32mm PVC Conduit for Commercial Distribution
The 32 mm conduit carries the distribution leg: power supply, lighting and data cables sharing a route through an office building or a large house. Despite the diameter it still bends cold, so it follows the structure instead of needing a fitting at every change of direction.
What This Profile Gives You
Multi Service Capacity
Accommodates several cables for power, lighting and data on one route.
Still Bends
High flexibility for its size: it can be bent to fit around corners rather than broken into fitted sections.
Impact and Corrosion Resistant
High grade PVC that resists knocks and chemical attack in service areas.
Efficient Vertical Distribution
Suits distribution between floors and rooms in apartment blocks and offices.
Application Scenarios
- Office buildings where one route carries power, lighting and data cables
- Large houses and apartment complexes distributing between floors
- Plant rooms and service corridors
Who It Is For
- Commercial contractors
- Developers of multi-storey residential
- Wholesalers serving the project trade
What Goes Wrong Without It
- Two or three parallel smaller conduits where one larger run would do
- Fittings stock being consumed by a long run with many direction changes
- Containment damaged in service corridors where trolleys and equipment knock the wall
Technical Features
- Rigid and cold bending grades
- Six stock colours
- High impact and chemical resistance
- Printed diameter and wall thickness
Customisation
OEM printing and colour, plus custom wall thickness for markets with a heavier duty requirement.
Specifications
| Nominal Size | 32 mm |
|---|---|
| Grades | Rigid and cold bending |
| Regular Colours | White, grey, red, orange, blue, yellow |
| Bending Range | 5 to 180 degrees over a matching spring |
| Joining | Solvent cement or threaded coupling |
| Packing | Bundled in printed white plastic bags |
| Wall Thickness | TBC per order |
Values marked TBC are confirmed per order against your drawing or sample. We do not publish numbers we cannot stand behind.
Quality Control
- First Inspection on the opening batch of every mould and colour run
- IPQC in-process checks on wall thickness, profile shape and colour while the line runs
- Final Inspection on packed goods before the container is loaded
Certification: RoHS, TUV and SGS; certificate copies are sent on request.
Comparison
32 mm replaces a pair of 20 mm runs on shared routes and costs less to clip and label than two pipes. Where the cable is genuinely large, move to 40 mm rather than forcing a 32 mm bore.
Use Guide
- Check clip centres: a loaded 32 mm run is heavy enough to sag between wide fixings
- Use a 32 mm spring and form the bend in a steady sweep, not a sharp pull
- Allow a straight section either side of a bend for the coupling to seat
- Label circuits at both ends before the cover trades close the route
Often Ordered Together
40mm PVC Conduit
40 mm is the top of our standard ladder and is built for large diameter cable: factory power distribution, high current feeds and the main runs in multi-storey commercial buildings.
View product →
25mm PVC Conduit
25 mm is the step where a run stops serving one circuit and starts serving several.
View product →
PVC Cable Trunking Raceway 60x40mm
A 60x40 mm raceway supplied as the wire trunking line for installers who buy channel and cover by the bundle.
View product →Where It Is Used
Questions About the 32mm PVC Conduit
Can 32 mm really be bent by hand?
With the cold bending grade and the matching spring, yes. Larger diameters need a steadier sweep, but the range is still 5 to 180 degrees.
Which grade for a buried run?
Rigid, joined with solvent cement, with the ends capped before the pour.
Is there a heavier wall version?
Wall thickness can be quoted to your standard as an ODM item; tell us the specification you need to meet.
How is the price quoted?
Per metre against a container volume, on EXW, FOB, CFR or CIF terms.
What is the production time for a full container?
Generally 7 to 15 days after the advance payment, with 5 to 10 days to finish loading one high cube.
Quote the 32mm PVC Conduit
Tell us the quantity, colour and packing you need. We reply with a price, a lead time and the container plan.
