-Organism | Yes (add every 3-6 months) |
| Power Supply | AC380V, 60Hz,15KW |
| Output | Organic Fertilizer |
Figures as published by TMK for this model. Confirm voltage and frequency for your destination country before ordering.
TMK-500 Composter in Detail
What Is Controlled and Protected
- Overload function stops the machine before spillage or operator risk
- Sterilization within the process makes the output relatively safe for human handling
- No wastewater generated and no toxic traits in the process
What Can Be Configured
- Bin lifter configuration for 120 and 240 litre wheelie bins
- Automatic door opener available on the commercial range
- Power supply confirmed for the destination country
How It Compares
Compared with
TMK-1000 Composter
The TMK-1000 doubles capacity to 365 tons per year and adds the SS-304 chamber, shaft and blade specification.
Compared with
TMK-300 Composter
The TMK-300 covers 110 tons per year at 8 KW with an optional bin lift. The TMK-500 nearly doubles throughput and has the bin lifter built in.
Compared with
Traditional composting method
A waste composter machine occupies less space because it is compact, and it does not need a landfill or any other compost technique behind it.
Running the TMK-500 Composter
- Separate water and solids before loading
- Use the built-in bin lifter rather than manual tipping
- Expect a 21 to 24 hour cycle for a full load
- Add micro-organism every 3 to 6 months
- Route the pathogen-free organic fertilizer and sterile condensate stream to their planned destinations
Accepted input: Vegetable leaves, leftovers, vegetable peel, fish, meat, shrimp shells, crab shells, egg shells, small bones, bread, coffee grounds.
Keep out: Plastic products, metals, ceramics, fuel oil, solvents, large wood, large animal bones, cloth, other domestic waste, hazardous waste.
TMK-500 Composter Questions
How much can the TMK-500 actually process
500 kg per day rated, and the machine is described as decomposing 500 to 550 kg of organic food waste in an expected 21 to 24 hours. That is 180 tons per year.
Is a bin lifter included
Yes. The TMK-500 has a built-in bin lifter system for easy food waste input.
What is the expected service life
The tank is stainless steel and is stated to have a lifespan of over 20 years.
What warranty applies
This model is described as coming with a 3 year warranty. Confirm the terms for your destination country at quotation.
What are the dimensions and weight
2812 mm by 1874 mm by 1644 mm, weighing 1800 kg, at AC380V 60Hz 15 KW.
