7 Inch LED Driving Light F016
The SLL-F016 is a 7 inch LED driving light designed for off-road vehicles and heavy machinery that operate in low visibility conditions. It delivers a raw 8500 lumen output using Osram CROP-SH LEDs, projecting a beam that reaches 1 lux at 874 meters, so operators on trucks, excavators, or mining vehicles can see terrain and obstacles far ahead. The light is built for continuous duty under vibration and dust, with a die-cast aluminium housing and sealed electrical connections that maintain performance in harsh environments.
- Raw 8500 lumen output with a 1 lux reading at 874 meters for long-range visibility in darkness
- Osram CROP-SH LEDs provide consistent light output and long life under high thermal load
- Die-cast aluminium housing with robust heat dissipation for stable performance during extended use
- 12V/8.3A draw at 12V allows direct fitment on 12V vehicle systems without additional voltage regulation
- 96W maximum power rating supports high output without exceeding standard vehicle electrical capacity
Where This Lamp Is Used
- Front-mounted lighting on off-road trucks and 4x4 vehicles operating in remote areas without street lighting
- Primary illumination on excavators and engineering vehicles working at night in construction zones
- Navigation lighting on mining machinery where visibility beyond 500 meters is required for safety
- Auxiliary lighting on fleet vehicles used for night transport or emergency response
- Mounting on cranes and vessels where long-distance beam reach is needed for safe operation
Who It Is For
- Distributors of off-road vehicle lighting needing a high-output driving light with proven long-range performance
- Machinery OEMs integrating a reliable driving light into new machine builds with minimal design changes
- Fleet operators replacing halogen driving lights that degrade quickly and lack range
- 4x4 accessory brands developing a private label driving light with strong beam distance
- Equipment dealers fitting lighting upgrades on older machines with 12V electrical systems
Problems It Solves
- Halogen driving lights fail under vibration and have a short effective range, requiring frequent replacement
- Cheap LED lights with poor heat sinking overheat and lose lumen output within weeks of continuous use
- Unsealed electrical connections allow water ingress, leading to short circuits and premature failure
- Narrow beam lights illuminate a small area but leave terrain beyond the beam edge in darkness
- Low lumen output forces operators to rely on multiple lights, increasing wiring complexity and power draw
Technical Features
- 96W maximum power with 12V/8.3A electrical current draw at 12V DC
- Raw lumen output of 8500 lm with a 1 lux reading at 874 meters for long-distance visibility
- Osram CROP-SH LEDs with high thermal stability and consistent light output
- Die-cast aluminium housing with integrated heat sink fins for efficient thermal management
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-F016 |
|---|---|
| Size | 7 inch |
| Max Power | 96W |
| Real Power | 96W |
| LED | Osram CROP-SH |
| Raw Lumen | 8500 lm |
| 1 Lux Distance | 874 meters |
| Operating Voltage | 12V DC |
| Amp Draw | 8.3A at 12V |
| Housing Material | Die-cast aluminium |
| Lens Material | Anti-scratch PC |
| Beam Pattern | Spot |
Materials Used
- Die-cast aluminium housing with heat sink fins
- Anti-scratch UV resistant polycarbonate lens
- Silicone rubber gasket and sealed cable entry gland
- Semi-gloss black powder coating on housing
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black
LED board assembly with Osram CROP-SH emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Vibration testing on a vibration test machine to reproduce machine mounted service
- Salt spray corrosion testing on housing coating and stainless bracket
Customisation Options
- Alternative cable length to match a specific machine harness
- Private label logo on the housing and printed carton
- Spot beam optics in place of the standard beam pattern
- Mixed cartons combining this light with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Halogen driving light of similar output | Draws 8.3A at 12V against roughly double that for halogen and survives vibration that destroys a filament |
|---|---|
| Round 7 inch driving light | The square body allows more LED area behind the same mounting footprint but requires a flat surface for the bracket |
| Spot beam version of the same lamp | Flood beam covers a wider area while spot reaches further ahead but leaves the sides of the path dark |
| Smaller 5 inch driving light | Higher output and longer range but requires more space for mounting on the front bumper |
How to Fit and Use It
- Wire through a fused feed sized for 8.3A at 12V and keep the cable entry pointing downward to prevent water entry
- Aim the spot beam at the center of the road ahead and use a flood lamp separately for side visibility
- Clean the PC lens with water and a soft cloth only, since solvents will haze the anti-scratch coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on 12V vehicles
Yes. The lamp is designed for 12V DC systems and draws 8.3A at 12V, making it suitable for 12V fleets.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Get a Price on 7 Inch LED Driving Light F016
Send the quantity, the destination port and any branding requirement. You will get pricing, packing data and the production lead time.
