Coil Supply for Building and Architectural Products
Building products are bought on design life. The structural members have to reach a stated yield so a section can be calculated, and the visible surfaces have to still look right after a decade outdoors. Both requirements come back to what was specified on the coil.
Where It Goes Wrong
- A section is designed in mild steel and painted, which adds a step and a failure point
- Zinc coating is chosen by habit rather than by exposure, so parts either corrode early or cost too much
- Facade panels from different batches do not match once installed
- Profile stock has to be trimmed because the coil was not slit to the developed width
What the Sector Actually Needs
- Structural galvanized grades with a stated minimum yield
- Coating weight selected against the actual exposure class
- Finished aluminum coil that matches across adjacent areas
- Slit width equal to the developed width of the profile
Grades We Supply Into Building and Architectural Products
Hot Dipped GalvanizedS260GD to S550GD Structural Galvanized Steel Strip
Structural galvanized strip, zinc 30 to 350 g/m2, 0.40 to 1.0 mm, slit 5 to 1500 mm.
View Specification
Hot Dipped GalvanizedDX51D to DX56D Hot Dipped Galvanized Steel Strip
Forming grade galvanized strip, zinc 30 to 350 g/m2, 0.15 to 1.0 mm, slit 5 to 1500 mm.
View Specification
Aluminum CoilPainted Aluminum Coil
Colour coated aluminum coil, 3000 to 6000 series, 0.15 to 1.0 mm, slit 5 to 1500 mm.
View Specification
Aluminum CoilAnodized Aluminum Coil
Continuously anodized aluminum coil, 3000 to 6000 series, 0.15 to 1.0 mm, slit 5 to 1500 mm.
View SpecificationTypical Applications
- Purlins, studs and track roll formed from S350GD or S550GD
- Ducting and light framing in DX51D
- Facade cassettes and ceiling tiles in painted aluminum
- Interior trim and profiles in anodized aluminum
How We Deliver Into This Sector
- Grade chosen against the calculated section load
- Coating weight matched to the exposure class of the element
- Matching panel areas kept together in one coil run
Guides for This Sector
Material GuideZinc Coating Weight Guide for Hot Dipped Galvanized Strip
Coating weight decides both how long a part survives outdoors and how tightly it can be bent. Those two pull in opposite directions, which is the whole problem.
Read The Guide
Comparison GuidePainted or Anodized Aluminum Coil Which Finish to Specify
Both arrive finished on the coil. They fail in different ways and they cost differently, so the choice is worth making deliberately.
Read The GuideBuilding and Architectural Products Questions
Which galvanized grade should a purlin be designed in?
How do I choose the zinc coating weight?
How do I keep facade panels matching?
Material Advice for Building and Architectural Products
Tell us the part, the process and the environment. Grade selection in this sector is usually settled in one conversation.
