Offroad CREE LED Light Bar EMC CISPR 25 CLASS 4
The SLL-88X is a 10W CREE LED light bar designed for off-road vehicles and heavy machinery that operate in extreme conditions. It delivers consistent illumination through a spot, flood, or combo beam pattern with a 6000K colour temperature, ensuring visibility in dust, rain, and high vibration environments. The die-cast aluminium housing and IP68 sealing prevent water and dust ingress during prolonged exposure. EMC protection to CISPR 25 Class 4 ensures the light bar does not interfere with vehicle electronics, which is critical for modern machines with advanced control systems.
- CISPR 25 Class 4 EMC protection prevents interference with vehicle electronics on modern off-road machines
- 10W CREE LED delivers high brightness with low power draw and long lifespan of more than 50000 hours
- IP68 sealing and a durable UV polyester powder coating resist water, dust, and UV degradation in harsh outdoor environments
- Operates reliably across 9 to 32V DC, covering both 12V and 24V systems without voltage regulation
- Overvoltage and overheat protection prevent damage from electrical surges or prolonged high-temperature operation
Where This Lamp Is Used
- Front mounting on off-road vehicles and 4x4s for high-speed night driving on unpaved trails
- Side and rear mounting on excavators and cranes where consistent beam coverage is needed in dusty or wet conditions
- Auxiliary lighting on engineering vehicles and mining machinery where electrical noise from other systems can disrupt sensors
- Fleet vehicles operating in remote areas with unstable power supplies and frequent voltage spikes
- Mounting on utility and service trucks where the light bar must survive daily exposure to rain, salt, and vibration
Who It Is For
- Distributors of off-road vehicle lighting needing a single model with multiple beam options and EMC compliance
- Machinery OEMs integrating lighting into new builds where electronic compatibility is a design requirement
- Fleet operators replacing older LED bars that fail due to electrical noise or heat buildup
- 4x4 accessory brands building a private label range with proven EMC and environmental performance
- Equipment dealers fitting lights on machines used in mining, construction, and agriculture with high vibration
Problems It Solves
- Cheap LED light bars without EMC protection can cause malfunctions in vehicle control modules or sensor systems
- LEDs with short lifespans fail after a few hundred hours in continuous use, increasing maintenance costs
- Light bars with inadequate sealing let water in during pressure washing or heavy rain, leading to internal corrosion
- Voltage fluctuations in 12V and 24V systems can damage unregulated LED drivers, especially in older vehicles
- Standard powder coatings degrade under UV exposure, causing fading and reduced protection over time
Technical Features
- 10W CREE LED with a 6000K colour temperature for clear, daylight-like visibility
- Beam pattern options: spot, flood, or combo beam to suit different operational needs
- Die-cast aluminium housing with durable UV polyester powder coating for long-term protection
- Durable polycarbonate lens resistant to impact and UV degradation
- Operating voltage range of 9 to 32V DC, compatible with 12V and 24V systems
- Overvoltage and overheat protection circuits to extend component life
- IP68 sealing ensures full protection against water and dust ingress
- EMC protection to CISPR 25 Class 4 standard, preventing electromagnetic interference
- Lifespan rated at more than 50000 hours under normal operating conditions
- Operating temperature range from -40 to +85 degrees Celsius, suitable for extreme climates
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-88X |
|---|---|
| LED | 10W CREE |
| Beam Pattern | Spot, Flood, Combo |
| Colour Temperature | 6000K |
| Operating Voltage | 9–32V DC |
| Operating Temperature | -40 to +85 degrees Celsius |
| Waterproof Rating | IP68 |
| EMC Protection | CISPR 25 Class 4 |
| Housing Material | Die-cast aluminium |
| Lens Material | Polycarbonate |
| Coating | UV polyester powder coating |
| Protection | Overvoltage, Overheat |
| Input Type | DC |
| Power Draw | 10W |
| Mounting Type | Bracket or bolt-on |
| Certification | EMC, IP68, CISPR 25 Class 4 |
Materials Used
- Die-cast aluminium housing
- UV polyester powder coating
- Durable polycarbonate lens
- CREE 10W LED emitter
- Silicone gasket for sealing
- Stainless steel mounting bolts (included)
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating with UV polyester finish for outdoor durability
LED board assembly with CREE 10W emitters
Lens bonding with UV-resistant adhesive
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing tested to IP68 standard using water immersion and dust exposure
- Vibration testing on a vibration test machine to simulate machine-mounted service
- Salt spray corrosion testing on housing and mounting hardware
- High and low temperature alternating humidity testing across the -40 to +85 degrees Celsius range
- EMC testing to CISPR 25 Class 4 standard using a shielded chamber
Customisation Options
- Choice of spot, flood, or combo beam optics
- Clear or amber lens colour as standard options
- Custom cable length to match specific machine harnesses
- Private label logo on the housing and printed carton
- Deutsch connector instead of standard bare wire lead
- Mixed cartons combining this light bar with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Standard LED light bar without EMC protection | This model meets CISPR 25 Class 4, preventing interference with vehicle electronics, while others may cause sensor or control system errors |
|---|---|
| LED bar using generic LEDs | CREE 10W LEDs offer higher efficiency and longer lifespan than generic equivalents under continuous duty |
| Light bar with plastic housing | Die-cast aluminium housing provides better heat dissipation and mechanical strength in high-vibration environments |
How to Fit and Use It
- Mount the light bar on a flat, stable surface using the provided bracket or bolts, ensuring no stress on the housing
- Connect the cable to a fused 10A feed sized for the 10W input, and route the cable away from moving parts
- Keep the cable entry point facing downward to prevent water from entering the gland
- Select the beam pattern (spot, flood, or combo) based on the intended use: spot for long distance, flood for wide coverage, combo for mixed needs
- Avoid exposing the lens to solvents or abrasive cleaners; clean with water and a soft cloth only
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this light bar work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the light bar with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for use on vehicles with electronic systems
Yes. The light bar is EMC protected to CISPR 25 Class 4, which ensures it does not interfere with vehicle electronics.
Get a Price on Offroad CREE LED Light Bar EMC CISPR 25 CLASS 4
Send the quantity, the destination port and any branding requirement. You will get pricing, packing data and the production lead time.
