Large Stainless Steel Sculpture - Moon Gate
Large stainless steel Moon Gate sculpture, custom fabricated in Shenzhen, China. Designed for public and garden spaces, the gate stands 5 metres in diameter with a 2.1 metre high central opening. Constructed from AISI 201, 304 or 316 stainless steel, wall thickness ranges from 1 mm to 6 mm. The form is built from pressed and welded steel sections, finished in mirror, brushed or matt polish, and delivered with detailed shop drawings for site assembly. Suitable for parks, plazas, campuses, and private gardens where a large-scale, reflective architectural feature is needed.
Key Benefits
- Custom size available beyond standard tooling, so the gate can be scaled to site dimensions without compromise
- Hollow construction keeps the weight manageable for lifting and installation, even at 5 metre diameter
- Mirror polished finish holds clarity outdoors without fading or requiring repainting
- Wall thickness selectable from 1 mm to 6 mm to match structural needs without over-engineering
- Detailed shop drawings supplied so the gate can be assembled on site with no on-site welding or cutting
- Available in AISI 201, 304 or 316 stainless steel to suit climate exposure and budget
Problems It Solves
- Large steel gates become too heavy to install once they exceed 3 metres in diameter, requiring cranes and complex rigging
- Site welding on a large mirror polished surface damages the finish and requires costly rework
- Buying a gate from multiple suppliers results in mismatched finishes, welds and dimensions
- Lack of shop drawings means on-site assembly is slow, error-prone and requires skilled welders
- Cast or solid steel gates are too heavy for transport and lifting, even at moderate sizes
- Painted steel gates fade, chip and rust at the seams, requiring maintenance every few years
Application Scenarios
Central feature in a public plaza or campus courtyard where a large, reflective architectural form is needed
Entryway or focal point in a private garden or estate with a strong visual presence
Landmark sculpture in a park or nature reserve where the gate’s silhouette is visible from a distance
Architectural element in a school or university campus that doubles as a symbolic gateway
Installation in a corporate park or business district where a sculptural entrance enhances the site identity
Site-specific artwork for a municipal or cultural project requiring a custom-scale metal structure
Who It Is For
- Landscape architects specifying a large-scale, permanent sculptural element in a public space
- Public art commissioners needing a custom gate with detailed fabrication drawings
- Campus planners designing a symbolic entrance or gathering point for students and staff
- Property developers adding a distinctive feature to a residential or commercial complex
- Interior designers integrating a large-scale metal form into a building’s exterior or atrium
- Sculpture installers who need a pre-fabricated, ready-to-assemble structure with no on-site welding
Technical Features
- Constructed from pressed and welded steel sections, not cast or solid
- Wall thickness from 1 mm to 6 mm, selected to match structural load and site conditions
- Available in AISI 201, 304 or 316 stainless steel, with 316 for coastal or high-salinity environments
- Mirror, brushed or matt finishes applied after welding and grinding to ensure a consistent surface
- Detailed shop drawings provided for site assembly, including bolt positions and alignment marks
- Welds ground and blended to be invisible in reflection, with no visible seams in the final form
- Custom size possible beyond standard tooling, with no fixed step between sizes
- Can be delivered with pre-drilled holes and mounting points for bolts or brackets
Specifications and Materials
| Material | AISI 201, AISI 304 or AISI 316 stainless steel |
|---|---|
| Wall Thickness | 1 mm to 6 mm |
| Forming Method | Stamping press formed sections, hand welded and ground |
| Standard Finish | Mirror polished |
| Optional Finishes | Brushed, matt, vacuum metallising, electroplating, transparent candy colour spray |
| Secondary Operations | Drilling, metric and unified thread tapping, pedestal or mounting bracket welding |
| Lead Time | 15 to 30 days after deposit received |
| Packing | Strong wooden or iron case with soft foam plastic inside |
| Place of Origin | Shenzhen, China |
| Shop Drawings | Supplied with every order for large sculptures |
| Size Range | Customised to any size |
Materials
- AISI 201 stainless steel, used for indoor or low-exposure outdoor applications
- AISI 304 stainless steel, standard for outdoor gardens, parks and public spaces
- AISI 316 stainless steel, recommended for coastal areas, pool surrounds and high-salinity environments
Customization
