Split Type 100-Ton Hydraulic Electric Powder Pellet Press with Safety Shield

Applications

This electric powder pellet press is mainly used for samples that require high pressure for shaping, such as ceramics, metal powders, and various large-sized molds.

Introduction

The hydraulic press adopts a split-type structure and operates fully automatically through programmed procedures: programmed pressurization/gradual pressurization, pressure holding, pressure supplementation, timed pressure release, etc. It features a liquid crystal display screen for intuitive and simple operation. Equipped with plexiglass protective cover as standard, ensuring safe and reliable operation. It offers stable pressure and convenient operation.

Operating Steps

• Place the assembled mold into the press and tighten the screw;
• Press the “Settings” button to enter the settings interface;
• Settings interface content: upper limit pressure – lower limit pressure – pressurization time – mold diameter;
• Press the “+” key to increase the value;
• Press the “-” key to decrease the value;
• Press the “Settings” key to move the setting item, long press to exit the setting menu;
• Return to the operating menu;
• Press the “Pressurize” button to start the equipment;
• When the pressure reaches half of the set parameter, the system will reduce the pressurization speed;
• When the pressure reaches the set value, the system stops pressurizing and starts timing, followed by automatic pressure release;
• In case of emergency, press the “Stop” button to stop the equipment from pressurizing and release the pressure;
• The press resets automatically.

Others

Optional- Matching Dry Pellet Pressing Die Set
