D Type End Anchor Shackle
The D type end anchor shackle connects the swivel to the anchor chain, in nominal diameters from 12.5mm to 162mm. It is supplied in grades 2 and 3 and mooring grades R3, R4 and R5, in alloy, carbon or stainless steel, with black…
What This Product Is For
The D type end anchor shackle connects the swivel to the anchor chain, in nominal diameters from 12.5mm to 162mm. It is supplied in grades 2 and 3 and mooring grades R3, R4 and R5, in alloy, carbon or stainless steel, with black painting, hot dip galvanized or electro-galvanized finish and certification from DNV, GL, BV, LRS, ABS, IRS, RS, KR, NK and CCS.
Key Benefits
- Covers 12.5mm to 162mm nominal diameter, from small craft chain to heavy mooring systems
- Grade 2 and 3 plus R3, R4 and R5 mooring grades for offshore specifications
- Certification from ten classification societies for survey acceptance
- Three surface finishes to suit permanent immersion or deck storage
Problems It Solves
- Fittings rejected at survey because the classification certificate is missing
- Chain grade and shackle grade mismatched on a mooring line
- Finish not matched to permanent immersion service
Application Scenarios
- Connection of swivel to anchor chain on ships
- Offshore mooring line terminations
- Anchor handling assemblies
- Heavy mooring systems using R3 to R5 grade chain
Who It Is For
- Shipyards and mooring contractors specifying certified fittings
- Offshore operators working to R-grade requirements
- Marine equipment distributors
Technical Features
- Nominal diameter 12.5mm to 162mm
- Grade 2 and 3, plus mooring grades R3, R4 and R5
- Material alloy steel, carbon steel or stainless steel
- Surface finishing black painting, hot dip galvanized or electro-galvanized
- Certificates from DNV, GL, BV, LRS, ABS, IRS, RS, KR, NK and CCS
Specification Table
Values below are taken from our own product data. Where a figure is not published for this item, we confirm it against your order rather than estimating it.
| Material | alloy steel/carbon steel/stainless steel |
|---|---|
| Surface Finishing | black painting/hot dip galvanized/electro-galvanized |
| Nominal Diameter | 12.5mm to 162mm |
Customization Options
- Nominal diameter from 12.5mm to 162mm
- Grade 2, grade 3 or mooring grades R3, R4 and R5
- Material and surface finish by order, with the classification certificate specified
Quality Control
- Precision forging and heat treatment controlled through production
- Classification society inspection and certification on request
- Dimensional check against the nominal diameter ordered
Photographs Of This Product
How It Compares With The Alternatives
Compared with Pear shaped end shackle
Both are end fittings, the D type has the classic straight-sided body while the pear shape tapers to suit different end link geometry
Compared with D type joining shackle (lugged)
The end shackle terminates a chain run at the swivel, the joining shackle connects two lengths of chain together
How To Use And Maintain It
- Match the shackle grade to the grade of chain in the mooring line
- Specify the classification society before production starts
- Choose hot dip galvanized or black painting according to immersion exposure
- Check nominal diameter against the chain it connects
What We Need From You To Quote
- Size or diameter, and the grade if it is specified
- Quantity and packing format
- Surface finish for the environment it works in
- Classification society, if a certificate is required
- Destination port for freight
D Type End Anchor Shackle FAQ
What diameter range do you supply?
Nominal diameter 12.5mm to 162mm.
Which grades are available?
Grade 2 and 3, as well as mooring grades R3, R4 and R5.
Which certificates can you provide?
DNV, GL, BV, LRS, ABS, IRS, RS, KR, NK and CCS.
What materials can it be made from?
Alloy steel, carbon steel or stainless steel.
What surface finishes are offered?
Black painting, hot dip galvanized or electro-galvanized.
What does this shackle connect?
It connects the swivel with the anchor chain in marine anchor and mooring systems.
