Modern Concave Mirror Stainless Steel Sculpture at the Exhibition Center of Art the Fan Concave Sculpture
Modern concave mirror stainless steel sculptures formed from pressed metal plates, designed to create a lifelike water drop or raindrop shape. Constructed from AISI 201, 304 or 316 stainless steel with wall thicknesses from 1 mm to 2 mm, and diameters from 300 mm to 2000 mm. The surface is mirror polished to ensure a uniform, high-gloss reflection with no visible distortion. Each sculpture is custom formed using external force to shape the plate, then welded and polished to a seamless finish. The final piece is designed to reflect the viewer and surroundings, creating a dynamic, changing visual experience.
Key Benefits
- Mirror polished surface provides a clear, undistorted reflection with no visible seam or flat spot
- Hollow construction keeps the sculpture light enough for two people to handle and install without lifting equipment
- Wall thickness from 1 mm to 2 mm allows cost control while maintaining structural integrity
- Custom shape and size available to match architectural or landscape design intent
- Seam welding and grinding ensure the joint is invisible in reflection
- Welded base or stand available to match the installation method
- AISI 304 and 316 options for indoor and outdoor use, including coastal or high-moisture environments
Problems It Solves
- Solid or cast metal sculptures become too heavy for large sizes, requiring cranes or heavy plant for installation
- Painted or coated surfaces degrade outdoors, leading to peeling, fading or rust at joints
- Off-the-shelf mirror sculptures have fixed shapes and sizes, limiting design flexibility
- Site welding or polishing of a finished mirror surface damages the finish and creates visible marks
- Multiple suppliers for different parts of a sculpture lead to inconsistent polish and finish quality
- Lack of custom forming options means the design must conform to standard shapes
Application Scenarios
Interior wall installations in exhibition centers, lobbies, and art galleries where reflective surfaces draw attention
Landscape features in gardens and public plazas where the sculpture reflects sky, trees and passersby
Art installations in commercial buildings where the changing reflection adds dynamic interest
Focal points in hotel atriums and retail spaces where the concave form creates a visual pull
Custom sculptural elements in architectural facades where a water drop shape is desired
Public art commissions where the viewer becomes part of the artwork through reflection
Who It Is For
- Interior designers specifying reflective wall art for high-end commercial spaces
- Exhibition center planners needing a unique, eye-catching installation piece
- Landscape architects integrating reflective metal forms into garden or plaza designs
- Public art commissioners requiring a custom, durable sculpture with a strong visual impact
- Architects seeking a sculptural element that changes with the viewer’s position
- Property developers adding distinctive art features to residential or commercial buildings
Technical Features
- Formed from metal plate using external force to create the concave water drop shape
- Multiple plates welded together and ground to an invisible seam
- Mirror polished to a high-gloss finish with uniform reflection
- Wall thickness from 1 mm to 2 mm, selected based on size and structural need
- Available in AISI 201, 304 or 316 stainless steel depending on environment
- Welded base, stand or mounting plate available on request
- Custom curvature and height possible to match design drawings
- Surface checked for reflection clarity and lack of distortion before delivery
Specifications and Materials
| Material | AISI 201, AISI 304 or AISI 316 stainless steel |
|---|---|
| Wall Thickness | 1 mm to 2 mm |
| Size Range | 300 mm to 2000 mm diameter |
| Forming Method | Press formed, welded, seam ground and mirror polished |
| Standard Finish | Mirror polished |
| Optional Finishes | Vacuum metallising, electroplating, transparent candy colour spray |
| Secondary Operations | Welded base, stand, or mounting plate, drilling and tapping |
| Lead Time | 15 to 30 days after deposit received |
| Packing | Wooden stand or case, foam protection inside |
| Payment Terms | T/T, 50% deposit and 50% balance before shipping |
| Place of Origin | Shenzhen, China |
Materials
- AISI 201 stainless steel, suitable for indoor or sheltered outdoor use
- AISI 304 stainless steel, standard for outdoor gardens, parks and interiors
- AISI 316 stainless steel, recommended for coastal, poolside or high-salt exposure
Customization
- Any diameter between 300 mm and 2000 mm, not limited to standard sizes
- Wall thickness selected based on size and load case, not fixed by default
- Curvature and height adjusted to match your design or drawing
- Welded base, stand, flange or mounting plate positioned exactly where needed
- Multiple units in a set can be made with the same polish batch for visual consistency
- Custom colour finishes including vacuum metallising, electroplating or candy spray
How It Is Made
- Step 1Sheet metal cut to size based on the design drawing
- Step 2Plate pressed and formed into the concave water drop shape using external force
- Step 3Multiple plates joined and seam welded into a single unit
- Step 4Welds ground and blended until invisible in reflection
- Step 5Surface polished through progressive grits to achieve mirror finish
- Step 6Optional vacuum metallising, electroplating or candy colour spray applied
- Step 7Base, stand or mounting plate welded on if required
- Step 8Protective film applied, foam wrapped and packed in wooden stand or case
Quality Control and Use
Quality Control
- Seam inspected under reflected light to ensure no flat spots or visible welds
- Diameter and curvature checked against the drawing before polishing
- Mirror finish tested by viewing a clear object in reflection to check clarity and distortion
- Wall thickness measured at multiple points to confirm consistency
- Final inspection includes checking for scratches, dents or surface imperfections
- Photographs of the finished piece sent for approval before shipping
Use Guide
- Specify the diameter, wall thickness, finish and mounting method when requesting a quote
- Send the base or stand detail so the welded attachment is positioned correctly
- Use 316 stainless steel for coastal or high-salt environments
- Keep the protective film on until the sculpture is mounted and the site is clean
- Clean with soft cloth and water only; avoid wire brushes or chloride cleaners
Compared With The Alternatives
| Alternative | How this product compares |
|---|---|
| Cast or solid metal sculptures | Much lighter for the same size, so easier to install without lifting plant, but not load bearing |
| Painted or coated metal sculptures | No peeling, fading or rust at joints, but higher initial cost |
| Acrylic or GRP concave mirrors | Real specular reflection and no yellowing outdoors, but heavier and slower to produce |
| Flat mirror panels | The concave form creates a dynamic, changing reflection that draws the viewer in |
