30W High Quality Truck Tractor Light Bar Flood Spot Beam Driving Light Offroad LED Work Light
Six 5W Osram LEDs deliver 2700 effective lumens with a flood or spot beam pattern, ensuring visibility across the work zone or down the road. The die-cast aluminium housing is sealed to IP68 and rated for -40 to +105 degrees Celsius, making it suitable for continuous operation in freezing climates and high-heat environments. A 316 stainless steel bracket resists corrosion on machines exposed to salt, chemicals, or frequent washdowns.
- 2700 effective lumens from six 5W Osram LEDs provide clear visibility in dark or dusty conditions
- IP68 sealing and a 316 stainless steel bracket prevent water ingress and corrosion during washdowns
- Operating range of 9-32V DC covers both 12V and 24V systems, reducing SKU complexity
- Rated for more than 50000 hours, reducing replacement frequency on long-haul or remote machines
- Dual beam option (flood or spot) allows one model to serve multiple tasks on the same machine
Where This Lamp Is Used
- Front lighting on tractors and trucks working in night farming or mining operations
- Auxiliary driving lights on off-road vehicles navigating rough terrain at low speeds
- Work area illumination on construction equipment where vibration and dust degrade standard lights
- Fleet vehicles operating in cold climates where standard LEDs fail due to low temperature
- Trucks and trailers used in salt-affected regions where corrosion destroys standard brackets
Who It Is For
- Fleet operators needing one light bar to cover both 12V and 24V vehicles
- Machinery OEMs integrating lighting into production line builds with consistent mounting
- Distributors selling off-road lighting for trucks and tractors who need a dual-beam option
- 4x4 accessory brands building private label lighting with high durability and long life
- Equipment dealers fitting lights on machines used in extreme temperature zones
Problems It Solves
- Standard LED light bars fail under vibration or in high heat due to poor thermal management
- Cheap brackets rust quickly when exposed to salt or cleaning chemicals on daily washdowns
- Narrow spot beams leave the near work zone dark, while narrow flood beams don’t reach far enough
- Lights with limited voltage range require different models for 12V and 24V fleets
- Low lifespan lights need replacement every few months, increasing downtime and cost
Technical Features
- Six Osram 5W LEDs with a real power draw of 30W and 2700 effective lumens
- Flood or spot beam pattern available as an option, with no change to part number
- Die-cast aluminium housing with semi-gloss black powder coating for heat dissipation
- Anti-scratch UV resistant polycarbonate lens over the LED array
- DT connector standard, with bare wire available on request
- Operating voltage range of 9-32V DC, compatible with 12V and 24V systems
- Sealed cable entry gland and silicone gasket prevent water and dust ingress
- Rated for -40 to +105 degrees Celsius operating temperature
- Lifespan of more than 50000 hours under continuous operation
Technical Specification
Values taken from the original factory specification for this model. Fields the factory sheet does not state are left out rather than estimated.
| Part Number | SLL-W3034 |
|---|---|
| Max Power | 30W |
| Real Power | 30W |
| LED | 6 pcs x 5W Osram |
| Theoretical Lumen | 2700 lm |
| Effective Lumen | 2700 lm |
| Beam Pattern | Flood or Spot (optional) |
| Colour Temperature | 5500K-6000K |
| Operating Voltage | 9-32V DC |
| Housing Material | Die-cast aluminium, semi-gloss black powder coating |
| Lens Material | Anti-scratch UV resistant PC |
| Bracket Material | 316 stainless steel |
| Waterproof Rating | IP68 |
| Operating Temperature | -40 to +105 degrees Celsius |
| Electrical Connection | DT connector standard, bare wire available |
| Lifetime | More than 50000 hours |
| Certification | CE, RoHS |
Materials Used
- Die-cast aluminium housing and heat sink
- Anti-scratch UV resistant polycarbonate lens
- 316 stainless steel mounting bracket
- Silicone rubber gasket and sealed cable entry gland
- Semi-gloss black powder coating on housing and bracket
How This Lamp Is Built
Die casting of the aluminium housing and heat sink
Powder coating in semi-gloss black
LED board assembly with Osram emitters
Lens bonding and gasket sealing
Quality Control on This Model
- Photometric output verified in an integrating sphere
- Sealing verified against the IP68 rating before shipment
- Vibration testing on a vibration test machine to reproduce machine mounted service
- Salt spray corrosion testing on housing coating and 316 stainless bracket
- High and low temperature alternating humidity testing across the -40 to +105 degrees Celsius window
Customisation Options
- Option to choose flood or spot beam pattern at time of order
- Deutsch DT connector instead of standard bare wire lead
- Private label logo on the housing and printed carton
- Alternative cable length for integration with a specific machine harness
- Mixed cartons combining this light bar with other SUNLITEC models for trial orders
How It Compares With the Alternatives
| Standard 30W LED light bar with mild steel bracket | 316 stainless bracket resists corrosion in salt and chemical environments where mild steel fails |
|---|---|
| Light bar with 50000 hour lifespan but only 12-24V range | 9-32V operating range covers both 12V and 24V systems, reducing SKUs |
| Flood beam only light bar | Spot beam option allows longer reach for road use, while flood covers near work zones |
| Light bar with lower IP rating | IP68 sealing ensures operation after pressure washing and in high humidity |
| Light bar with 50000 hour lifespan but no ECE R10 approval | CE and RoHS compliant, suitable for road-going machines in Europe |
How to Fit and Use It
- Leave a drip loop in the 40cm lead so water runs away from the gland rather than into it
- Choose flood beam for near work area lighting or spot beam for long-distance visibility
- Clean the PC lens with water and a soft cloth only, since solvents will haze the anti-scratch coating
Questions About This Model
Can I order a sample before placing a bulk order
Yes. Sample orders are welcome and mixed samples of different models in one shipment are accepted.
What is the lead time
Sample orders normally take around 3 to 7 working days. Bulk lead time depends on the model and the quantity ordered.
Do you have a minimum order quantity
There is an MOQ for standard orders, but smaller orders are also accepted, which suits distributors testing a new model.
How is the lamp shipped
Samples usually go by DHL, UPS, FedEx or TNT in around 4 to 7 days. Bulk orders ship by air in about 7 to 15 days or by sea in about 15 to 30 days.
Will this lamp work on both 12V and 24V machines
Yes. The operating range is 9 to 32V DC, so the same part number can be fitted to 12V and 24V vehicles.
Can you supply the lamp with our own brand
Yes. OEM and ODM service is available, including a private label logo on the housing and printed cartons.
Is it approved for road going machines
The lamp is CE and RoHS compliant, suitable for use on machines that operate on public roads.
