Lowboy Trailer for Sale
Lowboy in 2, 3 or 4 axles carrying 40, 60 or 80 tons
Looking for a reliable heavy-duty transport trailer? Our Lowboy Trailer is specially designed for transporting heavy equipment, construction machinery, and bulk goods. It is available in 2-axle, 3-axle, and 4-axle configurations, capable of carrying extremely heavy loads and ensuring the stability of long-distance transportation.
- Product Name
- 2 axles lowboy trailer 3 axles lowboy trailer 4 axles lowboy trailer
- Size (mm)
- 12500*3000*1100 13000*3000*1100 14000*3000*1100
- Payload
- 40000KG 60000KG 80000KG
- Axles
- 2 * 13ton capacity (FUWA) 3 * 13ton capacity (FUWA) 4 * 13ton...
Built at SINOHENG Trailer Factory, Jinan, Shandong, China. Exported to 30+ countries across Southeast Asia, Africa, the Middle East and South America.
Operators This Trailer Is Built Around
- Heavy equipment movers whose machine weights span a wide range
- Contractors carrying excavators and bulldozers through height-restricted routes
Problems It Solves
Machines too tall for bridges and underpasses
The low bed design lets tall equipment pass bridges and narrow sections that a flatbed cannot clear.
One payload rating never covers a mixed fleet
40,000, 60,000 and 80,000 kg builds on 2, 3 or 4 FUWA 13-ton axles.
What You Get For the Money
Heavy section main beam
500 mm beam height with 16 mm upper plate, 8 mm middle and 18 mm lower plate in Q345B steel.
250 mm I-beam side members
Plus 20 mm Q235 channel steel, sized for concentrated track loads.
ABS optional
Double air chamber braking with brake valve and 45 L air tanks, with ABS available on request.
Technical Description
Technical Construction
This Lowboy Trailer is made of high-strength steel and equipped with reinforced axles. It is specially designed for transporting heavy machinery such as excavators and bulldozers. The low-bed design ensures that even goods of considerable height can safely pass through Bridges and narrow sections, greatly enhancing transportation efficiency and safety.
Build and Finish
We offer factory-direct prices, allowing you to obtain high-quality trailers at the most competitive prices. Whether it’s a single unit customization or a large order, we can provide customized configurations tailored to your specific transportation needs.
Operating Detail
Choose our Lowboy Trailer. Whether it’s the transportation of construction equipment, mining machinery, or heavy agricultural equipment, we can provide the most suitable solutions. Contact us immediately to get a customized quotation and technical support!
Manufacturing Notes
SINOHENG Trailer Factory is an enterprise specializing in the production and sales of trailers, dedicated to providing customers with high-quality and high-performance trailer products. We use high-strength steel and optimized design to ensure that the products maintain high load-bearing capacity while being lightweight, meeting customers’ dual demands for transportation efficiency and cost control.
Included Equipment
- High load-bearing capacity – can carry 80 tons or more, depending on the configuration of the number of shafts
- Customized axle count configuration – Available in 3-axle, 4-axle, 5-axle, or 6-axle configurations to ensure the best weight distribution
- Low bed design – specifically designed for transporting tall goods
- Heavy-duty structure – Made of high-quality steel to ensure durability
- Factory direct sales price – No middlemen, ensuring more competitive prices
- Fast global delivery – Providing reliable global transportation services
Lowboy Trailer for Sale Specification Sheet
Figures below are the published specification for the standard build. Anything not listed is confirmed on the approval drawing before production, and we mark unknowns as TBC rather than estimating them.
| Product Name | 2 axles lowboy trailer 3 axles lowboy trailer 4 axles lowboy trailer |
|---|---|
| Size (mm) | 12500*3000*1100 13000*3000*1100 14000*3000*1100 |
| Payload | 40000KG 60000KG 80000KG |
| Axles | 2 * 13ton capacity (FUWA) 3 * 13ton capacity (FUWA) 4 * 13ton capacity (FUWA) |
| Landing gear | 28-ton two-speed |
| Ladder | Hydraulic ladder or Mechanical spring ladder |
| Leaf spring | 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets) |
| Main beam | Height: 500mm, upper plate is 16mm, middle plate is 8mm, down plate is 18mm ; Material is Q345B Steel. |
| Side beam | 250mm I beam; 20mm channel steel ( Material is Q235steel ). |
| Bottom Platform | 4mm thickness diamond steel plate |
| Suspension | Mechanical suspension (Air suspension optional) |
| Braking system | Double air chamber, brake valve,45L air tanks; ABS optional |
| Electrical | LED light, 7 ways,24V |
| Rim | 9.00-22.5 / 11.00R20 8pcs (Other size optional) |
| Kin pin | 2’’/3.5’’ bolt type |
| Accessory | One tooling box with a set of standard trailer tools |
| Painting | 1. Sand blasting processing cleans rust. 2. Coat of anticorrosive primer. 3. Coats of finish urethane paint. 4. Color as customer choice. |
This Build in the Factory
How It Compares
The 13 m three-axle low bed is a fixed, fully published build. This lowboy model is the option range around it, for buyers who need a different payload class or axle count.
Operating Notes
- Check the ramp angle against the machine before loading, not on site.
- Restrain each machine at four independent points.
- Inspect the I-beam side members and welds annually.
Every vehicle ships with an illustrated operation manual covering coupling, braking and turning technique.
Other Builds Worth Comparing
13M Three Axles Low-bed Trailer for sale
13 m low bed with 8,765 mm working platform at 1,255 mm height
View specification →
Buy Low Bed Trailer 3/4 Axles Mechanical Suspension
13 m three axle low bed rated at 60 tons for excavators and dozers
View specification →
Extendable Lowbed Semi Trailer for Oversized Cargo
Telescopic low bed that extends to the length of the machine you are moving
View specification →
Custom Fence Trailer for Sale
Stake side trailer built to your side wall height and axle count
View specification →Questions About This Trailer
How many axles do I need?
Divide the heaviest machine weight by your legal axle load. Two axles suits 40-ton work, three covers 60 tons, and four is normal at 80 tons in most markets.
Mechanical or air suspension?
Mechanical is standard and preferred for site access. Air suspension is optional where you run long paved distances.
Are ramps included?
Ramp type is specified per order against the machines you load. Send the approach angle and track width with your enquiry.
Do you ship to my country?
SINOHENG exports in bulk to 30+ countries and regions across Southeast Asia, Africa, the Middle East and South America. Send your destination port with the enquiry and we will quote delivery with the trailer.
Ask for a Drawing Before You Commit
We confirm dimensions, axle loads and coupling height on an approval drawing before any steel is cut, so the trailer is legal and couples to your tractors.
