Crinkle Paper Shredding Machine
Cuts kraft into 3 mm crinkle paper filler for gift boxes and bottle packaging
Product Overview
The EM-PS500 shreds kraft paper into crinkle paper, a light, fluffy decorative filler with distinct three dimensional strands that can be packed into any size of box. It takes sheets up to 480 mm wide from 14 gsm to 350 gsm and cuts them at 25 m per minute, normally to 3 mm wide. The finished paper is used as filler for gift boxes, glass bottles, wine packaging, electronics, ceramics and other fragile goods.
Key Benefits
- Crinkle paper is light and fluffy, so it fills a box volume at very low weight
- Strands stay distinct and three dimensional, which is what makes it a presentation material
- Wide 14 gsm to 350 gsm input range covers everything from tissue to board
- Fits any box size because the filler is packed loose rather than cut to shape
What This Machine Fixes
- Plastic shred and foam chips look cheap and are rejected by premium retail packaging
- Buying crinkle filler in bulk means paying freight on an almost weightless product
- Cut widths from a general purpose shredder are uneven and do not present well
Who Buys It
- Gift packaging producers and hamper assemblers
- Wine, spirit and specialty food packers
- Converters supplying decorative filler to retail brands
Where The Output Is Used
- Filling gift boxes and hampers where presentation matters
- Packing wine and spirit bottles in retail cartons
- Protecting ceramics and glass products against shock in transit
- Candy and confectionery packaging, where the material is widely used
How It Is Built
- Machine model EM-PS500, maximum feeding material width 480 mm
- Finished material width usually 3 mm, with 2 mm, 4 mm and 6 mm available by changing the module
- Paper thickness 14 gsm to 350 gsm, with a maximum of 8 to 10 sheets per pass at 70 g
- Working speed 25 m per minute, adjustable
- Paper sheet feeding height up to 100 mm
- 3.2 kW, 260 kg, machine size 2500 x 820 x 960 mm
Published Specification
Every figure below is the specification published for this machine. Where a value is not listed it is confirmed with the quotation rather than estimated.
| Machine model | EM-PS500 |
|---|---|
| Max. feeding material width | 480mm |
| Finished material width | Usually 3mm (if 2mm or 4mm or 6mm,need to change module) |
| Paper thickness | 14-350gsm,Max. 8-10pcs/each time if thickness 70g |
| Machine working speed | 25m/min(Adjustable) |
| Paper sheet feeding height | Max. 100mm |
| Machine power | 3.2 KW |
| Machine weight | 260 kg |
| Machine size | 2500*820*960mm (LxWxH) |
| Wooden box size | 810*900*1100mm (LxWxH) and conveyor 1600*780*565mm (LxWxH) |
| Power supply | 380V 3 Phase,50hz or as customer requirement |
Materials
- Kraft paper 14 gsm to 350 gsm
- Kraft or mixed colour paper
Customization Options
- Cutting module supplied for 2 mm, 3 mm, 4 mm or 6 mm strand width
- Kraft or mixed colour paper as the input
- Power supply built to the destination market's voltage and frequency
The Process This Machine Runs
Sheet feeding
Stage 1 of the crinkle paper shredding machine process.
Shredding to 3 mm
Stage 2 of the crinkle paper shredding machine process.
Crinkling
Stage 3 of the crinkle paper shredding machine process.
Conveyor discharge
Stage 4 of the crinkle paper shredding machine process.
Quality Control
- Strand width checked against the fitted module before each run
- Feed height kept within 100 mm so cutting stays even
- Finished filler checked for fluffiness rather than only for cut width
Use Guide
- Keep the sheet feed height within 100 mm so cutting stays even
- At 70 g paper, feed no more than 8 to 10 sheets per pass
- Change the module rather than forcing a different strand width
- Let the filler fall loose into the collection box so it stays fluffy
How It Compares With The Alternatives
Compared with Kraft Paper Shredding Machine
The same EM-PS500 platform. This listing is written around decorative crinkle filler for gift and bottle packaging, where presentation is the buying reason.
Compared with Paper bubble and honeycomb wrap
Crinkle paper fills the void around an item. Bubble and honeycomb wrap go around the item itself. Many packers use both.
Crinkle Paper Shredding Machine FAQ
What strand width does it cut?
Usually 3 mm. 2 mm, 4 mm and 6 mm are available by changing the module.
What paper thickness can it shred?
14 gsm to 350 gsm. At 70 g a maximum of 8 to 10 sheets can be fed at a time.
How fast does it run?
25 m per minute, adjustable, at a maximum feeding width of 480 mm.
What colour paper can we use?
Kraft, and mixed colour paper is also possible.
What power and weight should we plan for?
3.2 kW and 260 kg, on a 2500 x 820 x 960 mm footprint, at 380 V three phase 50 Hz or as required.
How is the machine packed for export?
In a wooden box of 810 x 900 x 1100 mm, with the conveyor packed at 1600 x 780 x 565 mm.
