High Speed Paper Sheeting Machine

The HQ-H1400 and HQ-H1700 High Speed Paper Sheeting Machines convert large kraft paper rolls into precise sheets in a single continuous process. They handle paper from 50 to 500 gsm and cut sheets between 400 and 1600 mm in length at up to 300 cuts per minute. The machines are designed for converters who need to produce consistent sheet sizes for packaging, wrapping, or cushioning without relying on third-party suppliers.

Converts kraft paper rolls into uniform sheets in one pass, eliminating manual cutting and handling
Cuts sheets from 400 to 1600 mm with an accuracy of +/-0.4 mm, ensuring consistent packaging fit
Runs paper from 50 to 500 gsm, including heavy-duty kraft, corrugated liner, and cushioning grades
Maximum cutting speed of 300 cuts per minute allows high throughput for volume production
Operates at up to 300 m/min cutting meter speed, matching fast packaging lines

Why It Is Specified

Key Benefits

Converts kraft paper rolls into uniform sheets in one pass, eliminating manual cutting and handling
Cuts sheets from 400 to 1600 mm with an accuracy of +/-0.4 mm, ensuring consistent packaging fit
Runs paper from 50 to 500 gsm, including heavy-duty kraft, corrugated liner, and cushioning grades
Maximum cutting speed of 300 cuts per minute allows high throughput for volume production
Operates at up to 300 m/min cutting meter speed, matching fast packaging lines
Built with a 25KW or 28KW total power system and 0.8MPa atmospheric pressure for stable performance

Where It Runs

Application Scenarios

Packaging converters producing custom-sized sheets for e-commerce cartons and protective inserts
In-house packaging departments replacing plastic foam or bubble wrap with paper sheets
Paper mills converting parent rolls into finished sheet products for direct sale
Fruit and flower packers needing consistent paper sheets for tray lining and separation
Printing houses producing paper sheets for labels, tags, or display inserts

Who It Is For

Protective packaging producers needing high-speed sheet output for cushioning applications
Paper mills expanding from raw rolls to finished sheet products
E-commerce fulfilment centres requiring fast, consistent sheet production
Packaging converters adding sheeting capability to a paper-based production line
Manufacturers of paper-based packaging who want to eliminate third-party sheet suppliers

Problems It Solves

Manual sheet cutting is slow and inconsistent, leading to material waste and packing delays
Buying pre-cut sheets from suppliers adds cost and reduces control over sheet size and timing
Plastic foam inserts are being restricted in markets with environmental regulations
Inconsistent sheet lengths cause misalignment in automated packing systems
Lack of in-house sheeting capacity forces reliance on external vendors with long lead times

Technical Features

Single-pass slitting and shearing process from unwound roll to finished sheet
Cutting length adjustable from 400 to 1600 mm with accuracy of +/-0.4 mm
Maximum cutting speed of 300 cuts per minute at full line speed
Maximum cutting meter speed of 300 m/min for high-volume output
Air pressure system operating at 0.8MPa for reliable blade actuation
Main motor powered by AC380V/220V x 50HZ, standard for industrial use
Inflatable air shafts for unwinding with maximum diameter of 1650 mm
Automatic sheet stacking or discharge system available as part of the standard setup
Robust frame construction with precision linear guides for consistent blade alignment

As Published by the Factory

Specifications

Specifications for High Speed Paper Sheeting Machine
Model	HQ-H1400
Reference weight of cutting paper	50-500 g/m 2
Max.Diameter of paper	1650 mm(65 " )Max
Max.Width of paper	1400 mm(55 " )Max
Total power	25 kW
Cutting length	400-1600 mm
Cutting accuracy	+/-0.4 mm
Maximum cutting speed	300cuts/min
Maximum cutting meter speed	300 m/min
Atmospheric pressure	0.8MPa
Power supply	AC380V/220Vx50HZ
Total weight	11000 kg
Dimensions	12m×3.9m×2.35m

Materials It Runs

Kraft paper from 50 to 500 gsm
Corrugated liner paper
Cushioning paper
Heavy-duty wrapping paper
Paper grades used in protective packaging and carton lining

Manufacturing and Process

Unwinding the kraft paper roll from a 1650 mm diameter shaft
Guiding the web through tension control system
Slitting the web to the desired width using precision blades
Cutting the continuous web into sheets of set length
Discharging or stacking the finished sheets for packaging or storage

Quality Control

Cut length verified against the set value using a laser or mechanical gauge
Tension control tested with the heaviest paper grade (500 gsm) at full speed
Blade alignment checked for parallelism and wear before shipment

Certifications

ISO 9001:2000 certificate obtained in 2005
CE certificate obtained in 2006

Customization Options

Material width configured to match the buyer's existing roll stock
Power supply adjusted to local voltage and phase if required
Cutting length range modified if needed beyond 400-1600 mm
Sheet stacking or discharge system added based on production layout
OEM badging and manual language provided on request

Compared With the Alternatives

Manual sheet cutting

The machine delivers consistent sheet lengths and higher speed, reducing labor and waste

Buying pre-cut sheets

In-house production removes supplier dependency and allows on-demand sheet sizes

Low-speed sheeters

This machine runs at 300 m/min and 300 cuts/min, suitable for high-volume production

Roll-to-roll folding machines

This machine produces sheets; folding machines are used after shearing for packaging

Use Guide

Mount a kraft paper roll up to 1650 mm diameter on the inflatable air shaft
Set the desired sheet length on the control panel and confirm the cutting accuracy
Start the machine at low speed to test web tracking and blade alignment
Gradually increase speed to 300 m/min while monitoring tension and cut quality
