SL-TJ-03 Ratchet Trailer Jack With 6 Inch Load Spreading Beam
SL-TJ-03 is the only jack in the range that spreads its load along a beam rather than through a single cap. A 6 inch beam sits across the front of the trailer, and a wheel barrel frame with 8 inch rear and 4 inch front wheels lets one person steer 180 lb into position.
Product Overview
What This Product Is and Where It Fits
The 6 inch beam is what sets this model apart. Instead of concentrating the reaction under one 8 inch cap, it distributes it across the front of the trailer. That matters on older trailers and on any frame where a point load under the nose is not welcome.
The frame is a wheel barrel design: two larger wheels at the rear and a single smaller wheel at the front, so the jack is steered rather than shoved. At 180 lb it is the heaviest jack in the range and that frame is what makes the weight workable.
Lifting capacity is 40,000 lb, delivered through a ratchet screw lift. A ratchet gives more mechanical advantage per stroke than a spin head, which is the right trade when the jack is being used to raise rather than only to hold.
Service range is 39.5 through 51 inches, the same as SL-TJ-02 and SL-TJ-04, so a yard can mix models without changing its working practice.
Key Benefits
Three Reasons Buyers Specify This Line
Spreads the reaction across the trailer front
A 6 inch beam instead of a single cap, which suits older frames and repeated use on the same trailer.
Steered, not shoved
The wheel barrel frame with 8 inch rear and 4 inch front wheels gives one operator directional control over 180 lb.
Ratchet lift for load, not speed
More advantage per stroke than a spin head when the jack is actually raising a nose.
Application Scenarios
- Raising the front of a trailer where a point load is unwelcome
- Older trailers and frames with no dedicated jacking pad
- Workshop lifting during landing gear work
- Yards that move one jack between many trailers
Who It Is For
- Fleets running mixed-age trailers
- Workshops that lift the same trailers repeatedly
- Operators who want steering control over a heavy jack
Problems It Solves
- Point loading under a trailer nose on an older frame
- Heavy jacks that cannot be steered into position
- Not enough mechanical advantage to raise a settled nose by hand
- Jacks that have to be lifted rather than wheeled
Technical Features
What Is Actually Published For This Line
6 inch load spreading beam
Distributes the load across the front of the trailer.
Wheel barrel frame
8 inch diameter wheels at the rear and a 4 inch wheel at the front.
Ratchet screw lift
40,000 lb lifting capacity through a ratchet mechanism.
39.5 to 51 inch service range
Matches the other wheeled models in the range.
Specifications
SL-TJ-03 Ratchet Screw Trailer Jack Specification Table
Every figure below is transcribed from the specification sheets S&L published for this line. Where a figure is not published, it is marked rather than estimated.
| Specification |
|---|
| Ratchet screw lift |
| Wheel barrel design for ease of positioning |
| 6 inch beam distributes the load across the front of the trailer |
| 40,000 lb lifting capacity |
| 8 inch diameter wheels at the rear |
| 4 inch diameter wheel at the front |
| Painted safety yellow |
| Service range 39.5 through 51 inches |
| Weight 180 lbs |
Source: the S&L trailer jack product sheet.
Product Photography
SL-TJ-03 Ratchet Screw Trailer Jack As Supplied
Every photograph below is from the S&L product records for this line. Nothing is a stock image or a rendering.
Materials
Materials and Finish
Steel frame, beam and ratchet screw assembly with three wheels. Painted safety yellow.
ManufacturingHow It Is Made
The barrel frame is welded up, the beam and ratchet screw assembly fitted, wheels and axles installed, then the jack is painted.
Quality Control
What Is Checked Before Packing
Ratchet engagement is checked in both directions through the service range. Beam alignment, wheel rotation and frame welds are inspected before packing.
CertificationsCertification Status
No third-party certification is published for SL-TJ-03 Ratchet Screw Trailer Jack in S&L's own documentation, so this page marks it TBC at quotation rather than implying one. For a jack the evidence that matters is the static and lifting rating, and both are published for this model. If your specification also requires a test certificate for the delivered batch, say so before the order is placed.
Customisation
Options Within The Published Range
- Standard 6 inch beam
- Safety yellow finish
- Export packing by quantity
Comparison
How It Compares With The Alternatives
| Option | When To Choose It |
|---|---|
| SL-TJ-03 | 6 inch beam spreads the load, wheel barrel frame, 40,000 lb lifting, 180 lb. |
| SL-TJ-02 | Single 8 inch top cap, spin top head, 40,000 lb lifting, 110 lb. |
| SL-TJ-01 | No wheels, no lifting rating, 50,000 lb static, 35 lb. |
Use Guide
Getting It Right On Site
- Steer the jack into position using the barrel frame rather than lifting it
- Seat the 6 inch beam squarely across the trailer front before taking load
- Work the ratchet in short even strokes and watch the beam contact as load comes on
- Lower fully and check the ratchet releases cleanly before wheeling the jack away
Questions
SL-TJ-03 Ratchet Screw Trailer Jack Questions
What does the 6 inch beam do?
It spreads the jack's reaction across the front of the trailer instead of concentrating it under a single cap, which suits older frames and repeated lifts on the same trailer.
What is the lifting capacity?
40,000 lb, through a ratchet screw lift.
What size are the wheels?
8 inch diameter at the rear and a 4 inch wheel at the front.
How heavy is the jack?
180 lb, the heaviest in the S&L range, which is why it is on a steerable barrel frame.
Is a static capacity published for this model?
The original specification lists a 40,000 lb lifting capacity but no separate static figure. Confirm the static rating with S&L if your application needs it.
