7 Inch 105W 8 400 LM 6000K
The SLL-7105 is a 7 inch spot beam LED driving light designed for off-road vehicles and heavy machinery that operate in low visibility conditions. It delivers 8400 effective lumens from 105W of real power using nine Osram 5W LEDs, providing a focused beam that extends visibility beyond the vehicle's standard headlights. The die-cast aluminium housing with IP68 sealing and a durable polycarbonate lens ensures reliable performance in rain, dust, and vibration. This light is suitable for front and rear mounting on bumpers, grilles, and luggage bars, and is built for long-term use in extreme temperatures.
- 8400 effective lumens from 105W real power with nine Osram 5W LEDs for extended visibility in off-road conditions
- IP68 sealing and a sealed cable entry gland prevent water and dust ingress during high-pressure washing or off-road use
- Stainless steel U bracket provides a secure, vibration-resistant mount on vehicles that experience constant movement
- Operates across 9–32V DC, compatible with 12V and 24V systems, reducing SKU complexity for fleet operators
Where This Lamp Is Used
- Front-mounted lighting on 4x4s and ATVs used for night trail riding and off-road racing
- Rear-mounted auxiliary lighting on trucks and utility vehicles for reversing in low-light conditions
- Grille or bumper mounting on excavators and engineering vehicles operating in remote construction zones
- Auxiliary lighting on mining support vehicles where long-range visibility is critical in dark tunnels
- Lighting on UTVs and off-road motorcycles used for night patrols or emergency response
Who It Is For
- Distributors of off-road vehicle lighting needing a single part number for 12V and 24V fleets
- 4x4 accessory brands building a private label driving light range with consistent performance
- Fleet operators replacing halogen driving lights that fail under vibration and high heat
- Machinery OEMs integrating a reliable driving light into production line builds for off-road equipment
- Equipment dealers fitting auxiliary lights on machines used in mining, agriculture, and construction
Problems It Solves
- Halogen driving lights burn out quickly under vibration and draw excessive current from the vehicle's electrical system
- Cheap plastic lenses crack or yellow under UV exposure, reducing light output and clarity over time
- Inadequate sealing in low-cost lights allows water to enter and cause short circuits during wash cycles
- Narrow beam lights with low effective lumens leave the road edge and obstacles in darkness beyond the headlight range
- Mild steel brackets rust within months on machines exposed to salt, mud, or frequent washing
Technical Features
- Nine Osram 5W LEDs with a real power draw of 105W and a maximum rating of 105W
- Semi-gloss black UV-resistant polyester powder coating over the full housing and bracket
- Bare wire lead of 40cm as standard with a Deutsch connector available on request
- Overvoltage and overheat protection built into the driver circuit
- Operating window of -40 to +85 degrees Celsius, suitable for extreme climates
- Double screw mounting design for secure attachment on vibrating platforms
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-7105 |
|---|---|
| Max Power | 105W |
| Real Power | 105W |
| LED | 9 pcs x 5W Osram |
| Effective Lumen | 8400 lm |
| Beam Pattern | Spot |
| Colour Temperature | 6000K |
| Operating Voltage | 9–32V DC |
| Lens Material | Anti-scratch, UV-resistant polycarbonate |
| Waterproof Rating | IP68 |
| Operating Temperature | -40 to +85 degrees Celsius |
| Electrical Connection | Bare wire 40cm, Deutsch connector available |
| Lifetime | More than 50000 hours |
| Certification | CE, RoHS |
Materials Used
- Anti-scratch, UV-resistant polycarbonate lens
- Silicone rubber gasket and sealed cable entry gland
- UV-resistant polyester powder coating
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black with UV resistance
LED board assembly with Osram emitters and driver integration
Lens bonding and gasket sealing with silicone
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating before shipment
- Vibration testing on a vibration test machine to simulate off-road service
- Salt spray corrosion testing on housing coating and stainless bracket
- High and low temperature alternating humidity testing across the -40 to +85 degrees Celsius range
Customisation Options
- Deutsch DT connector instead of the standard 40cm bare wire lead
- Spot beam optics in place of the flood pattern
- Private label logo on the housing and printed carton
- Alternative cable length for a specific machine harness
- Mixed cartons combining this lamp with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Round 7 inch driving light | The square body allows for more LED area behind the same mounting footprint but requires a flat surface for the bottom bracket |
|---|---|
| Flood beam version of the same lamp | Spot beam reaches further ahead for road visibility while flood covers a wider area but with less reach |
| Larger 8 inch driving light | Lower output but fits on narrow bumpers and grille areas where an 8 inch body would not clear |
How to Fit and Use It
- Leave a drip loop in the 40cm lead so water runs away from the gland rather than into it
- Aim the spot beam at the road ahead and use a flood lamp separately for near-field illumination
- Clean the PC lens with water and a soft cloth only, as solvents will degrade the anti-scratch coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is CE and RoHS compliant and carries IP68 sealing, which supports use on vehicles operating on public roads.
Get a Price on 7 Inch 105W 8 400 LM 6000K
Send the quantity, the destination port and any branding requirement. You will get pricing, packing data and the production lead time.
