SY-100-250 Heating Circulator for Reactor
SY-100-250 Heating Circulators has a better service performance. Corrosion resistant with superior stainless steel. Warning alarms built in for temperature and overload protection. Built-in function for injecting cooling water into the heating
Introduction
This is a water-cooled type heating circulator. The bath fluid is heated up by electricity and transferred to reactors by circulating pump, which can be applied to pharmaceutical plants, chemical industry, petrochemical industry, laboratory research, etc.
Features and Advantages
- Circulation pump with stainless steel magnetic drive ensures no leakage at high temperatures.
- Expansion tank made of SUS304 material, offering strong corrosion resistance.
- All pipes in the circulation system are made of SUS304 stainless steel.
- Sealed circulation system prevents the thermal fluid from evaporating and oxidizing easily, extending the service life of the thermal fluid and avoiding environmental pollution.
- Casters with brake devices facilitate easy movement and precise positioning of the equipment.
- Temperature control utilizes PID algorithm for high precision.
- Button input and LCD display ensure easy operation.
- Equipped with a liquid level display tube to monitor the amount of thermal fluid in the system in real-time, ensuring safe usage.
- Over-temperature protection device cuts off power and alarms immediately when the system temperature exceeds the set limit, ensuring safety.
- Comes with cooling coils that can be connected to an external cooling water source to adjust the temperature of the thermal fluid, meeting process requirements.
Which Kinds of Industry Can Use This Heating Circulator?
Pharmaceutical plants;
Chemical industry;
Petrochemical industry;
Biological industry;
Laboratory research;
Education; etc
Applications of Heating Circulator
This heating circulator heat liquids effectively at working temperatures between RT+5 °C to +250 °C. Meeting demanding tasks and strict requirements for research, material testing, and production applications.
Specifications
Figures below are the manufacturer data for this model. Anything not listed is confirmed in writing with the quotation rather than estimated here.
| Model No. | SY-100-250 | |
|---|---|---|
| Operating temperature range (℃) | Room temperature +5-250 | |
| Temperature stability (℃) | ±0.5 | |
| Safety protection functions | Overcurrent, ground fault, overload and over-temperature protection | |
| Heater power (W) | 12000 | |
| Circulation pump | Power (W) | 1500 |
| Maximum flow rate (L/min) | 100 | |
| Maximum pressure (bar) | 1.5 | |
| Power source | 3～, 380V, 50Hz | |
| Ambient temperature range (℃) | 5—35 | |
| Ambient relative humidity (%) | ≤ 70 | |
| Expansion box material | SUS304 | |
| Cooling coil material | Oxygen-free copper tube | |
| External diameter of cooling coil (mm) | Φ10 hose connector | |
| External circulation connector size | 3/4” | |
| Conveying pipe and valve materials | SUS304 | |
| Heat carrier filling volume (L) | 17 | |
| Dimensions (mm) | 640W×940D×1585H | |
| Net weight (kg) | 185 | |
| Warranty | 12 months, lifetime support |
