Diameter 3 inch x 3 inch NaI(Tl) Scintillation Detector, Energy Resolution: <7.0%@662keV(6.6% typ.)

Specifications

1. Model Number: NAI3/3P3
2. Scintillator: Dia. 3 inch x 3 inch NaI(Tl) scintillator
3. PMT: 8-stage Dia. 3 inch PMT with 14-pin connector
4. Energy Resolution: <7.0%@662keV(6.6% typ.)
5. Operating Temperature: -30~50℃
6. High Voltage: +400~+1100V(Positive polarity configuration)
7. Aluminum Housing

Diameter 3 inch x 3 inch NaI(Tl) Scintillation Detector Description

The Model NAI3/3P3 Scintillation Detector is a hermetically sealed assembly which includes a high resolution Dia. 3″x3″ NaI(Tl) scintillator, a 3″ photomultiplier tube, an internal magnetic/light shield, an aluminum housing and a 14-pin connector.

This kind of 14-pin NaI(Tl) detectors have good energy resolution(<7.5%@662keV) and stability, their standard 14-pin connector can be easily inserted in plug-on photomultiplier tube(PMT) base or digital Multi-Channel Analyzer(MCA) for Gamma-ray detection systems.

For more information please visit 3"x3" NaI(Tl) Scintillation Detector. If you have any further inquiries and comments, or require a quotation for different specifications and quantities, please do not hesitate to contact our sales team: [email protected].
