Temperature Resistent 3D Printing Filament Manufacturer in China
Glass transition temperature of 85 degrees keeps the part stable in summer heat
View product
3D Printing Filament
3D Printing Filament PETG Pro Good Quality Best Price
Model TR-YL
Translucent yellow, and the roll that makes the cost case easiest to check. At 340 meters and 1.0 kg net per roll with a minimum order of one roll, a workshop can price a job accurately per letter instead of estimating against a bulk purchase it has not made yet.
- Minimum order of one roll so a new colour can be trialled without committing stock
- 340 meters per 1.0 kg roll gives a clear basis for costing per letter
- Yellow reads bright at night without needing extra LED output
- Grade of printing difficulty rated easy with no jamming which protects yield
Product Overview
Translucent yellow, and the roll that makes the cost case easiest to check. At 340 meters and 1.0 kg net per roll with a minimum order of one roll, a workshop can price a job accurately per letter instead of estimating against a bulk purchase it has not made yet.
Who It Is For
- Workshops costing jobs per letter rather than per project
- Sign makers trialling a colour before stocking it
- Advertising companies serving food and convenience retail
Problems It Solves
- Bulk minimums force a workshop to stock colours it rarely uses
- Jamming mid print wastes both the material used and the machine hours
- Guessing material cost per letter erodes margin on fixed price quotes
Key Benefits
- Minimum order of one roll so a new colour can be trialled without committing stock
- 340 meters per 1.0 kg roll gives a clear basis for costing per letter
- Yellow reads bright at night without needing extra LED output
- Grade of printing difficulty rated easy with no jamming which protects yield
- Same industrial PETG-S specification as every other colour in the range
Technical Features
- Filament type PETG-S at 1.75 MM diameter
- 340 meters per roll at 1.0 KG net and 1.3 KG gross
- Recommended printing temperature 230 to 250 degrees and bed 40 to 60 degrees
- Printing speed 40 to 120 MM per second in FDM mode
- Glass transition temperature 85 degrees with a working range of minus 40 to 70 degrees
- Tensile strength 50 MPa and bending strength 68 MPa
- Density 1.25 G per CM3 and moisture absorption 0.12 percent
- Outdoor durability 5 to 10 years
- Translucent yellow colour
- Grade of printing difficulty rated easy with no jamming
- Spool size 200 x 200 x 60 MM
Application Scenarios
- Fast food and convenience retail signage
- High visibility warning and wayfinding elements
- Yellow accent letters in a multi colour sign
- Trial orders before a colour is adopted into standard stock
- Cost sensitive jobs where material per letter has to be calculated exactly
Customisation Options
- Custom colour matched to your reference from a minimum of 100 rolls
- Spool and carton labelling on request
Product Gallery
Specifications
| Product Model | TR-YL |
|---|---|
| Filament Type | PETG-S |
| Brand Name | IROGA 3D |
| Color | Translucent Yellow |
| Length | 340 Meters/Roll |
| Diameter | 1.75 MM |
| Net Weight | 1.0 KG |
| Gross Weight | 1.3 KG |
| Application | 3D Logo Printers / 3D Model Printers |
Materials
- PETG-S signage grade copolyester
Manufacturing and Quality Control
Process
- Material selection
- Compounding and pelletizing
- Filament extrusion
- Filament spooling
- Quality control
- Vacuum bagging and carton packing
Quality Control
- Diameter monitored during extrusion so feeding stays consistent
- Colour checked against the reference sample for each batch
- Each roll vacuum bagged then packed 12 rolls per export carton
Comparison With Other Options
Compared with Translucent orange
Orange is warmer and deeper. Yellow reads brighter at night and carries further in daylight.
Compared with Buying in bulk from a general filament supplier
General filament is not specified for signage service life. This is an industrial PETG-S rated 5 to 10 years outdoors.
Use Guide
- Order a single roll first to check the colour under your own LED strip
- Calculate letters per roll from the 340 meter length before quoting
- Print at 230 to 250 degrees with the bed at 40 to 60 degrees
- Store part used rolls in the vacuum bag between jobs
Questions
Frequently Asked Questions
Answers to what buyers ask before ordering 3D Printing Filament PETG Pro Good Quality Best Price.
Can I order just one roll to try it
Yes, the minimum order quantity is 1 roll for stocked colours.
How many letters will one roll print
That depends on letter size and wall thickness. One roll holds 340 meters at 1.0 KG net, which is the figure to calculate from.
Is it easy to print
The grade of printing difficulty is rated easy with no jamming.
Is the quality the same as the other colours
Yes, every colour is the same industrial PETG-S specification.
What is the minimum order quantity
1 roll for stocked colours. A customised colour has a minimum of 100 rolls.
How is the filament packed for export
Each roll goes into a vacuum bag and 12 rolls are packed per standard export carton, at 440 x 440 x 220 MM.
What warranty applies
One year quality warranty on all products with lifetime technical support.