- Any diameter and height can be built, not limited to standard sizes
- Wall thickness selected for structural load, not a fixed default
- Finish chosen from mirror, brushed, matt, vacuum metallising, electroplating or candy colour spray
- Mounting points, brackets and base plates positioned to your drawing
- Shop drawings provided with every order to guide on-site assembly
- Multiple units can be built with the same polish batch for visual consistency
How It Is Made
- Step 1Steel sheet cut to size and blanked according to the custom design
- Step 2Sections stamped on a press to form the curved panels and frame elements
- Step 3Panels assembled and seam welded by hand, with precise alignment for the final form
- Step 4Welds ground and blended until invisible under reflected light
- Step 5Holes drilled and threads tapped, mounting brackets or pedestals welded on
- Step 6Mirror, brushed or matt finish applied through progressive grit polishing
- Step 7Optional vacuum metallising, electroplating or candy colour spray applied
- Step 8Protective film applied, foam wrapped, and packed in a wooden or iron case
Quality Control and Use
Quality Control
- Welds inspected under reflected light to confirm no flat spots or visible seams
- Diameter and wall thickness verified against the order before finishing begins
- Thread holes checked for pitch and depth after tapping
- Final form checked against shop drawings for alignment and symmetry
- Photographs of the finished sculpture sent for approval before the balance is invoiced
- Packing inspected to ensure foam protection and case strength for sea freight
Use Guide
- Specify the exact diameter, wall thickness, finish and mounting method when requesting a quote
- Send the base or support detail so the mounting brackets are welded in the correct position
- Use 316 stainless steel if the gate is near salt water, pools or de-icing salt
- Keep the protective film on until the gate is bolted down and the site is clean
- Clean with water and a soft cloth; avoid wire brushes or chloride-based cleaners
- For a gate over 3 metres, plan for a two-point lift and padded cradle during installation
Compared With The Alternatives
| Alternative | How this product compares |
|---|---|
| Cast or solid steel gates | Much lighter and easier to transport and install, but not load bearing |
| Painted mild steel gates | No rust at seams and no repainting cycle, but higher initial cost |
| GRP or fibreglass gates | Real metal reflection and no yellowing outdoors, but slower to produce and less durable |
| Site-welded steel gates | No on-site welding means no finish damage and faster assembly, but requires pre-fabrication |
Related Products
Garden SculptureOutdoors Garden Geometrical Stainless Steel Rock Ellipse Sculpture Stone Sculpture
View Details
Garden SculptureLarge Stainless Steel Mirror Water Drop Sculpture
View Details
Garden SculptureLarge Stainless Steel Sculpture - Windmill & Eye of the Sky
View Details
Garden SculptureGarden Decorative Stainless Steel Stone & Cobblestone Sculpture
View DetailsGuides That Help You Specify This
AISI 304 vs 316 Stainless Steel for Outdoor Sculpture
When 304 is enough, when 316 earns the extra cost, and why chloride rather than rain is what actually attacks a polished surface.
Mirror Polishing Explained for Stainless Steel Sculpture
Why the quality of a mirror finish is decided during welding and fixing, long before the piece reaches the polishing shop.
Installing a Large Stainless Steel Sculpture
What has to be agreed before a large piece ships, from base plate geometry to when the protective film comes off.
Questions About Large Stainless Steel Sculpture - Moon Gate
What is the largest size you can make?
Any size up to 3000 mm diameter on standard tooling. The Moon Gate was made at 5 metres, so larger sizes are possible with custom tooling and lead time adjustment.
How long does delivery take?
15 to 30 days after deposit received. Larger or complex custom sculptures may take closer to 30 days.
Should I use 201, 304 or 316?
AISI 201 for indoor or low-exposure areas. AISI 304 for general outdoor use. AISI 316 for coastal, pool or high-salinity environments.
Can you provide shop drawings?
Yes. Detailed shop drawings are supplied with every large sculpture order to guide site assembly.
How are large gates packed for shipping?
Wrapped in soft foam, then packed in a strong wooden or iron case. Wooden stands are used for gates over 2 metres in diameter.
What are the payment terms?
T/T with 50% deposit and 50% balance before shipping. Photographs of the finished sculpture are sent for approval before the balance is invoiced.
Get a Price on Large Stainless Steel Sculpture - Moon Gate
Send the size, finish and fixing you need and we will come back with a price and a lead time for Large Stainless Steel Sculpture - Moon Gate.
