Collapsible Box Making Machine
Collapsible Box Forming Machines and Lines
Guorun collapsible box machines glue and form folding boxes, including handbag-style boxes, shoe boxes and flat-packed gift boxes. The range starts at the 220 V GR-1000BA for small workshops and runs up to the GR-1200ZA 7-link board line with CCD vision and a YAMAHA four-axis robot. Forming positioning accuracy is 0.3 mm across the range.
Every Model In This Range
Collapsible Box Making Machine Models and Published Envelopes
Machines and full lines that glue and form folding boxes so they ship flat and erect square at the far end.
GR-1000BA
GR-1000BA Semi-Automatic Collapsible Box Forming Machine
Compact semi-automatic collapsible box forming machine running on 220 V, covering shells from 250 x 180 mm to 1000 x 490 mm at 0-18 pcs/min.
GR-1100ZA
GR-1100ZA Fully Automatic Collapsible Box Spraying and Assembly Line
Nine-metre fully automatic collapsible box spraying and assembly line handling shells to 1050 x 500 mm at 0.3 mm positioning and about 7,000 units per day.
GR-1200ZA
GR-1200ZA 7-Link Board Collapsible Box Forming Machine
High-precision 7-link board collapsible box line with CCD vision glue dispensing and a four-axis robot, running shells to 1000 x 450 mm at 2 mm robot positioning.
What This Range Solves
Production Problems These Machines Are Built Around
Boxes that do not fold flat0.3 mm forming positioning keeps wings and side panels square, so the box collapses and re-erects cleanly.
Separate spraying and assembly stationsThe GR-1100ZA and GR-1200ZA run spraying, positioning and pressing as one continuous line.
Complex blanks that defeat fixed glue patternsFull-vision camera glue dispensing on the GR-1200ZA follows the actual blank instead of a fixed path.
No spare three-phase capacityThe GR-1000BA runs on 4 kW at 220 V and weighs 260 kg.
Industries This Range Serves
- Footwear and Apparel Box Packaging
- Wine and Gift Box Packaging
- Cosmetic and Eye Shadow Box Packaging
- Electronics and Jewellery Box Packaging
Each industry page lists the specific models whose published envelope fits that market's formats.
Related Solutions and Ranges
- Rigid Box Assembly Lines
- Collapsible Box Forming Lines
- Post-Press Glue Spraying
- Rigid Box Assembly and Forming Machines
The GR-950WA appears in both machine ranges because an integrated side and plane machine covers work at the boundary between them.
Answers
Collapsible Box Making Machine Questions
What is the smallest collapsible box machine Guorun builds
The GR-1000BA at 2200 x 1400 x 1750 mm and 260 kg, running on 4 kW at 220 V.
Which line handles irregular and craft boxes best
The GR-1200ZA, because CCD vision and a four-axis robot place panels that a fixed mechanism cannot.
How much output can a fully automatic line produce
Around 7,000 pieces per day on both the GR-1100ZA and the GR-1200ZA.
What is the largest finished collapsible box
450 x 450 x 150 mm on the GR-1200ZA, from a case shell up to 1000 x 450 mm.
How long is the delivery time
Sample delivery is quoted at 30 working days and OEM orders at 45 working days.
Next Step
Get A Quote On A Collapsible Box Making Machine
Send us the box you need to run. We will confirm which models in this range cover it, what the utilities look like and what the delivery time would be.
