3D Printing Filament
Rigid 3D Printing Filament with Translucent Color Made in China
Model TR-BL
Translucent blue, and the roll that carries the stiffness numbers. A flexural modulus of 2027 MPa and 68 MPa bending strength are what keep a large printed face flat instead of bowing between mounting points, which is the defect that shows up months after a big sign is installed.
- 2027 MPa flexural modulus resists bowing on large face panels
- 68 MPa bending strength supports wide unsupported spans
- 21.5 percent elongation at break gives toughness alongside stiffness
- Blue stays a clean blue when lit rather than shifting purple
Product Overview
Translucent blue, and the roll that carries the stiffness numbers. A flexural modulus of 2027 MPa and 68 MPa bending strength are what keep a large printed face flat instead of bowing between mounting points, which is the defect that shows up months after a big sign is installed.
Who It Is For
- Sign makers producing large single panel faces
- Engineers specifying the structural side of a sign
- Workshops reducing internal bracing to save material and time
Problems It Solves
- Large faces bow between fixings and the sign looks poor after installation
- Adding internal bracing costs material print time and weight
- Flexible materials distort under wind load on exposed facades
- Rigid but brittle materials crack at fixing points
Key Benefits
- 2027 MPa flexural modulus resists bowing on large face panels
- 68 MPa bending strength supports wide unsupported spans
- 21.5 percent elongation at break gives toughness alongside stiffness
- Blue stays a clean blue when lit rather than shifting purple
- Rigidity reduces the number of internal supports a large sign needs
Technical Features
- Filament type PETG-S at 1.75 MM diameter
- 340 meters per roll at 1.0 KG net and 1.3 KG gross
- Recommended printing temperature 230 to 250 degrees and bed 40 to 60 degrees
- Printing speed 40 to 120 MM per second in FDM mode
- Glass transition temperature 85 degrees with a working range of minus 40 to 70 degrees
- Tensile strength 50 MPa and bending strength 68 MPa
- Density 1.25 G per CM3 and moisture absorption 0.12 percent
- Outdoor durability 5 to 10 years
- Translucent blue colour
- Flexural modulus 2027 MPa and bending strength 68 MPa
- Elongation at break 21.5 percent and elongation at yield 4 percent
Application Scenarios
- Large lightbox faces with wide unsupported spans
- Signs mounted on widely spaced fixings
- Blue corporate identities in finance technology and healthcare
- Faces that have to stay flat under their own weight
- Elements exposed to wind load on a facade
Customisation Options
- Custom colour matched to your reference from a minimum of 100 rolls
- Spool and carton labelling on request
Product Gallery
Specifications
| Product Model | TR-BL |
|---|---|
| Filament Type | PETG-S |
| Brand Name | IROGA 3D |
| Color | Translucent Blue |
| Length | 340 Meters/Roll |
| Diameter | 1.75 MM |
| Net Weight | 1.0 KG |
| Gross Weight | 1.3 KG |
| Application | 3D Letter Printers / 3D Model Printers |
Materials
- PETG-S signage grade copolyester
Manufacturing and Quality Control
Process
- Material selection
- Compounding and pelletizing
- Filament extrusion
- Filament spooling
- Quality control
- Vacuum bagging and carton packing
Quality Control
- Diameter monitored during extrusion so feeding stays consistent
- Colour checked against the reference sample for each batch
- Each roll vacuum bagged then packed 12 rolls per export carton
Comparison With Other Options
Compared with Translucent turquoise
Turquoise carries a green cast. This is a true blue for corporate palettes that specify one.
Compared with Flexible filaments
Flexible materials cannot hold a large flat face. The stiffness figures here are why a large panel stays flat.
Use Guide
- Design fixing spacing against the bending strength rather than by eye
- Keep face thickness consistent so stiffness is uniform across the panel
- Print at 230 to 250 degrees at 40 to 120 mm per second
- Support very large faces at the centre as well as the edges
Questions
Frequently Asked Questions
Answers to what buyers ask before ordering Rigid 3D Printing Filament with Translucent Color Made in China.
How stiff is the material
Flexural modulus is 2027 MPa and bending strength is 68 MPa.
Will a large face stay flat
Stiffness is what determines this. Set fixing spacing against the bending strength and keep the face thickness consistent.
Is it brittle
Elongation at break is 21.5 percent and Charpy impact strength is 7.9 KJ per M2, so it is stiff without being brittle.
Is this a true blue
Yes, translucent blue. Turquoise is the separate option with a green cast.
What is the minimum order quantity
1 roll for stocked colours. A customised colour has a minimum of 100 rolls.
How is the filament packed for export
Each roll goes into a vacuum bag and 12 rolls are packed per standard export carton, at 440 x 440 x 220 MM.
What warranty applies
One year quality warranty on all products with lifetime technical support.
