4 inch x 4 inch x 16 inch NaI(Tl) Scintillation Detector, Energy Resolution: ≤8.5%@662keV(Cs-137)

Specifications

1. Model Number: NAI4/4/16P3.5
2. Scintillator: 4 inch x 4 inch x 16 inch NaI(Tl) scintillator
3. PMT: 8-stage Dia. 3.5 inch PMT with 14-pin connector
4. Energy Resolution: ≤8.5%@662keV(Cs-137)
5. Operating Temperature: -30~50℃
6. High Voltage: +400~+1100V(Positive polarity configuration)
7. Stainless Steel Housing

4 inch x 4 inch x 16 inch NaI(Tl) Scintillation Detector Description

The Model NAI4/4/16P3.5 Scintillation Detector is a hermetically sealed assembly which includes a high resolution 4″x4″x16″ NaI(Tl) scintillator, a 3.5″ photomultiplier tube, an internal magnetic/light shield, an stainless steel housing and a 14-pin connector.

This kind of 14-pin NaI(Tl) detectors have good energy resolution(≤8.5%@662keV) and stability, their standard 14-pin connector can be easily inserted in plug-on photomultiplier tube(PMT) base or digital Multi-Channel Analyzer(MCA) for Gamma-ray detection systems.

For more information please visit 4"x4"x16" NaI(Tl) Scintillation Detector. If you have any further inquiries and comments, or require a quotation for different specifications and quantities, please do not hesitate to contact our sales team: [email protected].
