Building a Collapsible Box Forming Line
Collapsible box lines are specified around the fold, not the footprint. Wing and side panel sizes, the number of links in the board system and the placement accuracy decide whether the box erects square at the customer's warehouse. Guorun builds three levels of the same process.
Process
From First Enquiry To A Running Machine
Each stage below produces something you can check: a matched envelope, a signed delivery term, a tested first-article box.
Pick the automation level
GR-1000BA for short runs and samples, GR-1100ZA for volume, GR-1200ZA where vision-guided placement is needed.
Plan the run length
2.2 m for the GR-1000BA, 9 m for the GR-1100ZA and 11.5 m for the GR-1200ZA, plus access on the operator side.
Confirm power and air
4 kW at 220 V, or 25 kW and 28 kW at 380 V. Compressed air at 0.7 MPa on all three.
Prove the fold
First-article boxes are folded and re-erected during the factory test before the line ships.
Hand over
Operation training, one-year warranty and compliance documents for import clearance.
Machines Involved
Equipment Used In This Solution
GR-1000BA
GR-1000BA Semi-Automatic Collapsible Box Forming Machine
Compact semi-automatic collapsible box forming machine running on 220 V, covering shells from 250 x 180 mm to 1000 x 490 mm at 0-18 pcs/min.
GR-1100ZA
GR-1100ZA Fully Automatic Collapsible Box Spraying and Assembly Line
Nine-metre fully automatic collapsible box spraying and assembly line handling shells to 1050 x 500 mm at 0.3 mm positioning and about 7,000 units per day.
GR-1200ZA
GR-1200ZA 7-Link Board Collapsible Box Forming Machine
High-precision 7-link board collapsible box line with CCD vision glue dispensing and a four-axis robot, running shells to 1000 x 450 mm at 2 mm robot positioning.
Answers
Collapsible Box Forming Lines Questions
What decides between the GR-1100ZA and the GR-1200ZA
Blank complexity. The GR-1200ZA adds CCD vision and a four-axis robot for irregular and craft geometry the GR-1100ZA does not target.
How much floor length should I reserve
Nine metres for the GR-1100ZA and 11.5 metres for the GR-1200ZA, plus maintenance access.
What positioning accuracy do the lines hold
0.3 mm forming positioning accuracy, with 2 mm robot placement on the GR-1200ZA.
Can a small workshop start with one machine
Yes. The GR-1000BA runs on 220 V, weighs 260 kg and covers shells up to 1000 x 490 mm.
Next Step
Discuss Collapsible Box Forming Lines With Our Engineers
Describe the box, the volume and the workshop constraint. We will come back with the model shortlist, the utilities needed and a realistic delivery date.
