Honeycomb Paper Cutting Machine 2 Roll
The HQ 600-2 Rolls cuts finished honeycomb paper rolls into uniform sheets in a single pass. It handles two rolls at once, feeding them through a die-cutting station to produce sheets up to 550 mm wide and 999 mm long. Converters use it to turn their in-house honeycomb rolls into ready-to-use packaging sheets without manual cutting, and it runs at 30 to 60 m/min with a 2.5 kW motor.
- Converts honeycomb paper rolls into consistent sheets without manual cutting or tape
- Two-roll input allows higher throughput than single-roll cutting machines
- Runs at 30 to 60 m/min, matching the output speed of most honeycomb forming machines
- No need for plastic tape due to the interlocking honeycomb structure that locks when torn
- Compact design fits into small production areas and integrates with existing packaging lines
Key Benefits
- Converts honeycomb paper rolls into consistent sheets without manual cutting or tape
- Two-roll input allows higher throughput than single-roll cutting machines
- Runs at 30 to 60 m/min, matching the output speed of most honeycomb forming machines
- No need for plastic tape due to the interlocking honeycomb structure that locks when torn
- Compact design fits into small production areas and integrates with existing packaging lines
- Produces sheets that are recyclable, biodegradable and compostable for eco-friendly packaging
Application Scenarios
- Packaging converters turning honeycomb rolls into sheets for e-commerce order packing
- In-house packaging teams replacing plastic tape with self-locking honeycomb sheets
- Fruit and flower packers needing scratch-free, soft wrapping for delicate items
- Ceramics and glassware producers using pre-cut sheets to protect fragile surfaces
- Craft and gift brands offering unboxing experiences with sustainable, tearable paper
Who It Is For
- Protective packaging converters adding sheet output to their honeycomb production line
- E-commerce fulfilment centres packing high volumes of fragile goods daily
- Paper mills that produce honeycomb rolls and want to offer finished sheet products
- Sustainable packaging brands replacing plastic wrap with compostable alternatives
- Manufacturers of kraft paper packaging machines needing a downstream sheeting solution
Problems It Solves
- Manual cutting of honeycomb paper is slow, inconsistent and labor-intensive
- Plastic tape is required to secure loose sheets, increasing cost and waste
- Sheet lengths vary when cut by hand, leading to material waste and packing delays
- Lack of a dedicated sheeting machine forces converters to use inefficient workarounds
- Packaging lines cannot scale without a reliable, automated sheeting step
Technical Features
- Two-roll input system for simultaneous feeding of two honeycomb paper rolls
- Max cutting width of 550 mm for wide sheet output
- Max cutting length of 999 mm for standard-sized sheets
- Production capacity of 30 to 60 m/min to match forming machine output
- 2.5 kW motor powers the cutting and conveyor system
- Die-cutting station ensures clean, repeatable sheet edges
- Conveyor system moves sheets forward after cutting for easy collection
- Compact frame allows placement in tight production spaces
- Interlocking honeycomb structure locks when torn, eliminating need for tape
Specifications
| Model | HQ 600-2 rolls |
|---|---|
| Max.Cutting width | 550 mm |
| Max.Cutting length | 999 mm |
| Production capacity | 30-60 m/min |
| Power | 2.5 kW |
| Machine Dimension | 3800X1200X1200 mm |
| Weight of machine | 900 kg |
Materials It Runs
- Finished honeycomb paper rolls made from kraft paper
- Tissue interleaf paper laminated behind the honeycomb layer
Manufacturing and Process
- Feed two finished honeycomb paper rolls into the machine
- Pass through die-cutting station to cut sheets to set length
- Conveyor moves sheets forward after cutting
- Collect sheets in batch for use at packing stations
- Optional: feed sheets directly into a kraft paper packaging machine
Quality Control
- Die-cut edges inspected for clean, consistent cuts before shipment
- Conveyor belt tested for smooth sheet movement at full 60 m/min speed
- Cut length verified against the set value on the control panel
- Interlocking structure tested by tearing a sample to confirm self-locking
Certifications
- ISO 9001:2000 certificate obtained in 2005
- CE certificate obtained in 2006
Customization Options
- Cutting length adjusted to match customer's packaging line requirements
- Conveyor height and angle modified for integration with downstream equipment
- Power supply configured to local voltage and phase on request
- OEM badging and manual language available upon request
- Machine frame painted in customer's brand color if needed
Compared With the Alternatives
Manual cutting with scissors or knife
This machine produces consistent sheet sizes and speeds up packing, reducing labor and waste
Single-roll cutting machines
The two-roll input doubles throughput and reduces downtime between roll changes
Plastic wrap cutting machines
This machine produces a compostable, tape-free solution, though it does not seal moisture like plastic film
Roll-to-roll forming machines
This machine only cuts sheets; it requires a prior forming step to create the honeycomb roll
Use Guide
- Load two finished honeycomb paper rolls onto the input shafts
- Set the desired sheet length on the control panel to match your packaging needs
- Start the machine at low speed to verify the die-cutting alignment
- Check that the conveyor moves sheets smoothly and collects them without jamming
- Tear a sample sheet to confirm the interlocking structure locks securely
Questions About This Machine
What is the maximum sheet size it can cut?
Up to 550 mm wide and 999 mm long.
How fast does it run?
30 to 60 m/min, depending on the paper grade and sheet length.
Can it handle two rolls at once?
Yes, it is designed for two-roll input to increase throughput.
Does it need plastic tape to secure sheets?
No, the interlocking honeycomb structure locks when torn, eliminating the need for tape.
What power supply does it require?
2.5 kW standard. Can be adjusted to local voltage and phase on request.
Can it integrate with a kraft paper packaging machine?
Yes, the conveyor system feeds sheets directly into downstream packaging equipment.
Do you support OEM orders?
Yes, OEM badging, manual language and power supply can be configured at order.
