A dentist in Spain asked for a quotation on a system similar to the Vatech CBCT A9 with cephalostat arm. For a Spanish-market buyer, the conversation splits into two parts: raw spec equivalence, and CE mark compliance. The CE question is actually the more important one, because without it you can't install the unit in an EU clinic.
The Vatech A9 baseline
The A9 (sometimes called Green CT A9) is a hybrid ortho-endo platform:
- FOV range: 8×5 cm up to 16×9 cm (adjustable by mode)
- Voxel: 0.08-0.2 mm
- Cephalostat arm: one-shot fast-ceph, typically 8.9 seconds acquisition
- Panoramic: tomosynthesis-capable on later firmware
- Tube: 50-90 kV, 2-10 mA
- Integrated Ez3D-i planning software
Price in Spain through Vatech Iberia typically lands EUR 55,000-70,000 installed, depending on ceph arm configuration and software bundle.
Chinese 4-in-1 with cephalostat — spec comparison
Our 4-in-1 CBCT platform with cephalostat arm runs:
- FOV: 5×5 cm up to 16×17 cm (wider max than A9)
- Voxel: 0.1-0.3 mm (A9's 0.08 is genuinely better for endo)
- Cephalostat: dual-shot, typically 12-14 seconds (slower than A9's one-shot)
- Panoramic: tomosynthesis standard
- Tube: 60-90 kV, 2-10 mA
- SMARTer metal artifact reduction
- DICOM 3.0, compatible with Ez3D-i imports and standard third-party planners
The honest gap: A9's one-shot cephalostat is genuinely better for pediatric and uncooperative patients. Our dual-shot produces comparable clinical output but asks the patient to hold still for a few seconds longer. For an adult orthodontic practice that's a non-issue; for a pediatric-heavy practice, consider whether that matters.
CE mark — non-negotiable for Spain
Any CBCT installed in an EU clinic must carry a valid CE mark under MDR (Medical Device Regulation, 2017/745). For our platform, that means:
- Technical documentation compliant with Annex II of MDR
- Notified Body-issued CE certificate (not self-declaration — CBCTs are Class IIb)
- Authorised Representative in the EU registered and named on the device
- EUDAMED registration before first placement
- Declaration of Conformity available on request
We ship EU-market units with full CE documentation package. The CE number is verifiable on the issuing Notified Body's public database — always ask to verify this before signing. There are Chinese CBCT sellers whose "CE marks" are self-declaration on Class I, not genuine Class IIb certificates. The difference matters when Spanish health inspectors check.
Shipping to Barcelona or Valencia
Sea freight Shanghai → Barcelona: 32-38 days via Suez Canal. Typical LCL rate runs USD 380-520 per CBM, so a single CBCT crate (about 4.3 CBM) lands around USD 1,800-2,300 in freight alone. A 20 ft container (accommodates 2-3 CBCTs plus accessories) runs USD 2,800-4,000 total — much better per-unit economics if you're a distributor.
Spanish customs on medical imaging: TARIC 9022.12.00, 0% duty (medical exemption), 21% IVA recoverable for clinics VAT-registered as healthcare providers.
Landed cost in Spain
For our 4-in-1 with cephalostat + CE documentation + sea freight to Barcelona + Spanish installation partner:
- FOB Shanghai: EUR 22,000-26,000
- CFR Barcelona: add EUR 2,000-2,800
- Local installation + training: EUR 1,800-3,000
- Total installed: EUR 26,000-32,000
Roughly half the Vatech A9 installed price for clinically comparable output on adult cases. If your Spanish practice is primarily adult ortho and implants, this math works. If it's pediatric-heavy, factor in whether A9's one-shot ceph justifies the price gap for your specific patient mix.
Ready to price this out?
Tell us the model, quantity and destination port. We reply with FOB or CIF pricing, current stock status and a video demo where the unit is in our Shanghai warehouse.
