Automatic Lab Press for Powder Pellet Pressing (2–60 Ton)
The ZYLAB Automatic Lab Press is a fully automated hydraulic press designed specifically for powder pellet preparation in laboratories. Available in 2-ton, 10-ton, 20-ton, 30-ton, 40-ton, and 60-ton models, it is ideal for precise and efficient powder compaction and pellet formation. This press is independently...
Introduction
The ZYLAB Automatic Lab Press is a fully automated hydraulic press designed specifically for powder pellet preparation in laboratories. Available in 2-ton, 10-ton, 20-ton, 30-ton, 40-ton, and 60-ton models, it is ideal for precise and efficient powder compaction and pellet formation. This press is independently developed by our company, incorporating advanced control systems and user feedback from universities and research institutions.
Engineered based on our proven manual and electric press models, the automatic press offers accurate pressure control, programmable operation, and high safety standards. It is suitable for a wide range of laboratory applications including sample preparation for spectroscopy, XRF analysis, and materials research.
Main Features of Automatic Lab Press
1.Smart Pressure Control System
Integrated SAVTA intelligent system
Supports 5-stage pressure programming (upgradable to 15 stages)
Ensures stable and repeatable pressure profiles
2. Fully Automated Operation
Automated pressurizing, pressure compensation, holding, and release
Reduces manual intervention and improves consistency
3. Real-Time Pressure Conversion
Converts hydraulic pressure to sample pressure automatically
Displays real-time pressure values
Includes overpressure warning and alert system
4. User-Friendly Interface
7-inch touchscreen with English/Chinese switchable UI
Intuitive menus and programmable parameters for easy operation
5. High Safety Standards
10 mm alumina side panels and 6 mm acrylic safety door
Protects operators during high-pressure operation
6. Limit and Overload Protection
Automatically releases pressure if the cylinder height exceeds limit
Triggers automatic pressure release when system pressure exceeds maximum
7. Fault Detection & Emergency Stop
Detects mechanical and pressure system faults
Built-in emergency stop button for immediate shutdown
8. Data Storage & Export
Stores up to 10,000 records
Supports USB export for easy data management and traceability
9. Electrical Safety Protection
Equipped with leakage protection
Integrated emergency stop button ensures safe operation
Why Choose ZYLAB Automatic Lab Press?
Precise control, safe design, and reliable automation
Trusted by university labs, R&D centers, and material testing facilities
Engineered for long-term use with high structural integrity and software flexibility
Matching Die Set：
If you require other special-shaped die sets, or specific types such as tungsten carbide dies, XRF-dedicated molds, or electrically heated die sets, please contact our customer service team immediately. Our technical engineers will assist you in evaluating feasibility and providing customized solutions tailored to your application needs.
Specifications
Figures below are the manufacturer data for this model. Anything not listed is confirmed in writing with the quotation rather than estimated here.
| Model | AP-2 | AP-10 | AP-20 | AP-30 | AP-40 | AP-60 |
|---|---|---|---|---|---|---|
| Pressure Range | 0.2-2T | 0.2-10T | 0.2-20T | 0.2-30T | 1-40T | 1-60T |
| Cylinder Diameter | 95mm | 95mm | 95mm | 110mm | 130mm | 150mm |
| Cylinder Stroke | ≤30mm | ≤50mm | ||||
| Power Supply | 220V(50Hz/60Hz)/Customized 110V | |||||
| Power Consumption | 400W | |||||
| Usable Space | 145x145x160mm | 170x170x180mm | 190x190x225mm | |||
| Overall Dimensions | 230x395x432mm | 285x460x555mm | 305x520x585mm | |||
| Equipment Weight | 96Kg | 152Kg | 182Kg |
Automatic Lab Press for Powder Pellet Pressing (2–60 Ton) In Detail
Processes This Unit Supports
These are the applications ZYLAB lists this model under. Each link opens the full equipment set for that process, which is useful when a project needs more than one machine.
Who Orders It
Fields this model already works in, plus what ZYLAB puts behind it: a 2-year warranty on most products, glass excluded, spare parts in stock and free application support by WhatsApp or email.
