90W Wireless Handheld Remote Control Search Light 370°Rotation X 135°Tilt
The SLL-2090 is a 90W wireless handheld remote control search light designed for operators who need to scan large areas in complete darkness, on vehicles that operate in extreme conditions. It delivers 7000 lumens with a max beam distance of 1000 meters and features 370 degree rotation and 135 degree tilt, allowing a single operator to cover a full hemisphere without repositioning the light. The die-cast aluminium housing with UV polyester powder coating resists corrosion and impact, while IP68 sealing ensures operation after immersion or exposure to high-pressure washes. The light runs on 9–32V DC, making it compatible with both 12V and 24V vehicle systems, and includes overvoltage and overheat protection for reliable use in harsh environments.
- 370 degree rotation and 135 degree tilt allow full hemisphere coverage without moving the light
- 7000 lumens with a 1000 meter max beam distance provide visibility over long distances
- IP68 sealing ensures operation after immersion or exposure to high-pressure washes
- 9x10W CREE LEDs deliver high output with a 50,000 hour lifespan, reducing replacement frequency
- 9–32V DC input works on both 12V and 24V systems, reducing the number of SKUs needed
Where This Lamp Is Used
- Nighttime inspection of large construction sites, cranes, or mining equipment where a fixed light cannot cover all angles
- Emergency response on off-road vehicles or utility trucks where rapid scanning of terrain is required
- Security patrols on vessels, boats, or industrial yards where a handheld light must operate without wires
- Maintenance access on heavy machinery where a fixed light cannot reach tight or overhead areas
- Fleet operations in remote regions where a single light must serve multiple vehicle types with different power systems
Who It Is For
- Fleet operators needing a single search light for 12V and 24V vehicles without changing parts
- Machinery OEMs integrating a high-output handheld light into new machine designs
- Distributors selling search lights for off-road, marine, and industrial applications
- 4x4 accessory brands building a private label search light range with remote control
- Equipment dealers fitting a versatile light on service trucks and utility vehicles
Problems It Solves
- Fixed search lights require multiple units or frequent repositioning to cover a full hemisphere
- Wired handheld lights limit mobility and risk damage from cable strain or water ingress
- Lights without overvoltage protection fail during alternator spikes or battery jumps
- Painted or plastic housings degrade under UV exposure or impact on rugged machinery
Technical Features
- 9x10W CREE LEDs with a real output of 7000 lumens and a theoretical maximum of 9000 lumens
- Max beam distance of 1000 meters with a spot beam option available
- 370 degree rotation and 135 degree tilt for full hemisphere scanning
- Die-cast aluminium housing with durable UV polyester powder coating
- Anti-impact polycarbonate lens with UV resistance and scratch protection
- 5 meter cord with cigarette plug for direct vehicle power connection
- Overvoltage and overheat protection circuits for electrical and thermal safety
- Operating temperature range of -40 to +60 degrees Celsius
- IP68 sealing for dustproof and waterproof operation
- 9–32V DC input compatible with 12V and 24V vehicle systems
- Available with magnetic mount shoe with suction cup or 4-hole screw mounting
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-2090 |
|---|---|
| Max Power | 90W |
| Real Power | 90W |
| LED | 9 pcs x 10W CREE |
| Beam Pattern | Spot (optional) |
| Rotation | 370 degrees |
| Tilt | 135 degrees |
| Colour Temperature | 6000K |
| Operating Voltage | 9–32V DC |
| Housing Material | Die-cast aluminium, UV polyester powder coating |
| Lens Material | Durable polycarbonate |
| Mounting Options | Magnetic shoe with suction cup or 4-hole screw mount |
| Cord Length | 5 meters with cigarette plug |
| Waterproof Rating | IP68 |
| Operating Temperature | -40 to +60 degrees Celsius |
| Electrical Protection | Overvoltage and overheat protection |
| Lifetime | 50,000 hours |
Materials Used
- Die-cast aluminium housing with UV polyester powder coating
- Durable polycarbonate lens with anti-scratch and UV-resistant properties
- CREE 10W LEDs with high lumen output and long lifespan
- Silicone gasket and sealed cable entry for IP68 protection
- 5 meter flexible cord with cigarette plug for vehicle power access
- Magnetic shoe with suction cup or 4-hole screw mounting bracket
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating with UV polyester finish for corrosion and UV resistance
LED board assembly with CREE emitters and thermal management
Lens bonding with silicone seal and gasket installation
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating using water immersion test
- Vibration testing on a vibration test machine to simulate vehicle-mounted operation
- Salt spray corrosion testing on housing coating and metal components
- High and low temperature alternating humidity testing across the -40 to +60 degrees Celsius range
- Overvoltage and overheat protection tested under simulated electrical stress
Customisation Options
- Spot beam optics instead of standard flood or wide beam
- Alternative mounting options including custom brackets or rail mounts
- Private label logo on the housing and printed carton
- Different cord length or connector type for specific vehicle harnesses
- Mixed cartons combining this light with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Wired handheld search light | The wireless design with 5 meter cord allows full mobility without cable drag or risk of damage |
|---|---|
| Fixed search light with limited tilt | 370 degree rotation and 135 degree tilt cover a full hemisphere without repositioning |
| Lower power 50W handheld light | 90W output with 1000 meter beam distance provides visibility over twice the distance |
| Plastic-bodied handheld light | Die-cast aluminium housing resists impact and heat better than plastic in high-use environments |
How to Fit and Use It
- Attach the magnetic shoe or screw mount to the vehicle or equipment before use
- Plug the 5 meter cord into a 9–32V DC power source using the cigarette plug
- Ensure the cord is routed away from moving parts and does not create a tripping hazard
- Use the remote control to adjust rotation and tilt to scan the desired area
- Do not operate the light continuously above 30 minutes without cooling to prevent overheating
- Clean the polycarbonate lens with water and a soft cloth only; avoid solvents
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this light work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be used on both 12V and 24V vehicles.
Can you supply the light with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for use on vehicles used on public roads
The light is CE and RoHS compliant and carries IP68 sealing, but road use depends on local regulations and vehicle type.
