ATF Exchanger · Model ATF500S
ATF500S Auto Transmission Fluid Exchanger & Cleaner
Touch screen ATF exchanger with model database
Product Overview
ATF500S adds a large touch screen and a vehicle database to the automatic ATF exchange platform. It guides the technician through the correct procedure for the model in front of them, shows new and old fluid temperature, and can reduce the transmission oil quantity automatically where the vehicle requires it. New oil heating is available as an option.
Key Benefits
What This Machine Changes in the Bay
- Large touch screen with a guided procedure for each model
- Database of standard oil quantity by vehicle model removes the manual lookup
- New and old fluid temperature display confirms the exchange is done at the right condition
- Automatic function to reduce transmission oil quantity where the procedure calls for it
- Automatic cycle cleaning and automatic filling
- New oil heating available as an option
Application Scenarios
- Transmission fluid service across a wide model range
- Workshops where several technicians share the machine
- Vehicles whose procedure specifies a fill at a defined fluid temperature
- Scheduled gearbox maintenance programmes
Who It Is For
- Transmission specialists
- General workshops running a broad model mix
- Dealership and fleet service departments
- Distributors supplying upper-range transmission equipment
Problems It Solves
What It Stops Costing You
- Standard fill quantities differ by model and are easy to get wrong from memory
- Filling at the wrong fluid temperature produces an incorrect level
- Procedures vary between technicians without on-screen guidance
- Incomplete fluid replacement leaves the original complaint in place
Technical Features
- Fully automatic identification of oil inlet and outlet direction
- Fully automated high precision equivalent exchange of new and old oil
- Regular maintenance gearbox function
- Fully automatic oil exchange guiding function for various models
- Automatic transmission cycle cleaning function
- Automatic filling function
- Automatic function to reduce transmission oil quantity
- New fluid and old fluid temperature display
- Database of latest standard oil quantity by vehicle model
- Large size touch screen with radiator hydraulic pressure gauge
- Optional new oil heating
Specifications
Compared With Other Models
- Against the ATF500: adds a large touch screen, the model database, temperature display and automatic filling
- Against the ATF-7800: a different platform in the same automatic exchange family; tell us your model mix and we will recommend one
- Against a drain and refill: a complete equivalent exchange rather than a partial change
Use Guide
- Select the vehicle on the touch screen so the correct standard oil quantity is loaded
- Connect the correct quick connector and let the machine identify flow direction
- Run cycle cleaning, then the guided exchange
- Watch the fluid temperature display and complete the fill to the vehicle procedure
Quality and Support
What Comes With the Machine
Quality Assurance
Every product is supplied with a long warranty assurance.
Expert Guidance
Pre-sales and after-sales teams give professional guidance and aftersales support.
Reliability
Consistent and reliable performance across every product line.
Innovation
An experienced R&D team develops the products the market asks for.
Customization. Machines are built to your local voltage and frequency, and optional equipment is listed on the quotation. Send us your requirement and we will confirm what can be changed before you order.
Bay Solutions Using This Machine
ATF500S Questions Buyers Ask
What does the database contain?
The latest standard oil quantity for each vehicle model, which is what the guided exchange works from.
Why does fluid temperature matter?
Many transmissions specify a level check at a defined fluid temperature, so the machine displays both new and old fluid temperature.
Is new oil heating included?
It is optional. Tell us the climate you operate in and we will advise whether it is worth adding.
Can it reduce the oil quantity automatically?
Yes, there is an automatic function to reduce the transmission oil quantity where the procedure requires it.
How does it differ from the ATF500?
The ATF500S adds the large touch screen, the model database, automatic filling and the temperature display.
Which connectors are supplied?
Connector sets are matched to the vehicle makes you service. Send us your model mix and we will list them on the quotation.
