21 Pin SCART RGB Audio Visual Wire Harness

A 21 pin SCART harness carrying RGB video and audio, used on European televisions and game consoles including PlayStation hardware. RGB over SCART still gives the cleanest analogue picture on that generation of equipment, which is why the cable stays in demand.

Full 21 pin wiring keeps RGB video available rather than composite only
Single connector carries video and audio to the television
Moulded SCART hood holds the heavy connector without stressing the cable
Built to the European AV standard for consoles and displays

Samples ship within 3 days of confirmation. Bulk lead time is typically 7 to 12 days.

Problems It Solves

Composite-only SCART cables lose picture sharpness on RGB capable hardware
Heavy SCART hoods pull out of sockets when unsupported
Mixed pin wiring across suppliers gives inconsistent results

Who It Is For

Retro gaming accessory brands
AV accessory distributors in SCART markets
Equipment refurbishers

Application Scenarios

Game consoles connected to European televisions
Legacy AV equipment in retail and rental
Display installations using RGB SCART inputs

Technical Features

21 pin SCART connector
RGB video wiring
Audio channels included
Moulded hood

Specifications

Connector	21 pin SCART
Signal	RGB audio visual
Application	TV and game console
Product Certificates	CE, RoHS

Values shown are the standard build. Connector family, conductor gauge, circuit count and finished length are all build options.

Quality Control And Certification

Continuity And Circuit Verification. Verifies the physical arrangement sequence of the harness terminals and the circuit topology between them
Circuit Configuration Verification. Confirms that a complete, uninterrupted current flow path exists within each circuit
Terminal Retention Strength Test. Measures the mechanical reliability of the connection between the terminal and the wire
Ingress Protection Rating Test. Evaluates the dust and water resistance sealing performance of harness connectors

The company is certified to IATF 16949 and UL standards. Samples are confirmed prior to trial or mass production, and the approved sample is the reference for every repeat order.

Customization Options

Connector family and terminal type to your part numbers
Conductor gauge selected from the current per circuit
Finished length and breakout positions to your drawing
Jacket colour, marking and labelling to your scheme
Packing to your instruction, PE bag and carton as standard

Compared With The Alternatives

Composite AV cables

RGB SCART carries separated colour signals for a sharper picture

HDMI converters

A direct SCART lead needs no power and adds no processing delay

Use Guide

Support the connector at the television so its weight is not on the socket
Select the RGB input mode on the display after connecting
Do not force the connector, the SCART body is keyed one way only

Other Assemblies In Home Appliance Wiring Harness

SCART To 3.5mm AV Cable For Game Consoles - Garfour view 1

Home Appliance Wiring Harness SCART To 3.5mm AV Cable For Game Consoles21 pin SCART to 3.5mm audio visual lead for console and TV hook-up View Specifications

56 Pin PCB Harness Wire Loom For Arcade Machines - Garfour view 1

Home Appliance Wiring Harness 56 Pin PCB Harness Wire Loom For Arcade MachinesJAMMA style 56 pin loom for arcade cabinets and game console boards View Specifications

5.5mm x 2.1mm DC Power Extension Cable 12V - Garfour view 1

Home Appliance Wiring Harness 5.5mm x 2.1mm DC Power Extension Cable 12VMoulded 12V DC barrel jack and plug extension harness View Specifications

3 RCA To DB25 Amplifier Wire Harness - Garfour view 1

Home Appliance Wiring Harness 3 RCA To DB25 Amplifier Wire HarnessBulk-length audio and video harness linking 3 RCA to a DB25 amplifier interface View Specifications

21 Pin SCART RGB Audio Visual Wire Harness FAQ

Is RGB wired or is this composite only?

This build is wired for RGB audio visual use. Confirm your console output mode supports RGB.

What length is standard?

Length is built to order. Send the run length and quantity with your enquiry.

Do you charge for samples of 21 Pin SCART RGB Audio Visual Wire Harness?

Samples are charged for the sample and the shipping. The cost and the timing are confirmed with your quotation before anything is built.

Is a sample confirmed before mass production of 21 Pin SCART RGB Audio Visual Wire Harness?

Yes. Samples are confirmed prior to trial or mass production on every custom build, so the first production shipment is not the first time you see the part.

Can 21 Pin SCART RGB Audio Visual Wire Harness be built to our own drawing?

Yes. We are open to OEM projects whenever you can provide a drawing or a physical sample, and the approved sample becomes the reference for repeat orders.

Get A Price On 21 Pin SCART RGB Audio Visual Wire Harness

Tell us the quantity, the finished length and any change to the connector set. We come back with the price, the lead time and a sample plan.
