Spray Painting Machine
Automatic UV PE Spray painting Machine Slightness Surface Wood Furniture Spraying
Long bed reciprocating sprayer built around a 2400 mm door leaf. Configured for UV and PE paint on smooth surface furniture work.
Product Overview
Door Spray Painting Machine For Uv Pe Spraying For Smooth Surface Furniture
Configured for UV and PE paint on smooth surface furniture work.
A reciprocating spray painting machine laid out for door work: 8800 mm of bed handles a 2400 mm processing length at 1100 mm paint width, cycling at one to two minutes per door. Total power is 7.5 kW on 380 V 50 Hz, and the machine weighs 3000 kg.
TSI-1300
Key Benefits
What This Machine Changes On Your Floor
1
2400 mm processing length takes a full door leaf
2
One to two minutes per door gives a predictable hourly rate
3
7.5 kW total power on a standard 380 V 50 Hz supply
4
Sealed paint room with exhaust keeps dust out of the wet film
Who It Is For
Plants That Buy This Machine
- Finishers quoting by the door rather than by the square metre
- Interior door plants spraying leaves in volume
- Cabinet plants with tall components
Problems It Solves
What It Removes From Your Process
- Edges and faces get different film weights when sprayed by hand
- A panel sized booth cannot take a full 2400 mm door leaf
- Door output is measured in doors per hour and manual spraying cannot hold the rate
Application Scenarios
Typical Jobs It Runs
Coating long flat components at 1100 mm width
Spraying primer and top coat on flush and moulded door leaves
Painting tall wardrobe doors
Technical Features
How It Is Built
- 8800 mm long bed for full door leaves
- Reciprocating gun arm with photoelectric workpiece detection
- Sealed paint room with air exhaust system
- Fire proof lighting inside the spraying room
Specifications
Technical Data
| Parameter | Value |
|---|---|
| Model | TSI-1300 |
| Max.Paint Width | 1100mm |
| Feeding Speed | 1-2 |
| min/door Processing Length | 2400mm |
| Working Air Pressure | 0.6-0.8Mpa |
| Power Standard | 380V |
| / | 50Hz |
| TTotal Power | 7.5kw |
| Dimension(Length x Width x Height) | 8800x4700x2490mm |
| Net Weight | 3000Kg |
All machines can be customised to the buyer's requirement. Figures are the published data for this model series.
Quality Control
Checked Before It Leaves The Floor
- Full length door run through the bed and film weight checked end to end
- Gun arm travel verified across the 1100 mm paint width
- Exhaust and booth sealing tested
Customisation Options
Specified Per Order
- Bed length and paint width set for your door size
- Gun count for primer or top coat duty
- Conveyor connection to a dryer downstream
Comparison
How It Compares With The Alternatives
vs ITSII-1300 panel sprayer
The door machine trades paint width for an 8800 mm bed that takes a 2400 mm leaf
vs Manual door spraying
One to two minutes per door, repeated, instead of a rate that depends on who is holding the gun
Use Guide
Setting The Machine Up For A Run
Confirm air supply is between 0.6 and 0.8 MPa
Set the cycle for the door length you are running
Spray a test door and check film weight at both ends
Clean the guns and filters at the end of each colour
Related Machines
Woodworking Furniture Spray painting machine Panel Spraying machine for UV PE
Enclosed reciprocating spray booth that paints 1300 mm panels at a controlled film weight. Built to order.
View Machine Data →
Woodworking Furniture Panel Spraying machine Spray painting machine
Enclosed reciprocating spray booth that paints 1300 mm panels at a controlled film weight. Built to order.
View Machine Data →
Automatic Woodworking Spray Painting Machine Reciprocating UV Wood Furniture Cabinet CNC
Long bed reciprocating sprayer built around a 2400 mm door leaf. Built to order.
View Machine Data →
Questions About This Machine
Is this model set up for UV PE spraying for smooth surface furniture?
Yes. Configured for UV and PE paint on smooth surface furniture work. Every machine is built to order, so the configuration is confirmed against your own panel size and coating system before production.
What is the paint width?
1100 mm.
How many doors per hour?
The cycle is one to two minutes per door.
What power supply?
380 V, 50 Hz, 7.5 kW total power.
How much floor space does it need?
8800 x 4700 x 2490 mm.
What door length can it take?
Processing length is 2400 mm.
Ask For A Quotation On The Automatic UV PE Spray Painting Machine Slightness Surface Wood Furniture Spraying
Send your panel size, coating system and line speed. You will get the model recommendation, full technical data and a price.
