Rental LED Screen K Series

Name: Rental LED Screen K Series
Brand: MASTARLED

Product Overview

Rental LED Screen K Series

A rental LED screen designed for touring events, stage productions, and temporary installations with front and rear service access. The cabinet uses a slim, ultra-thin aluminium diecasting structure weighing only 28kg per square metre. Standard module sizes are 500x500mm and 500x1000mm, with fast lock and handle features for tool-free alignment. The screen supports curvilinear, concave, and convex shapes, and can be hung from trusses or set on ground supports. High-definition outdoor performance with excellent heat dissipation ensures stable operation during long shows.

Rental and Staging Companies Exhibitions and Conferences

Front and rear service access allows maintenance without removing the entire screen from the rig
Ultra-thin aluminium diecasting cabinet weighs only 28kg per square metre, reducing rigging load
Fast lock and handle design enables tool-free installation and precise alignment on site
Angle adjustment option supports creative shapes like curves, concave, and convex floor screens
High-definition outdoor display performance with excellent heat dissipation for continuous operation
Truss hanging and ground support options provide flexibility for different event setups

Application Scenarios

Where This Screen Is Used

Touring concerts and music festivals requiring quick setup and teardown
Stage productions with curved or shaped LED walls for immersive visuals
Trade shows and exhibitions needing portable, high-resolution displays
Temporary outdoor events with variable screen shapes and mounting options
Corporate events and product launches with dynamic, non-rectangular screen layouts

Buyer Fit

Who It Is For

Rental and staging companies managing multiple event setups per week
AV integrators installing temporary LED walls for live events and exhibitions
Event producers needing fast, reliable screen assembly with minimal crew time
Production houses building custom-shaped LED screens for stage and broadcast
Brand marketers deploying mobile LED displays at pop-up events and product launches

Problems Solved

Problems It Solves

Rental crews spend hours aligning cabinets with tools and shimming, slowing down setup
Heavy cabinets increase rigging risk and require more crew and equipment
Lack of front access forces disassembly to replace modules during events
Standard rectangular screens cannot form curved or shaped displays without visible gaps
Poor heat dissipation causes screen failure during long, high-brightness shows

Engineering

Technical Features

Slim and ultra-thin aluminium diecasting cabinet with 28kg per square metre weight
Fast lock and handle system for tool-free, high-precision cabinet alignment
Front and rear service access for module and power supply replacement
Angle adjustment feature for curvilinear, concave, and convex screen configurations
High-definition outdoor display with professional-grade LED lamps and signal processing
Excellent heat dissipation performance due to die-cast aluminium structure and airflow design

Specifications

Rental LED Screen K Series Technical Data

Installation	Rental / Temporary
Service Access	Front and rear
Cabinet Sizes	500x500mm, 500x1000mm
Weight Per Square Metre	28kg
Cabinet Material	Aluminium diecasting
Mounting Options	Truss hanging and ground support
Locking System	Fast lock with handle
Adjustment	Angle adjustment for curved shapes
Heat Dissipation	Excellent performance via die-cast aluminium structure
Module Type	High quality black LED lamp module

Pixel pitch, resolution and refresh rate are confirmed against your viewing distance and wall size when we quote. Send those two figures and we will return the exact configuration.

Build Materials

Materials

Aluminium diecasting cabinet shell
High quality black LED lamp module
Professional-grade fast lock and handle system
Die-cast aluminium heat dissipation structure
Reinforced mounting brackets for truss and ground support

Manufacturing Process

How This Screen Is Built

SMT placement of LED lamps and driver ICs on the module PCB
Reflow soldering followed by automated soldering inspection
Auto drying and module ageing test before assembly
Cabinet assembly with fast lock and handle integration
Full screen installation test with alignment and power check
Screen ageing test on assembled wall before packing

Inspection and Testing

Quality Control

Soldering inspection on every module after reflow
Module ageing test to detect early lamp and driver failures
Screen installation test with cabinets built as a full wall
Screen ageing test on the assembled wall before dismantling for shipping

Customisation

Customisation Options

Cabinet size selected from 500x500mm or 500x1000mm to match the event layout
Angle adjustment configured for concave, convex, or curvilinear screen shapes
Mounting method chosen based on venue setup: truss hanging or ground support
Pixel pitch and resolution specified to match the viewing distance and content source

Comparison

How It Compares With the Alternatives

Standard rental cabinet with tool-based alignment	The fast lock system reduces installation time and eliminates the need for shimming or tools
Rental cabinet with rear-only service access	Front access allows module replacement during events without disassembling the wall
Rental cabinet with plastic or steel frame	The aluminium diecasting cabinet is lighter and has better heat dissipation for long shows

Specifying and Operating

Use Guide

Choose cabinet size based on the event layout and transport constraints
Confirm the truss or ground support system can carry the total weight before rigging
Use the angle adjustment feature to create smooth curves without visible gaps
Keep spare modules and power supplies on site for quick replacement during events
Request a screen ageing test at the factory and review the assembled wall in the showroom before shipment
