Glass Insulators
The full Huasheng range of cap and pin toughened glass suspension insulators for overhead lines and substations, from U40B to U500B.
4 Products In This Family
Every unit Huasheng makes belongs to this family. A pressed and thermally toughened glass shell, a galvanised malleable iron cap, a forged steel pin, cemented together and proof loaded. What changes between products is the shed profile and the strength class, and those two choices are what a line designer actually makes.
Standard Type LXP40 To LXP1-160
U40B, U70BS, U70BL, U100BL, U120B, U160BS
View Specifications
Standard Type LXP-160 To LXP-550
U160BL, U210B, U240B, U300B, U420B, U500B
View Specifications
Fog Type LXWP1-70 To LXWP2-120
U70BLP1, U70BLP2, U100BLP1, U120BP1, U120BP2
View Specifications
Aerodynamic Type LAXP-70 To LAXP-160
U70BP, U100BP, U120BP, U160BP
View SpecificationsProblems This Family Solves
- Line crews cannot identify a punctured unit on a porcelain string without survey equipment
- Pollution flashover risk rises every year as industrial and coastal deposits build on the shed
- Specifications arrive written in GB designations one month and IEC the next
- Strings sized on failing load alone leave no defined routine test margin
Who Specifies It
- Transmission utilities maintaining lines from 35 kV up to 500 kV AC
- EPC contractors procuring insulator strings for new line and substation packages
- Line hardware distributors who need one glass supplier behind a full fittings catalogue
- Brand owners requiring private label marking on standard designs
Core Advantages
- Self-identifying failure mode, the shell shatters and the stub stays visible from ground level
- Toughened glass does not age electrically the way a porcelain dielectric or a polymer housing does
- Strength classes from 40 kN to 550 kN mechanical failing load from one plant
- GB, ANSI, BS, DIN, AS and IEC designs produced on the same line
Where It Is Used
- Suspension strings on tangent towers
- Tension and dead end sets on angle and terminal towers
- Substation strain and bus support assemblies
- Replacement and refurbishment of ageing porcelain strings
Industries That Use This Family
Overhead Transmission Lines
Suspension and tension strings for tangent, angle and dead end towers on systems up to 500 kV AC and 400 kV DC.
See The Application
Substations
Strain and support assemblies for substation gantries and bus work, in clean and polluted air.
See The Application
Coastal And Polluted Air
Anti-pollution insulation for salt fog coastlines, industrial corridors and chemical plant supply lines.
See The Application
Desert And Sandstorm Regions
Open profile insulation for dry pollution, wind-carried sand and long intervals between rain events.
See The ApplicationGlass Insulators Questions
What is the difference between the three shed profiles you make?
Standard type has a ribbed underside and is the default for clean and lightly polluted air. Fog type keeps the same 146 mm spacing but extends creepage to 400 mm or 450 mm for salt fog and industrial pollution. Aerodynamic type removes the ribs and widens the shed to 380 mm or 420 mm so wind carries deposits off the surface, which suits desert and sandstorm regions.
Which standards do you build to?
GB, ANSI, BS, DIN, AS and IEC standard designs, for power transmission lines and substations. Tell us the designation in your specification and the units are produced and marked against that class.
What system voltages do your insulators cover?
Huasheng specialises in insulator manufacture for systems up to 500 kV AC and 400 kV DC.
Can you supply units marked with our own brand?
Yes. We provide OEM service and private label your brand, and products can be customised. This is a standard arrangement for distributors carrying their own line fittings catalogue.
Other Product Families
Standard Type Insulator
Ribbed profile cap and pin units covering U40B through U500B, the default choice for clean and lightly polluted line environments.
Explore The Family
Fog Type Insulator
Anti-pollution bell profile units giving 400 mm or 450 mm creepage on the same 146 mm spacing as a standard unit.
Explore The Family
Aerodynamic Type Insulator
Open flat profile units 380 mm to 420 mm wide with no underribs, so wind and rain clear deposits instead of trapping them.
Explore The FamilyTell Us The Site Conditions And The Load Case
Pollution type and severity set the profile. Conductor, span and angle set the strength class. Send both and we will point at the column in the table.
