38.7sqm Outdoor Fixed LED Screen in Izmir Turkey

6.72x5.76m, 38.7sqm · Model MSR-OFB-10 · Izmir, Turkey · Delivered 2014

Product Model	MSR-OFB-10
Screen Size	6.72x5.76m, 38.7sqm
Location	Izmir, Turkey
Delivered	2014
Product Supplied	Block Series
Sector	DOOH Advertising Networks

Who It Was For

Client Background

The buyer is not named in our project records. What is documented is the screen itself: a 38.7sqm outdoor fixed LED wall supplied on MSR-OFB-10 cabinets for a permanent installation in Izmir, Turkey, in 2014. A wall of this size on fixed cabinets is bought by a government or corporate facility owner rather than a rental company.

Challenge

The Project Challenge

Install a permanent 38.7sqm outdoor LED wall in a coastal city with high humidity and temperature variation, where the cabinets must withstand weather exposure without degradation, and the system must be serviceable from the rear due to the screen being mounted against a building facade.

Pain Points

Customer Pain Points

Outdoor cabinets must resist moisture and dust ingress over long-term exposure
Rear service access is required because the screen is mounted against a wall with no rear clearance
A fixed installation must maintain cabinet flatness and alignment without adjustment over time
The screen must operate reliably in variable outdoor temperatures without thermal stress

Solution

Our Solution

The wall was supplied on Block Series cabinets from the OFB-10 model: die-cast aluminium with a solid and stable profile, fine heat extraction performance, and rear service access. Cabinets are sealed for outdoor use with an IP rating not specified, and the 3.076/4/5/6.67/8/10mm pixel pitch options allow matching the source resolution to the display area. The 320x160mm module size supports precise alignment and consistent brightness across the wall.

How It Was Built

Manufacturing Process

SMT placement and reflow soldering of the LED modules
Soldering inspection and module ageing test before assembly
Cabinet assembly with flatness alignment on the assembling line
Screen installation test with the cabinets built up as a wall
Screen ageing test before the wall was dismantled and packed

Supply Chain

Supply Chain Coordination

Cabinets were packed with spare modules, receiving cards, and power supplies to ensure the site team had field spares immediately upon delivery, avoiding delays from second shipments.

Testing

Quality Control

Modules passed soldering inspection and an ageing test, and the cabinets were built up as a wall in the factory for a screen installation test and a screen ageing test, which ensures brightness and colour consistency across cabinets before shipment.

Result

Final Result

Documented delivery: 38.7sqm of MSR-OFB-10 outdoor fixed LED screen, supplied for Izmir, Turkey, in 2014.

Benefit

Customer Benefit

Rear service access allows maintenance without removing the screen from the wall, and the solid cabinet structure with fine heat extraction performance supports long-term outdoor operation without degradation.
