7 Inch 50W Black/White Color Remote Control LED Search Light SLL-CH001-50W
The SLL-CH001-50W is a 7 inch remote control LED search light designed for vehicles and heavy machinery that operate in low visibility conditions. Ten 5W high intensity LEDs deliver 4000 lumens in a 30 degree spot beam, providing a focused beam that reaches deep into dark areas without spreading light across the surrounding terrain. The die-cast aluminium housing and polycarbonate lens are rated IP65, protecting the internal components from dust and water spray during prolonged outdoor use. The light operates on 12V or 24V DC systems and has a lifetime of more than 30000 hours, reducing the need for frequent replacements on machines that run long shifts.
- 30 degree spot beam concentrates light at distance instead of spreading it across the ground
- Remote control allows operation from inside the cab without leaving the driver's seat
- IP65 sealing resists dust and water spray during operation in rain or washdown conditions
- 12V and 24V DC operation means one part number works across different fleet voltage systems
- 30000 hours lifetime reduces maintenance frequency on machines that operate in remote locations
Where This Lamp Is Used
- Search and navigation lighting on off-road vehicles operating at night in mining or forestry zones
- Emergency lighting on cranes and excavators during night shifts or power outages
- Auxiliary lighting on service trucks and utility vehicles responding to roadside incidents
- Visibility enhancement on boats and vessels in low light or foggy conditions
- Remote operation on machinery where the operator cannot access the light directly
Who It Is For
- Fleet operators managing 12V and 24V vehicles who need a single search light model for both systems
- Machinery OEMs integrating a search light into production line builds with consistent mounting
- Distributors selling remote control lighting for 4x4 and off-road accessory markets
- Equipment dealers fitting search lights on custom-built machines for mining or construction
- 4x4 accessory brands developing a private label search light with remote control functionality
Problems It Solves
- Fixed search lights require the operator to exit the cab to activate them, increasing risk in hazardous environments
- Non-remote lights with short cables limit placement and reduce usability on large machines
- Lights without IP65 sealing fail after exposure to rain, dust or pressure washing
- Low lumen output or wide beam patterns waste light on distant targets and leave nearby areas dark
- Short lifetime lights require frequent replacement on machines that run multiple shifts per week
Technical Features
- Ten 5W high intensity LEDs with a total power draw of 50W and 4000 effective lumens
- 30 degree spot beam pattern focused at distance with no spill light to the sides
- Die-cast aluminium housing with a semi-gloss black or white finish and polycarbonate lens
- Remote control with a range sufficient for typical cab-to-light distances on heavy machinery
- 12V and 24V DC input allows use on both 12V and 24V vehicle electrical systems
- Operating temperature range of -40 to +60 degrees Celsius for use in extreme climates
- IP65 rating protects against dust and water jets from any direction
- Mounting bracket compatible with standard 7 inch light mounting patterns
- Cable entry gland sealed to prevent water ingress during operation
- Lifetime of more than 30000 hours under continuous operation
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-CH001-50W |
|---|---|
| Max Power | 50W |
| Real Power | 50W |
| LED | 10 pcs x 5W high intensity |
| Theoretical Lumen | 4000 lm |
| Effective Lumen | 4000 lm |
| Beam Pattern | Spot |
| Beam Angle | 30 degrees |
| Colour Temperature | 6000K |
| Operating Voltage | 12/24V DC |
| Housing Material | Die-cast aluminium |
| Lens Material | Polycarbonate |
| Bracket Material | Steel, powder coated |
| Mounting | Standard 7 inch mounting pattern |
| Waterproof Rating | IP65 |
| Electrical Connection | Bare wire lead, length not specified |
| Lifetime | More than 30000 hours |
| Size | 7 inch diameter |
| Packing | 1 unit per carton |
| Certification | CE, RoHS |
Materials Used
- Die-cast aluminium housing for heat dissipation and structural strength
- Polycarbonate lens with anti-reflective coating for clear light transmission
- Steel mounting bracket with powder coating for corrosion resistance
- Silicone gasket and sealed cable gland for IP65 protection
- Semi-gloss black or white powder coating on the housing
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in black or white finish
LED board assembly with ten 5W high intensity emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP65 rating before shipment
- Vibration testing on a vibration test machine to simulate machine-mounted service
- Salt spray corrosion testing on housing coating and steel bracket
- High and low temperature alternating humidity testing across the -40 to +60 degrees Celsius window
Customisation Options
- Remote control with extended range or different frequency for specific environments
- Alternative cable length to match a specific machine harness
- Private label logo on the housing and printed carton
- Alternative body color beyond black and white
- Mixed cartons combining this light with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Fixed search light without remote control | Remote control allows safe operation from inside the cab, reducing exposure in hazardous conditions |
|---|---|
| Wider beam search light | 30 degree spot beam reaches further than a wide beam but avoids illuminating unnecessary areas |
| Lower lumen search light | 4000 lumens provides greater visibility at distance compared to lower output models |
| Non-IP65 rated light | IP65 sealing prevents water and dust ingress during washdown or outdoor use |
How to Fit and Use It
- Mount on a flat surface using the standard 7 inch mounting pattern and ensure the bracket is secure
- Keep the remote control within range of the light and avoid placing metal objects between them
- Aim the 30 degree beam at the target area and adjust the mounting bracket for optimal reach
- Clean the polycarbonate lens with water and a soft cloth only, as solvents may damage the anti-reflective coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 12/24V DC, so the same part number can be fitted to both 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for use on public roads
The lamp is CE and RoHS compliant, but it does not carry ECE R10 or other road vehicle lighting approvals. Use is recommended for off-road or private property applications.
