Wholesale COB Chip DC24V LED Strip Light
The FD-LS020LCOB is a 10W per metre DC24V LED strip light designed for commercial office linear lighting applications. It uses a COB LED chip and is supplied without a driver, allowing integration into systems where central or distributed drivers are already specified. The strip is 8mm wide and sold in 10 metre rolls, with a copper substrate for thermal management. It is rated IP20, suitable for dry indoor environments such as office ceilings and suspended cassettes.
| Model | FD-LS020LCOB |
|---|---|
| Power | 10W/m |
| Input Voltage | DC24V |
| IP Rating | IP20 |
| Dimension | W8 mm, 10 meters/roll |
| Material | Copper |
| LED Chip | COB |
| Driver | Not included |
| Warranty | 3 Years |
Key Benefits
- DC24V input allows integration into low-voltage office lighting systems with existing central drivers
- COB LED chip provides a uniform light output across the strip without visible diodes
- Copper substrate improves heat dissipation, supporting stable performance over time
- 10 metre rolls reduce installation labour and joint count in long linear runs
- No driver included, so the same fixture can be used in projects with or without on-board drivers
- IP20 rating is sufficient for dry indoor office environments where dust and moisture are not present
Application Scenarios
- Linear ceiling cassettes in commercial office buildings with suspended ceilings
- Recessed linear lighting in office corridors and meeting room ceilings
- Continuous strip lighting in open-plan office zones with minimal visible joints
- Integration into central driver systems where multiple strips are powered from one control panel
Who It Is For
- Commercial office lighting contractors installing linear strips in suspended ceiling systems
- Lighting designers specifying low-voltage linear fixtures for office projects in Europe and the Middle East
- Electrical wholesalers supplying office lighting components to project teams
- Brand owners sourcing OEM LED strip lights under their own label for office applications
Problems It Solves
- Fixed driver integration forces a choice between on-board or off-board drivers, limiting system flexibility
- Non-uniform light from discrete LEDs creates visible dot patterns in long linear runs
- Aluminium substrates may not dissipate heat as effectively as copper in continuous high-density strips
- Shorter roll lengths increase the number of joints and installation time in long runs
- Lack of DC24V compatibility prevents use in low-voltage office lighting systems already designed for 24V
Technical Features
- COB LED chip for uniform light output without visible diodes
- DC24V input with no driver included, suitable for central or distributed driver systems
- Copper substrate for improved thermal conductivity and long-term reliability
- 10 metre roll length reduces the number of joints in continuous installations
- 8mm width allows tight spacing in narrow cassettes and recessed ceiling profiles
- IP20 rating for dry indoor environments only
Materials
- Copper substrate for effective heat transfer and long-term LED stability
- COB LED package for a seamless light output across the strip
- Flexible PCB base for bending and shaping in tight ceiling cassettes
- Protective coating on the copper surface to prevent oxidation in dry indoor environments
Manufacturing Process
- Copper substrate cutting and preparation
- COB LED chip mounting and soldering to the PCB
- Soldering of electrical contacts and connection points
- Inspection of electrical continuity and thermal performance
- Rolling and packaging of 10 metre lengths with protective film
Quality Control
- Incoming inspection of COB LED chips and copper substrates
- Electrical continuity and resistance testing after assembly
- Visual inspection for solder defects and alignment issues
- Stated defective rate below 0.2%
- Final packaging with protective film to prevent damage during transit
Certification
Only the certification the factory publishes is listed here.
- CE certificate and report
- Stated conformity with CE, RoHS and FCC
Customisation Options
- Customer logo printing available, confirmed against an approved sample before production
- Supplied without driver to match the site’s central driver strategy
- Available in 10 metre rolls, no shorter lengths offered
- OEM and ODM production for buyers selling under their own brand
Compared With the Alternatives
LED strip with on-board driver
Higher cost per metre, but reduces the need for external driver integration
Aluminium substrate strip
Copper conducts heat better, improving long-term LED performance in continuous runs
Discrete LED strip
COB chip gives a uniform light without visible diodes, better for aesthetic linear lighting
Use Guide
- Install the strip in dry indoor environments only, as IP20 does not protect against moisture or dust
- Use a 24V DC power supply with sufficient current capacity for the total length installed
- Avoid sharp bends or kinks that could damage the copper substrate or solder joints
- Secure the strip with adhesive or clips designed for flexible LED strips
- Keep the strip away from high-heat sources or areas with poor ventilation
Wholesale COB Chip DC24V LED Strip Light Questions
What is the input voltage for this LED strip?
The strip operates on DC24V input, with no driver included.
Is the driver included in the strip?
No. The strip is supplied without a driver, so it can be used with central or distributed drivers.
What is the power consumption per metre?
The strip consumes 10W per metre.
Can it be used in damp or outdoor areas?
No. The IP20 rating is for dry indoor use only. Use an IP65 or higher rated strip for damp or outdoor applications.
What is the warranty period?
This product carries a 3 year warranty. Across the FENGDIAN range, warranty varies from 2 to 5 years depending on the product.
Can I order a sample before placing a bulk order?
Yes. Sample orders are accepted, mixed samples are acceptable, and samples typically ship within 3-5 days.
How long does mass production take?
Mass production is typically 1-2 weeks, and goods normally ship by DHL, UPS, FedEx or TNT with 3-5 days in transit, or by air or sea freight.
