Ford Throttle Body CM5E-9F991-AD
This throttle body covers the Ford Focus III 1.6 petrol range and the Kuga II 2.0 TDCi, and it is the reference to quote when the customer has a Bosch number rather than a Ford one.
Overview
Ford Throttle Body CM5E-9F991-AD
This throttle body covers the Ford Focus III 1.6 petrol range and the Kuga II 2.0 TDCi, and it is the reference to quote when the customer has a Bosch number rather than a Ford one. The application list goes down to engine code and kilowatt rating, which is what separates the 77 kW Ti from the 134 kW EcoBoost on the same body shell.
Key Benefits
- Bosch reference 0280750586 cross referenced to the Ford numbers
- Applications listed by engine code, capacity and power output, not just by model name
- Covers both Focus III petrol and Kuga II diesel platforms
- Aluminium construction with the sensor specified to the application
- 1 piece minimum order
Who It Is For
- Distributors covering European engine management parts
- Workshops servicing Ford Focus and Kuga
- Exporters into markets where the Focus III is common
- Buyers matching from a Bosch reference
Problems It Solves
- A Bosch number that does not resolve in a Ford-only catalogue
- Three separate Ford references for what is the same part
- Engine code variants on one model that take different throttle bodies
- Rough idling and poor acceleration from carbon build-up or a failed sensor
Application Scenarios
- Focus III 1.6 EcoBoost drivability fault where cleaning has not cured the idle
- Kuga II 2.0 TDCi throttle actuator codes on a high mileage vehicle
- Parts counter enquiry where the customer quotes a Bosch number
- Distributor stock for the Focus III and Kuga II platforms
Engineering
Technical Features
- Bosch reference 0280750586
- Ford references CM5E9F991AD, CM5E-9F991-AD and 5152338
- Focus III applications cover the 1.6 Ti IQDB 77 kW, 1.6 Flexifuel MUDA 88 kW, 1.6 EcoBoost JTDB 134 kW and 1.6 Ti XTDA 63 kW hatchbacks
- Kuga II DM2 applications cover 2.0 TDCi UFMA 103 kW, TXMA 120 kW and UKMA 100 kW, front wheel drive and 4x4
Materials
- Aluminium body
- Throttle position sensor to original specification
At a glance
| Primary OE number | CM5E-9F991-AD |
|---|---|
| Bosch reference | 0280750586 |
| Additional Ford reference | 5152338 |
| Minimum order | 1 piece |
| Lead time, regular items | 45 days |
Values not present in the source part record are marked TBC and confirmed against your OE number before the order is placed.
Reference data
Numbers and Applications From the Source Catalogue
Everything in this section is taken from the published part record. Where a value is not in that record it is marked TBC rather than estimated.
OE and Interchange Numbers
- Bosch: 0280750586
- CM5E9F991AD
- CM5E-9F991-AD
- 5152338
Vehicle Applications (11 listed)
- FORD FOCUS III (2011/04 - /)
- FOCUS III 1.6 Ti IQDB 1596 77 105 Hatchback 11/04 - /
- FOCUS III 1.6 Flexifuel MUDA 1596 88 120 Hatchback 11/04 - /
- FOCUS III 1.6 EcoBoost JTDB 1596 134 182 Hatchback 11/04 - /
- FOCUS III 1.6 Ti XTDA 1596 63 85 Hatchback 11/08 - /
- FORD KUGA II (DM2) (2012/05 - /)
- KUGA II (DM2) 2.0 TDCi UFMA 1997 103 140 Closed Off-Road Vehicle 13/03 - /
- KUGA II (DM2) 2.0 TDCi 4x4 UFMA 1997 103 140 Closed Off-Road Vehicle 13/03 - /
- KUGA II (DM2) 2.0 TDCi 4x4 TXMA 1998 120 163 Closed Off-Road Vehicle 13/03 - /
- KUGA II (DM2) 2.0 TDCi UKMA 1997 100 136 Closed Off-Road Vehicle 13/03 - /
- KUGA II (DM2) 2.0 TDCi 4x4 UKMA 1997 100 136 Closed Off-Road Vehicle 13/03 - /
Manufacturing
How It Is Made and Checked
Casting and machining
Throttle plate and sensor assembly
Functional and electrical check
Packing
Quality Control
Plate movement and sensor output are checked before packing. The company runs to ISO 9001 and IATF 16949 quality management systems.
Customisation Options
Labelling and carton marking follow your scheme. Related Ford references can be developed in 30 to 45 days.
Comparison
The value of this reference against a generic Focus throttle body is the application table. Four Focus III 1.6 variants and five Kuga II 2.0 TDCi variants are listed by engine code and power, so a counter can confirm the fit from the V5 or the engine plate instead of guessing from the model year.
Use Guide
Step 1
Match the engine code from the vehicle plate against the application list
Step 2
Fit with a new gasket and torque the flange bolts evenly
Step 3
Connect the sensor plug and confirm it latches
Step 4
Run the throttle relearn procedure
Step 5
Clear codes and road test
Component reference
How a Ford Throttle Body CM5E-9F991-AD Works
Part Number:
Bosch: 0280750586 FORD: CM5E9F991AD CM5E-9F991-AD 5152338 Throttle Body used on:
FORD FOCUS III (2011/04 - /) FOCUS III 1.6 Ti IQDB 1596 77 105 Hatchback 11/04 - / FOCUS III 1.6 Flexifuel MUDA 1596 88 120 Hatchback 11/04 - / FOCUS III 1.6 EcoBoost JTDB 1596 134 182 Hatchback 11/04 - / FOCUS III 1.6 Ti XTDA 1596 63 85 Hatchback 11/08 - / FORD KUGA II (DM2) (2012/05 - /) KUGA II (DM2) 2.0 TDCi UFMA 1997 103 140 Closed Off-Road Vehicle 13/03 - / KUGA II (DM2) 2.0 TDCi 4x4 UFMA 1997 103 140 Closed Off-Road Vehicle 13/03 - / KUGA II (DM2) 2.0 TDCi 4x4 TXMA 1998 120 163 Closed Off-Road Vehicle 13/03 - / KUGA II (DM2) 2.0 TDCi UKMA 1997 100 136 Closed Off-Road Vehicle 13/03 - / KUGA II (DM2) 2.0 TDCi 4x4 UKMA 1997 100 136 Closed Off-Road Vehicle 13/03 - /
Related products
Often Ordered Together
Throttle Body
The throttle body controls how much air reaches the engine, and on modern vehicles it does so electronically, in…
Nissan Throttle Body 16119-AE013
This is the throttle body for the Nissan 2.5 litre QR25DE family, covering Altima, Sentra and X-Trail between 2001…
Power Steering Pump Pulley
This is the power steering pump pulley range, cross referenced against 42 Dorman part numbers covering Ford, GM and…
FAQ
Ford Throttle Body CM5E-9F991-AD FAQ
I only have a Bosch number, can you match it?
Yes. Bosch 0280750586 is listed on this page against the Ford references CM5E9F991AD, CM5E-9F991-AD and 5152338.
Does this fit the Kuga II 4x4?
Yes, the listed applications include Kuga II DM2 2.0 TDCi 4x4 in UFMA, TXMA and UKMA engine codes.
Does it cover the 1.6 EcoBoost?
Yes, Focus III 1.6 EcoBoost JTDB 1596cc 134 kW hatchback is on the application list.
What is the minimum order?
One piece.
How long is the lead time?
45 days for regular items.
Do I need to reset the vehicle after fitting?
Yes, carry out the throttle relearn or idle adaptation the vehicle requires.
