Standard Profile
U70BS · 70 kN
A 70 kN standard profile disc with 127 mm spacing, 255 mm diameter and 320 mm creepage, weighing 3.6 kg. The volume workhorse for…
Creepage 320 mm
Ø 255 mm
Coupling 16
Service
Customized Design And Manufacturing
When the standard disc does not fit the site, we develop one that does.
What It Covers
How This Works On A Real Order
We develop tailor-made glass insulators for special projects, including anti-fog, anti-pollution, aerodynamic and heavy-duty types, under OEM and ODM arrangements with quality control from raw material through finished product. Every development goes through full performance testing covering mechanical strength, electrical insulation, temperature resistance and ageing resistance.
- Tailor-made anti-fog anti-pollution aerodynamic and heavy-duty designs
- OEM and ODM with control from raw material to finished product
- Customised creepage distance special fittings and connection structures
- Full mechanical electrical thermal and ageing performance testing
Products In Scope
Models This Service Is Most Often Applied To
Anti-Fog Profile
U70BLP · 70 kN
A 70 kN anti-fog disc with 146 mm spacing, 280 mm diameter and 450 mm creepage, weighing 5.3 kg. Deep under-ribs hold a dry band…
Creepage 450 mm
Ø 280 mm
Coupling 16
Full Service Set
The Rest Of The Project Cycle
Six services covering pre-sales consultation through to lifetime technical support.
Pre-Sales Technical Consultation
Selection starts from your line conditions, not from our catalogue.
Production And Quality Assurance
Defective shells are removed in our furnace, not on your tower.
Logistics And Global Delivery
Export packing and documentation handled as part of the order, not as an afterthought.
On-Site And After-Sales Service
Support continues after the crates are opened.
R&D And Project Support
Joint development for projects that need something the market does not stock.
Answers
Customized Design And Manufacturing Questions
How does customized design and manufacturing work in practice?
We develop tailor-made glass insulators for special projects, including anti-fog, anti-pollution, aerodynamic and heavy-duty types, under OEM and ODM arrangements with quality control from raw material through finished product. Every development goes through full performance testing covering mechanical strength, electrical insulation, temperature resistance and ageing resistance.
Do you support OEM and ODM requirements?
Yes. We support customised creepage distance, special fittings and connection structures, colour, packaging and marking customization, and project-specific design.
What lead time should we plan for?
Normally 15 to 35 days after order confirmation and deposit, depending on quantity and production schedule. We support bulk orders, emergency orders and long-term framework supply.
Bring Us In Early
The cheapest time to fix an insulator specification is before the tender closes. Send the line data and we will review it with you.
