7 Inch 45W Osram Laser LED Driving Light 9000LM 1LUX@1900M SLL-19009
The SLL-19009 is a 7 inch laser LED driving light designed for off-road vehicles and heavy machinery that operate in low visibility conditions. Eight 5W Osram CRDP-SH+LASER LEDs deliver 9000 effective lumens and achieve a 1 lux reading at 1900 meters, providing long-range illumination for safe navigation on unlit roads, construction sites, and mining operations. The die-cast aluminium housing is sealed to IP67 and supports 10-30V DC input, allowing direct fitment on both 12V and 24V fleet systems without voltage conversion. This light is built to withstand vibration, dust, and rain during extended duty cycles.
- 9000 effective lumens with a 1 lux reading at 1900 meters for long-range visibility in darkness
- IP67 sealing prevents dust and water ingress during heavy rain and off-road use
- 10-30V DC operation allows one part number to serve both 12V and 24V vehicle systems
- 8 x 5W Osram CRDP-SH+LASER LEDs provide a focused spot beam with high lumen output
- Die-cast aluminium housing resists deformation under vibration and high thermal load
Where This Lamp Is Used
- Front-mounted driving light on off-road trucks and 4x4 vehicles operating at night on unpaved roads
- Primary illumination on excavators and cranes working in low-light construction zones
- Auxiliary lighting on mining trucks and haul trucks in underground or open-pit operations
- Night-time navigation on agricultural tractors and harvesters in wide-field environments
- Fleet vehicles used in remote areas where maintenance access is limited and light reliability is critical
Who It Is For
- Distributors sourcing high-lumen LED driving lights for 12V and 24V vehicle fleets
- Machinery OEMs integrating a single driving light model across multiple vehicle platforms
- Fleet operators replacing halogen or standard LED driving lights with longer-range, durable alternatives
- 4x4 accessory brands building a private label laser driving light range with consistent performance
- Equipment dealers fitting driving lights on machines that must operate beyond daylight hours
Problems It Solves
- Halogen driving lights fail quickly under vibration and provide insufficient range for off-road use
- Standard LED lights with lower lumen output and narrow beam patterns leave the far edge of the road dark
- Inconsistent voltage tolerance forces different part numbers for 12V and 24V systems, increasing inventory
- Shorter lifetimes (under 20000 hours) require frequent replacements on machines used in remote locations
Technical Features
- Eight 5W Osram CRDP-SH+LASER LEDs with a total real power draw of 45W and 9000 effective lumens
- Spot beam pattern with a 1 lux reading at 1900 meters, ideal for long-distance visibility
- Semi-gloss black powder coating over the full housing to resist abrasion and UV degradation
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-19009 |
|---|---|
| Max Power | 45W |
| Real Power | 45W |
| LED | 8 pcs x 5W Osram CRDP-SH+LASER |
| Theoretical Lumen | 9000 lm |
| Effective Lumen | 9000 lm |
| Beam Pattern | Spot |
| 1 Lux Reading | 1900 meters |
| Colour Temperature | 6000K |
| Operating Voltage | 10-30V DC |
| Amp Draw | 3.75A at 12V |
| Housing Material | Die-cast aluminium |
| Lens Material | PC |
| Bracket Material | Aluminium alloy |
| Waterproof Rating | IP67 |
| Lifetime | More than 50000 hours |
| Certification | CE, RoHS |
Materials Used
- Anti-reflective UV-resistant polycarbonate lens
- Silicone rubber gasket and sealed cable entry for IP67 protection
- Semi-gloss black powder coating on the housing and bracket
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black
LED board assembly with Osram CRDP-SH+LASER emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP67 rating before shipment
- Vibration testing on a vibration test machine to simulate machine-mounted service
- Salt spray corrosion testing on housing coating and bracket
Customisation Options
- Spot beam optics in place of the standard beam pattern
- Private label logo on the housing and printed carton
- Alternative cable length for a specific machine harness
- Mixed cartons combining this lamp with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Halogen driving light of similar range | Draws 3.75A at 12V against roughly double that for halogen and survives vibration that destroys filament-based lights |
|---|---|
| Standard 45W LED driving light | Uses Osram CRDP-SH+LASER LEDs for higher lumen output and longer reach, with better beam focus |
| Round 7 inch driving light | The same diameter allows fitment in standard mounting brackets, but the laser LED array improves beam distance |
| Flood beam version of the same lamp | Spot beam provides long-range visibility while flood covers a wider area but sacrifices distance |
| Larger 8 inch driving light | Lower output but fits standard mounting holes and avoids interference with bumpers or guards |
How to Fit and Use It
- Wire through a fused feed sized for 3.75A at 12V and keep the cable entry pointing downward to prevent water ingress
- Aim the spot beam at the road ahead and use a separate flood lamp for near-field illumination if needed
- Clean the PC lens with water and a soft cloth only, since solvents will degrade the anti-reflective coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 10 to 30V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is CE and RoHS compliant, with an IP67 sealing rating suitable for road use in most regions.
