3D Printing Material for Long Time Outdoor Use in Opaque Gray Color
Mid gray gives a lit face a defined edge without the hardness of black
View product
3D Printing Filament
3D Printing Consumables for 3D Signage Printers and 3D Model Printers
Model OP-GN
PETG-S in opaque green, supplied for workshops that run a signage printer and a model printer side by side. One industrial material across both machines means one set of temperature profiles, one stock line and no risk of a model grade filament ending up in an outdoor sign.
- Runs on 3D signage printers and 3D model printers so one material covers both machines
- Industrial grade rather than hobby grade, produced for signage service life
- Opaque green blocks light so it is used where a solid non lit element is wanted
- 340 meters per roll keeps roll changes off the operator during long jobs
Product Overview
PETG-S in opaque green, supplied for workshops that run a signage printer and a model printer side by side. One industrial material across both machines means one set of temperature profiles, one stock line and no risk of a model grade filament ending up in an outdoor sign.
Who It Is For
- Sign shops with mixed FDM machine types
- Workshops standardising on one industrial filament
- Buyers who want an opaque colour for non lit parts
Problems It Solves
- Hobby grade filament in an outdoor sign fails within a season
- Running different materials on different machines doubles the process settings to manage
- Translucent filament is wrong for parts that should not glow
Key Benefits
- Runs on 3D signage printers and 3D model printers so one material covers both machines
- Industrial grade rather than hobby grade, produced for signage service life
- Opaque green blocks light so it is used where a solid non lit element is wanted
- 340 meters per roll keeps roll changes off the operator during long jobs
- Rated easy to print with no jamming which matters on unattended runs
Technical Features
- Filament type PETG-S at 1.75 MM diameter
- 340 meters per roll at 1.0 KG net and 1.3 KG gross
- Recommended printing temperature 230 to 250 degrees and bed 40 to 60 degrees
- Printing speed 40 to 120 MM per second in FDM mode
- Glass transition temperature 85 degrees with a working range of minus 40 to 70 degrees
- Tensile strength 50 MPa and bending strength 68 MPa
- Density 1.25 G per CM3 and moisture absorption 0.12 percent
- Outdoor durability 5 to 10 years
- Opaque green colour
- Application 3D signage printers and 3D model printers
Application Scenarios
- Workshops running signage and model printers together
- Solid unlit letter returns and backing plates
- Green corporate identity elements
- Prototype parts printed on the same machine as production signage
- Fixtures and jigs printed in house
Customisation Options
- Custom colour matched to your reference from a minimum of 100 rolls
- Spool and carton labelling on request
Product Gallery
Specifications
| Product Model | OP-GN |
|---|---|
| Filament Type | PETG-S |
| Brand Name | IROGA 3D |
| Color | Opaque Green |
| Length | 340 Meters/Roll |
| Diameter | 1.75 MM |
| Net Weight | 1.0 KG |
| Gross Weight | 1.3 KG |
| Application | 3D Signage Printers / 3D Model Printers |
Materials
- PETG-S signage grade copolyester
Manufacturing and Quality Control
Process
- Material selection
- Compounding and pelletizing
- Filament extrusion
- Filament spooling
- Quality control
- Vacuum bagging and carton packing
Quality Control
- Diameter monitored during extrusion so feeding stays consistent
- Colour checked against the reference sample for each batch
- Each roll vacuum bagged then packed 12 rolls per export carton
Comparison With Other Options
Compared with PLA
PLA prints easily but is not specified for long outdoor service. PETG-S is rated 5 to 10 years outdoors.
Compared with Translucent colours
Translucent filament passes light for illuminated faces. Opaque green is chosen where light must be blocked.
Use Guide
- Set the nozzle to 230 to 250 degrees and the bed to 40 to 60 degrees
- Apply platform glue over the whole print area before starting
- Dry the roll if it has been open in humid air before a long job
- Store unused rolls in the vacuum bag
Questions
Frequently Asked Questions
Answers to what buyers ask before ordering 3D Printing Consumables for 3D Signage Printers and 3D Model Printers.
Can I use this on a normal 3D model printer
Yes. It is made for 3D signage printers and 3D model printers alike, for amateur and professional users.
What temperature should I print at
230 to 250 degrees at the nozzle and 40 to 60 degrees at the bed.
How much is on one roll
340 meters, 1.0 KG net weight.
Does opaque green let light through
No. Opaque colours block light and are used for returns backing and non lit elements.
What is the minimum order quantity
1 roll for stocked colours. A customised colour has a minimum of 100 rolls.
How is the filament packed for export
Each roll goes into a vacuum bag and 12 rolls are packed per standard export carton, at 440 x 440 x 220 MM.
What warranty applies
One year quality warranty on all products with lifetime technical support.
