Automotive Wiring Harness

LS Standalone Harness With Drive By Wire Pedal Circuits

A standalone LS harness that includes the drive by wire pedal circuits, for swaps where the throttle is electronic rather than cable operated. The pedal and throttle body wiring is the part most swap looms leave out.

  • Drive by wire pedal and throttle body circuits included in the build
  • Standalone layout runs the engine outside the donor vehicle
  • Fewer circuits than a body loom, so the install stays traceable
  • Suits truck and performance chassis swap builds
Request A Quote Email This Specification

Samples ship within 3 days of confirmation. Bulk lead time is typically 7 to 12 days.

Problems It Solves

  • Cable throttle looms will not run a drive by wire engine
  • Pedal circuits are commonly missing from generic swap harnesses
  • Unlabelled swap wiring is impossible to diagnose later

Who It Is For

  • Engine swap specialists
  • Performance workshops
  • Builders converting from cable to electronic throttle

Application Scenarios

  • Drive by wire LS swaps into older chassis
  • Truck and performance engine conversions
  • Engine stands running electronic throttle

Technical Features

  • Standalone engine harness
  • Drive by wire pedal and throttle circuits
  • Transmission control wiring included
  • Labelled circuit map

Specifications

ApplicationLS engine standalone swap with drive by wire
ThrottleDrive by wire pedal circuits
Transmission4L60E control wiring

Values shown are the standard build. Connector family, conductor gauge, circuit count and finished length are all build options.

Quality Control And Certification

  • Continuity And Circuit Verification. Verifies the physical arrangement sequence of the harness terminals and the circuit topology between them
  • Circuit Configuration Verification. Confirms that a complete, uninterrupted current flow path exists within each circuit
  • Terminal Retention Strength Test. Measures the mechanical reliability of the connection between the terminal and the wire
  • Ingress Protection Rating Test. Evaluates the dust and water resistance sealing performance of harness connectors

The company is certified to IATF 16949 and UL standards. Samples are confirmed prior to trial or mass production, and the approved sample is the reference for every repeat order.

Customization Options

  • Connector family and terminal type to your part numbers
  • Conductor gauge selected from the current per circuit
  • Finished length and breakout positions to your drawing
  • Jacket colour, marking and labelling to your scheme
  • Packing to your instruction, PE bag and carton as standard

Compared With The Alternatives

Cable throttle harnesses

Electronic throttle engines need the pedal and throttle body circuits this build includes

Donor vehicle looms

A standalone harness removes body circuits that the swap will never use

Use Guide

  • Mount the pedal assembly before final routing so the lead length is confirmed
  • Keep throttle circuits away from ignition leads to limit interference
  • Verify pedal position readings with a scan tool before first drive
