Jib Cranes
2 Ton Jib Crane
A 2 ton jib crane with a load capacity from 250 kg to 2000 kg and a 360 degree slewing range. It is offered in wall mounted, free standing, column mounted, mast type and portable versions, so the same crane can be fitted where there is a wall, where there is only a floor, or where it has to be moved.
Product Overview
A 2 ton jib crane with a load capacity from 250 kg to 2000 kg and a 360 degree slewing range. It is offered in wall mounted, free standing, column mounted, mast type and portable versions, so the same crane can be fitted where there is a wall, where there is only a floor, or where it has to be moved. Wireless remote control is available.
Key Benefits
- Capacity from 250 kg to 2000 kg within one crane
- 360 degree slewing for a full circular working area
- Five mounting types to suit the structure available
- Wireless remote control eases repetitive loading tasks
- Portable version can follow the work rather than fixing it in place
Problems It Solves
- Manual lifting of loads in the 250 to 2000 kg range
- No overhead crane in the building and no budget for a runway
- Fixed lifting points that no longer suit the production layout
- Pendant control fatigue on repetitive cycles
Where It Is Used
Applications And Buyers
Application Scenarios
- Loading a machine tool repeatedly through the shift
- Moving components between a bench and a pallet
- Lifting at a station in a building with no suitable wall
- Temporary lifting positions that change with production
Who It Is For
- Machine shops and tool rooms
- Assembly and packing stations
- Maintenance workshops
- Small plants without an overhead crane
Technical Features And Specifications
Technical Features
- Load capacity 250 kg to 2000 kg
- 360 degree slewing range
- Wall mounted, column mounted, free standing, mast type and portable versions
- Wireless remote control method available
- Mast type needs no building structure for support
| Rated Capacity | 2 ton |
|---|---|
| Load Capacity Range | 250 kg to 2000 kg |
| Series Range | 0.25 ton to 10 ton |
| Slewing Range | 360 degrees |
| Mounting Options | Wall mounted, column mounted, free standing, mast type, portable |
| Control | Wireless remote available |
How It Is Made And Checked
Materials Process And Quality Control
Manufacturing Process
- Structural fabrication
- Welding
- Assembly
- Load testing
Quality Control
- Specification agreed in writing before production starts
- First article or sample approved against the agreed specification
- Goods inspected and photographed at the factory before loading
- Inspection report sent to you before the container sails
Customisation Options
What Can Be Varied
- Mounting type for the structure available
- Arm length to the required radius
- Hoist selection within the capacity range
- Wireless or pendant control
- Portable base where the crane must be relocated
Compared With The Alternatives
| Jib crane up to 6 ton | Same principle at lower capacity; the 2 ton crane is lighter to mount and cheaper to install where loads stay under 2000 kg. |
|---|---|
| Wall mounted versus mast type | Wall mounting saves the most floor space; the mast type needs no building structure at all and can stand anywhere on a suitable floor. |
Use Guide
- Weigh the heaviest load including any lifting tackle before selecting capacity
- Check wall or column strength for a mounted version
- Leave the full slewing circle clear
- Use the portable version only on floors rated for the wheel loads
Questions
Questions Buyers Ask About This Product
What is the load range of this crane?
250 kg to 2000 kg, within a series that covers 0.25 to 10 tons.
Which mounting types are available?
Wall mounted, column mounted, free standing, mast type and portable.
How far does the boom swing?
360 degrees.
Do I need a building structure to mount it?
Not with the mast type or free standing versions, which support themselves.
Is wireless control available?
Yes, and it is worth specifying where the same lift repeats many times a shift.
