HTB2L-80 ELCB
For panel builders and installers, it replaces a conventional MCB or RCCB with a single device that adds reliable earth...
Product Overview
What This Model Does
For panel builders and installers, it replaces a conventional MCB or RCCB with a single device that adds reliable earth leakage detection and automatic disconnection, reducing the number of components in a distribution board and simplifying wiring.
Key Benefits
- Protects against electric shock and fire risks from earth leakage currents in three-phase systems
- Combines overcurrent and earth leakage protection in one DIN rail device
- Reduces panel space and wiring complexity by replacing separate MCB and RCCB units
- Operates independently of the power supply, so protection remains active during outages
Who It Is For
- Panel builders integrating protection into distribution boards for industrial or commercial projects
- Electrical wholesalers stocking ELCB devices alongside conventional MCBs and RCCBs
- Solar EPC contractors installing three-phase inverters with required earth leakage protection
- Switchgear assemblers building custom control cabinets with compact protection solutions
- OEM/ODM buyers sourcing a compliant ELCB for integration into their own electrical systems
Problems It Solves
- A separate MCB and RCCB are required for overcurrent and earth leakage protection, increasing panel space and wiring
- Earth faults go undetected in three-phase systems due to lack of dedicated ELCB protection
- Panel builders must manage multiple device types and mounting configurations for protection
- Safety compliance is harder to achieve when protection functions are split across devices
- Faults in three-phase circuits can persist and cause fire or injury without automatic disconnection
Application Scenarios
- Industrial control panels where three-phase motors need both overcurrent and earth leakage protection
- Commercial buildings with three-phase power feeding HVAC systems, pumps, or lighting circuits
- Solar PV systems with three-phase inverters requiring earth fault detection for safety compliance
- Manufacturing equipment where ground faults could cause injury or damage without immediate disconnection
- Data centres and server rooms where a single earth fault could lead to equipment failure or fire
Technical Features
How It Is Built
- Manual operation and a visible trip indicator for on-site verification
Materials and Construction
- Silver-alloy contacts with a thermal-magnetic trip mechanism
- Integrated residual current sensing coil and mechanical trip linkage
Quality Control
- Supplied to the ratings published for this model
Specifications
Stated Ratings for This Model
| Rated Current | 80A |
|---|---|
| Pollution Level | 2 |
Ratings are as published for this model. Where a value is not published we mark it TBC rather than estimating it.
Values that could not be confirmed against the published catalogue text for this model are marked TBC and confirmed by email before order: Standards Compliant, Rated Voltage, Frequency, Rack Rated Current, Rated Residual Operating Current, Rated Short-circuit Breaking Capacity, Rated Impulse Withstand Voltage, Protection Level, Specified Use Temperature, Mechanical Life, Electrical Life.
Manufacturing Process
- Moulding and machining of the breaker housing and internal carriers
- Assembly of the thermal-magnetic trip unit and contact system
- Installation of the residual current sensing coil and trip linkage
- Routine dielectric and operation testing before packing
Customization Options
- Rated current selected from 80A per order
- ODM branding on housing print and packaging
- Packaging and carton marking to the buyer's own specification
Comparison
How It Compares
| Conventional MCB plus separate RCCB | One device instead of two, reducing panel space and wiring complexity |
|---|---|
| Single-pole ELCB in a three-phase system | Four-pole version ensures all phases are protected simultaneously |
| Zigbee or WiFi smart ELCB | No network dependency; protection works offline, but remote monitoring is not available |
| RCBO with overcurrent and residual protection | Same protection function but with a higher rated current and different trip characteristics |
Use Guide
- Switch on manually and confirm the device holds under normal load before testing
- Test the residual current function using a test button or external tester
- Verify the trip indicator is visible when the device has operated
- Keep the manual handle accessible so the circuit can always be isolated on site
- Replace the device if it trips repeatedly without a clear fault condition
