6 Inch 90W Heavy Duty LED Work Light E-Mark Approved
The SLL-6090 is a 6 inch heavy duty LED work light designed for machines operating in extreme conditions across agriculture, forestry, mining and construction. It delivers 7200 lumens from nine 10W CREE LEDs and is E-Mark approved, which allows it to be used on vehicles that travel on public roads. The die-cast aluminium housing and polycarbonate lens resist impact, dust and water ingress to IP68, while the 9 to 32V DC operating range supports both 12V and 24V systems without changing part numbers.
- E-Mark approval enables use on public road vehicles without electrical interference issues
- 90W total power with 7200 lumens output provides bright, even illumination for large work zones
- IP68 sealing and a durable UV polyester powder coating resist dust, water and corrosion in harsh environments
- 9 to 32V DC input covers 12V and 24V systems, reducing the number of SKUs needed in stock
- Overvoltage and overheat protection prevent damage from electrical surges and high ambient temperatures
Where This Lamp Is Used
- Front and side lighting on agricultural tractors and harvesters working in low light or at night
- Excavator and loader boom lighting in mining and construction sites with dust, rain and vibration
- Forklift and crane lighting in warehouses and yards where machines are exposed to moisture and debris
- Road transport lighting on utility and service vehicles that must pass E-Mark compliance checks
- Auxiliary lighting on forestry machines operating in remote areas with no access to maintenance
Who It Is For
- Distributors of heavy duty vehicle lighting needing one part number for both 12V and 24V fleets
- Machinery OEMs integrating work lights into production line builds with consistent mounting and electrical specs
- Fleet operators replacing halogen lights that fail under vibration and draw excessive current
- 4x4 and industrial accessory brands building a private label work light line with E-Mark certification
- Equipment dealers fitting lights on machines sold to customers in Europe and other E-Mark regulated markets
Problems It Solves
- Halogen work lights fail early under vibration and draw more current than LED alternatives
- Uncertified auxiliary lights are rejected during E-Mark road inspections on machines used on public roads
- Cheap sealed lamps let water in through the cable entry and fog up after repeated wash cycles
- Narrow spot beams leave the near work area dark while wide flood beams lack reach for distant visibility
- Painted metal housings and brackets corrode quickly in salt, moisture or chemical environments
Technical Features
- Nine 10W CREE LEDs with a total power draw of 90W and 7200 lumens output
- Flood or spot beam pattern available depending on customer requirement
- Semi-gloss black UV polyester powder coating over the full housing and bracket
- Bare wire lead of 40cm as standard with Deutsch connector available on request
- Overvoltage and overheat protection circuits built into the driver
- Operating window of -40 to +85 degrees Celsius for use in extreme climates
- IP68 sealing with a sealed cable gland and silicone gasket to prevent water and dust ingress
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-6090 |
|---|---|
| Max Power | 90W |
| LED | 9 pcs x 10W CREE |
| Beam Pattern | Flood or Spot |
| Colour Temperature | 6000K |
| Operating Voltage | 9-32V DC |
| Lens Material | Anti-impact PC |
| Waterproof Rating | IP68 |
| Operating Temperature | -40 to +85 degrees Celsius |
| Electrical Connection | Bare wire 40cm, Deutsch connector available |
| Certification | E-Mark, CE, RoHS |
Materials Used
- Anti-impact UV resistant polycarbonate lens
- Silicone rubber gasket and sealed cable entry gland
- Semi-gloss black UV polyester powder coating
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black with UV protection
LED board assembly with CREE emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating before shipment
- Vibration testing on a vibration test machine to reproduce machine mounted service
- Salt spray corrosion testing on housing coating and stainless bracket
- High and low temperature alternating humidity testing across the -40 to +85 degrees Celsius window
Customisation Options
- Deutsch DT connector instead of the standard 40cm bare wire lead
- Spot beam optics in place of the flood pattern
- Private label logo on the housing and printed carton
- Alternative cable length for a specific machine harness
- Mixed cartons combining this lamp with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Round 6 inch work lamp | The square body puts more LED area behind the same mounting footprint but needs a flat surface for the bottom bracket |
|---|---|
| Spot beam version of the same lamp | Flood covers the near working area evenly while spot reaches further ahead but leaves the machine edges dark |
| Larger 8 inch work lamp | Lower output but fits guard rails and cab pillars where an 8 inch body will not clear |
How to Fit and Use It
- Leave a drip loop in the 40cm lead so water runs away from the gland rather than into it
- Aim the flood beam at the working area close to the machine and use a spot lamp separately for distance
- Clean the PC lens with water and a soft cloth only, since solvents will haze the anti-impact coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is E-Mark approved, CE and RoHS compliant, which together allow use on public road vehicles in Europe and other regulated markets.
