Standard Profile
U40B · 40 kN
A 40 kN standard profile disc with 110 mm spacing, 175 mm diameter and 190 mm creepage, weighing 1.8 kg. The lightest unit in our…
Creepage 190 mm
Ø 175 mm
Coupling 11
Service
Pre-Sales Technical Consultation
Selection starts from your line conditions, not from our catalogue.
What It Covers
How This Works On A Real Order
We recommend product selection based on voltage level, mechanical load, environmental conditions including pollution, ice and altitude, and the project standards you have to meet. That includes string configuration design, simulation analysis and customised insulation solutions, with compliance support for IEC, GB, ANSI, BS, DIN and AS.
- Product selection by voltage level mechanical load and environment
- String configuration design and simulation analysis
- Customised insulation solutions for specific route sections
- Compliance support for IEC GB ANSI BS DIN and AS standards
Products In Scope
Models This Service Is Most Often Applied To
Standard Profile
U70BS · 70 kN
A 70 kN standard profile disc with 127 mm spacing, 255 mm diameter and 320 mm creepage, weighing 3.6 kg. The volume workhorse for…
Creepage 320 mm
Ø 255 mm
Coupling 16
Full Service Set
The Rest Of The Project Cycle
Six services covering pre-sales consultation through to lifetime technical support.
Customized Design And Manufacturing
When the standard disc does not fit the site, we develop one that does.
Production And Quality Assurance
Defective shells are removed in our furnace, not on your tower.
Logistics And Global Delivery
Export packing and documentation handled as part of the order, not as an afterthought.
On-Site And After-Sales Service
Support continues after the crates are opened.
R&D And Project Support
Joint development for projects that need something the market does not stock.
Answers
Pre-Sales Technical Consultation Questions
How does pre-sales technical consultation work in practice?
We recommend product selection based on voltage level, mechanical load, environmental conditions including pollution, ice and altitude, and the project standards you have to meet. That includes string configuration design, simulation analysis and customised insulation solutions, with compliance support for IEC, GB, ANSI, BS, DIN and AS.
Do you support OEM and ODM requirements?
Yes. We support customised creepage distance, special fittings and connection structures, colour, packaging and marking customization, and project-specific design.
What lead time should we plan for?
Normally 15 to 35 days after order confirmation and deposit, depending on quantity and production schedule. We support bulk orders, emergency orders and long-term framework supply.
Bring Us In Early
The cheapest time to fix an insulator specification is before the tender closes. Send the line data and we will review it with you.
