IPDI Isophorone Diisocyanate
Cycloaliphatic diisocyanate for hard weather resistant coatings
What This Product Is and Who Buys It
IPDI is a colourless to slightly yellowish cycloaliphatic diisocyanate with a mild odour. Its saturated ring structure gives high hardness and excellent light stability, which is why it is the feedstock of choice for light stable polyurethane coating systems that also have to resist abrasion.
Key Benefits
- Outstanding weather resistance and non yellowing performance
- Higher hardness than straight chain aliphatic chemistry
- Good chemical resistance and UV stability
- Mild odour compared with HDI, easier to handle on site
Where This Material Is Used
Who It Is For
- Polyisocyanate producers making IPDI trimer allophanate and uretdione derivatives
- Coil coating and plastic coating formulators
- High end furniture finish manufacturers
Problems It Solves
- Soft aliphatic topcoats that mark and scratch in service
- Coil and plastic coatings needing both flexibility and surface hardness
- Systems where an aromatic isocyanate would be cheaper but would discolour
Technical Features
- Colourless or pale yellow clear liquid
- Molecular formula C12H18N2O2, molecular weight 222.3 g/mol
- Cycloaliphatic structure with one primary and one secondary NCO group
- Mild odour, high compatibility with common polyols
Specifications
These figures are the manufacturer grade data as published for this product family. Anything not listed below has not been confirmed and is marked TBC on request rather than estimated.
| Property | Specification |
|---|---|
| Appearance | Colourless or pale yellow clear liquid |
| NCO Content (%) | ≥ 37.5 |
| Purity (%) | ≥ 99.5 |
| Colour Value | ≤ 30 |
| Hydrolysed Chlorine Content | ≤ 150 mg/kg |
| Density at 20°C | ≈ 1.06 g/cm³ |
| Molecular Weight | 222.3 g/mol |
Grades listed are representative and not exhaustive. Ask for the batch certificate of analysis on the grade you intend to buy.
How It Compares
Within the Isocyanates category this product is positioned by the numbers in the table above rather than by a marketing claim. Compare NCO content, viscosity, equivalent weight or hydroxyl value against the alternative you are considering, and if the two are close, ask us for both samples and decide on your own line.
Quality and Documentation
Quality control runs across incoming raw materials, production and finished product inspection. A batch certificate of analysis is supplied with every shipment. We are a supply and trading company working with named manufacturers and OEM partners, so certification held by the producing plant is provided on request per grade rather than claimed here as ours.
Customisation
Customised grades and packing formats are available through our OEM partners and specialised manufacturing facilities. Tell us the property you need to move and we will say whether it is a grade change, a packaging change or not possible.
IPDI Questions
How does IPDI compare with HDI?
IPDI gives harder films and slightly slower reactivity because of its cycloaliphatic ring and its secondary NCO group. HDI derivatives are more flexible. Both are light stable, so the choice is usually hardness against flexibility.
What are the two isocyanate groups?
IPDI carries one primary aliphatic NCO on the methylene bridge and one secondary NCO on the ring, and they react at different rates. That difference is used deliberately in prepolymer and blocked isocyanate work.
Is IPDI used directly or as a derivative?
Both, but most coating work uses the IPDI trimer. See our IPDI Trimer page for the isocyanurate grades and their NCO and viscosity figures.
What is the hydrolysable chlorine specification?
150 mg/kg maximum on this grade, with purity at 99.5 percent minimum and colour value at 30 maximum.
