3 RCA To DB25 Amplifier Wire Harness - Garfour view 2

3 RCA To DB25 Amplifier Wire Harness - Garfour view 3

3 RCA To DB25 Amplifier Wire Harness - Garfour view 4

3 RCA To DB25 Amplifier Wire Harness - Garfour view 5

Home Appliance Wiring Harness

3 RCA To DB25 Amplifier Wire Harness

An audio and video harness that breaks a DB25 amplifier interface out to three RCA connectors, supplied in bulk lengths. It is used where a rack amplifier terminates on a D-Sub and the source equipment is on standard RCA.

DB25 to 3 RCA breakout removes a stack of separate adapter leads
Bulk 100M supply lets installers cut to the run length on site
Consistent factory termination on the D-Sub end where field soldering fails
1000mm breakout legs give slack for rack dressing

Samples ship within 3 days of confirmation. Bulk lead time is typically 7 to 12 days.

Problems It Solves

Adapter chains between D-Sub and RCA introduce noise and failure points
Field soldering 25 pin hoods is slow and inconsistent
Fixed-length leads either strain or leave loops in the rack

Who It Is For

Audio installers and integrators
Aftermarket car audio builders
AV equipment assemblers

Application Scenarios

Rack audio installs with D-Sub amplifier interfaces
Vehicle amplifier wiring on aftermarket audio builds
Audio visual distribution racks

Technical Features

DB25 male or female interface
Three RCA connectors
1000mm breakout legs
Bulk 100M supply

Specifications

Connector	3 RCA to DB25
Breakout Length	1000mm
Bulk Supply	100M
Application	Audio and video

Values shown are the standard build. Connector family, conductor gauge, circuit count and finished length are all build options.

Quality Control And Certification

Continuity And Circuit Verification. Verifies the physical arrangement sequence of the harness terminals and the circuit topology between them
Circuit Configuration Verification. Confirms that a complete, uninterrupted current flow path exists within each circuit
Terminal Retention Strength Test. Measures the mechanical reliability of the connection between the terminal and the wire
Ingress Protection Rating Test. Evaluates the dust and water resistance sealing performance of harness connectors

The company is certified to IATF 16949 and UL standards. Samples are confirmed prior to trial or mass production, and the approved sample is the reference for every repeat order.

Customization Options

Connector family and terminal type to your part numbers
Conductor gauge selected from the current per circuit
Finished length and breakout positions to your drawing
Jacket colour, marking and labelling to your scheme
Packing to your instruction, PE bag and carton as standard

Compared With The Alternatives

Individual RCA adapter leads

A single breakout keeps channel order fixed and reduces connector count

Field-soldered D-Sub hoods

Factory termination is crimped and tested to the same map every time

Use Guide

Mark the channel order at both ends before dressing the loom into the rack
Keep audio runs away from mains and motor cabling
Support the D-Sub hood so the cable weight is not carried on the solder cups

Other Assemblies In Home Appliance Wiring Harness

DC Buzzer Wire Harness For Alarm And Security Devices - Garfour view 1

Home Appliance Wiring Harness DC Buzzer Wire Harness For Alarm And Security DevicesHigh decibel acoustic sounder harness for EV, home security and telecom devices View Specifications

3 RCA To RCA Stereo Audio Video Cable - Garfour view 1

Home Appliance Wiring Harness 3 RCA To RCA Stereo Audio Video CableStandard 3 RCA composite audio and video cable for multimedia equipment View Specifications

DB25 Male To Female Multifunction D-Sub Cable - Garfour view 1

Home Appliance Wiring Harness DB25 Male To Female Multifunction D-Sub CableMoulded DB25 extension and interface cable for audio video and control equipment View Specifications

3.5mm To 2 RCA Stereo Audio Cable - Garfour view 1

Home Appliance Wiring Harness 3.5mm To 2 RCA Stereo Audio Cable3.5mm jack to stereo RCA cable for TV and multimedia audio View Specifications

3 RCA To DB25 Amplifier Wire Harness FAQ

Can you supply cut lengths instead of 100M?

Yes. Tell us the finished length and quantity and we cut and terminate to order.

Which RCA colours do you use?

Standard colour coding is supplied by default and custom colours are available on request.

Can you mark or label the circuits on 3 RCA To DB25 Amplifier Wire Harness?

Yes. Send your labelling scheme with the order and both ends are marked to it, which makes commissioning and later service much faster.

What lead time should we plan for on 3 RCA To DB25 Amplifier Wire Harness?

Sample orders ship within 3 days of confirmation. Production lead time for bulk orders is typically 7 to 12 days, and we confirm the date against your quantity when we quote.

How is 3 RCA To DB25 Amplifier Wire Harness packed for export?

Products are typically individually packed in PE bags and then boxed according to the specified quantity. Tell us any special packing requirement when you place the order.

Get A Price On 3 RCA To DB25 Amplifier Wire Harness

Tell us the quantity, the finished length and any change to the connector set. We come back with the price, the lead time and a sample plan.
