Import the pattern
Glue graphics are imported to the control system instead of being set by hand on each format change.
Solution
Glue Spraying and Drawing For Post-Press Box Work
Every Guorun machine applies adhesive by computer-controlled spraying rather than roller coating. The control system sprays stripe, dot and mist patterns, and can spray fonts and logos, which saves glue, holds adhesion and leaves no missed areas. The GR-500B online glue drawing machine covers inline gluing within an existing line.
Process
From First Enquiry To A Running Machine
Each stage below produces something you can check: a matched envelope, a signed delivery term, a tested first-article box.
Choose the pattern type
Stripes for panel edges, dots for large flat areas, mist for full coverage, and text or logo patterns where required.
Set the dispense area
Each model publishes a maximum and minimum glue area, from 50 x 50 mm up to 600 x 550 mm.
Verify the bond
A first-article box shows whether the bond line is free of bubbles and squeeze-out before the run is released.
Maintain the nozzle
Nozzle cleanliness at shift change is the single largest factor in consistent spray edges, together with holding 0.7 MPa air.
The GR-500B online glue drawing machine is part of the Guorun range. Published specifications are to be confirmed, so it is quoted on request rather than listed with a specification table.
Machines Involved
Equipment Used In This Solution
GR-600B
GR-600B Semi-Automatic Single Station Side and Plane Dual Purpose Assembly and Forming Machine
Single-station semi-automatic rigid box assembly machine that sprays glue on side panels and flat surfaces, takes shells up to 850 x 450 mm and changes over in about five minutes.
GR-1100ZA
GR-1100ZA Fully Automatic Collapsible Box Spraying and Assembly Line
Nine-metre fully automatic collapsible box spraying and assembly line handling shells to 1050 x 500 mm at 0.3 mm positioning and about 7,000 units per day.
GR-1000B
GR-1000B Semi-Automatic Dual Station Side and Plane Dual Use Assembly and Forming Machine
Two-station semi-automatic rigid box assembly machine covering shells up to 950 x 550 mm, with separate size envelopes for single and dual station work.
Answers
Post-Press Glue Spraying Questions
Why spray glue instead of using a roller
Spraying places adhesive only where it is needed, which reduces consumption and avoids squeeze-out at the seam.
Can the machine spray a logo
Yes. The control system sprays fonts and logos as well as stripe, dot and mist patterns.
What air pressure is needed
0.7 MPa on every model in the range.
Is the GR-500B glue drawing machine available
Yes, on request. Its published specification table is still to be confirmed, so it is quoted individually.
Next Step
Discuss Post-Press Glue Spraying With Our Engineers
Describe the box, the volume and the workshop constraint. We will come back with the model shortlist, the utilities needed and a realistic delivery date.
